Model Image
Manufacturer

Electrolux

Model Number

CGLES389FS3

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
318317100 318317100 ADAPTER ASSEMBLY
318335500 318335500 ANTI-TIP & ACCESSOR
318259220 318259220 BACK
316435702 316435702 BOARD
318272901 318272901 BOX
318225429 318225429 BOX
318306900 318306900 BRACKET
318261600 318261600 BRACKET
318298410 318298410 BRACKET
318318600 318318600 BRACKET
318251300 318251300 BRACKET
318382301 318382301 BRACKET
5303013071 5303013071 BULB/LAMP
318147430 318147430 BUMPER
318233400 318233400 BUSHING
5304447071 5304447071 CLIP
316095800 316095800 CLIP
316418735 316418735 CLOCK/TIMER
318299100 318299100 CONSOLE
316441801 316441801 CONTROL
316441804 316441804 CONTROL
318313803 318313803 CONTROL PANEL ASSEM
318262001 318262001 COVER
5303310526 5303310526 COVER
318123910 318123910 DEFLECTOR
318304404 318304404 DRAWER
318549825 318549825 DUCT
318254906 318254906 ELEMENT
318255503 318255503 ELEMENT
318255301 318255301 ELEMENT
318398302 318398302 FAN BLADE
318298226 318298226 FRAME
318298210 318298210 FRAME
318056217 318056217 FRONT
318223900 318223900 GASKET
318212210 318212210 GLASS
316117500 316117500 GLASS
318259506 318259506 GLIDE
318259507 318259507 GLIDE
316105501 316105501 GLIDE
316246102 316246102 HANDLE
318224813 318224813 HARNESS
318228852 318228852 HARNESS
318224945 318224945 HARNESS
318231848 318231848 HARNESS
318228932 318228932 HARNESS
318222400 318222400 HOUSING
316082000 316082000 INSERT
318594300 318594300 INSULATION
318044827 318044827 LIGHT
318261400 318261400 LINER
318223642 318223642 MAIN TOP
5304463302 5304463302 MOTORCONVECTION
316247700 316247700 NUT
316081900 316081900 PAN
318224405 318224405 PANEL
318260007 318260007 PANEL
318296902 318296902 PANEL
318296903 318296903 PANEL
318225110 318225110 PANEL
318225210 318225210 PANEL
318225211 318225211 PANEL
318303907 318303907 PANEL
318300300 318300300 PANEL
318300003 318300003 PANEL
318003000 318003000 PLATE
5303320846 5303320846 PLATE
318227503 318227503 PLATE
316217002 316217002 PROBE
318342400 318342400 RECEPTACLE
318112703 318112703 RELAY
318233721 318233721 RETAINER
5304400195 5304400195 RETAINER
5304453707 5304453707 SCREW
5303323134 5303323134 SCREW
5303300265 5303300265 SCREW
5303311333 5303311333 SCREW
5303323129 5303323129 SCREW
5303323139 5303323139 SCREW
318175503 318175503 SCREW
5303211311 5303211311 SCREW
3051050 3051050 SCREW
5304415832 5304415832 SCREW
5303307980 5303307980 SCREW
5304436875 5304436875 SCREW
5304459529 5304459529 SCREW
318053130 318053130 SEAL,DOOR,LOWER OVEN
318258902 318258902 SHIELD
318303800 318303800 SHIELD
316247900 316247900 SPACER
318165800 318165800 SPACER
316114100 316114100 SPACER
318014411 318014411 SPACER
316402403 316402403 SPACER
318192400 318192400 SPRING
318122008 318122008 SPRING
318122010 318122010 SPRING
5304403015 5304403015 SUPPORT
316445501 316445501 SWITCH
318005212 318005212 SWITCH
318005213 318005213 SWITCH
318003614 318003614 THERMOSTAT
318005108 318005108 THERMOSTAT
318298001 318298001 TRIM
318260201 318260201 TRIM
318260401 318260401 TRIM
318249403 318249403 TUBE
318531701 318531701 USE 318531701
316247800 316247800 WASHER
316136500 316136500 WASHER
3051063 3051063 WASHER
318199749 318199749 WIRING HARNESS
