Model Image
Manufacturer

Electrolux

Model Number

ATC150BK2

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
5303207410 5303207410 + ORIFICE,NATURAL GAS ,SIZE 44
5303281019 5303281019 BALL,GROUNDING
131419800 131419800 CLAMP,MOTOR MTG.
5303001199 5303001199 CLAMP-WIRING HARNES
5303281020 5303281020 CLIP,BALL ,STEEL ,FLAT NUT
131197000 131197000 CLIP,CONSOLE MTG
5303281074 5303281074 CLIP,GUIDE ,(3)
3205821 3205821 CLIP,TOP-TO-FRONT
5308003596 5308003596 CLIP-COMPRESSOR MTG
3206135 3206135 COVER
131658800 131658800 DOOR CATCH
5308000255 5308000255 DOOR STOP
131621903 131621903 DUCT,AIR
3205266 3205266 EDGE PROTECTOR
5303291344 5303291344 END CAP-L, H,
5303291352 5303291352 END CAP-R, H,
5303276130 5303276130 FRAME-NAMEPLATE
131129900 131129900 GASKET,DOOR SEAL
5303937139 5303937139 GLIDE-DRUM
131644700 131644700 HANDLE,DOOR ,WHITE
5308009875 5308009875 HANDLE-DOOR
3206349 3206349 HARNESS-WIRING-INTERNAL IM-W/ PLUG
3206120 3206120 HEATER-MULLION
3916557 3916557 HOT TUBE REPAIR KIT
3206111 3206111 INSERT-CRISPER CVR
5303283286 5303283286 LOWER FELT
131560100 131560100 MOTOR & PULLEY ASSY
3206125 3206125 MULLION
5303001348 5303001348 NUT
5303270406 5303270406 OVERLOAD SERVICE COMPRESSOR
5303916001 5303916001 PAN RETAINER, KIT, SERVICE
5303916980 5303916980 PANEL-REFR DOOR
5308000184 5308000184 PIN CENTER HINGE
5303001321 5303001321 PIN, LOWER HINGE
240494004 240494004 PLUG-BUTTON
5303001308 5303001308 PLUG-BUTTON
5303001389 5303001389 PLUG-BUTTON
5303281153 5303281153 REAR BEARING KIT,INCLUDES 5,6 ,12,13,14,18,32
5308011745 5308011745 SCREW
5303001380 5303001380 SCREW
5308000039 5308000039 SCREW
5303283289 5303283289 SCREW, CR PAN HEAD, 8-32 X 0.250, THREAD FORMING
131205300 131205300 SCREW,10-16 X 0.750
131477000 131477000 SCREW,10-16AB X 0.375
131205400 131205400 SCREW,BRACKET MTG. ,10-16B X 1.375 ,CR/SQ DRIVE
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
5303015671 5303015671 SCREW,HEX WASHER HEAD ,8-18 X 0 .375 ,CUP POINT
131527400 131527400 SCREW,LEVELING LEG
131168200 131168200 SCREW,PAN HEAD ,8-18B X 0.31
131382300 131382300 SCREW,QUADREX HEAD ,10-14 X 1.00 ,VANE MTG.,SPECIAL
131243800 131243800 SCREW-BRKT TOP,PAN HD LOCKING ,
5303001260 5303001260 SCREW-CONTROL MTG
5308013645 5308013645 SCREW-HANDLE MTG
241710601 241710601 SCREW-HINGE MTG,HEX HD ,1/4-20 X 0.875
3206141 3206141 SCREW-LEVELING
5303281135 5303281135 SENSOR,RADIANT
5303001037 5303001037 SHIM -UPPER HINGE
131601000 131601000 SPRING,IDLER ARM
5303006412 5303006412 STRAP-COVER MTG
3206166 3206166 SUPPORT-DOOR RACK, EXTENDS 1.06``, LH
3206165 3206165 SUPPORT-DOOR RACK, EXTENDS 1.06``, RH
3206150 3206150 SUPPORT-DOOR RACK, EXTENDS 1.81``, RH
316442300 316442300 SURFACE UNIT LARGE
5303203636 5303203636 SWITCH, INTERLOCK
131469000 131469000 SWITCH,PUSH/START
5309918806 5309918806 SWITCH-LIGHT/ LAMP
5308012296 5308012296 TAPPING PLATE
5308015399 5308015399 THERMOSTAT,SAFETY
5308015398 5308015398 THERMOSTAT,TEMP CONTROL
5303297139 5303297139 TIMER,DRYER
134237200 134237200 TIMER,WASHER ,5 OFF
131450300 131450300 TRAP,LINT BLADE ASSY
5303916855 5303916855 TUBE
131451600 131451600 TUBE,EXHAUST ,REAR ,W/MTG BRACKET
131456800 131456800 TUBE,EXHAUST ,SIDE/BOTTOM ,OPTIONAL KIT
5303207409 5303207409 VALVE,GAS
137552900 137552900 VANE,STRAIGHT
5308009617 5308009617 WASHER
5308000186 5308000186 WASHER , .34 X .62 X .10, NYLON
5308003633 5308003633 WASHER-COMPR MTG
