Model Image
Manufacturer

Electrolux

Model Number

CRTE217AS2

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
241602010 241602010 BASECOMPRESSOR
240527102 240527102 BEARING-HINGE
240495804 240495804 BIN-DOOR
5303321321 5303321321 BLACK TOUCHUP PAINT
240335502 240335502 BOLT-ROLLER ADJ
240368102 240368102 BOX
240313803 240313803 BRACKET-CTR HINGE
5303292397 5303292397 BRACKET-MOTOR MTG
5303292396 5303292396 BRACKET-MOTOR MTG
241555401 241555401 BULB-LAMP
218233300 218233300 CHANNEL
5303292395 5303292395 CHANNEL-SHELF MTG
241941901 241941901 CLAMP
240396801 240396801 CLAMP-TUBE
218490901 218490901 CLEANER
240542601 240542601 CLIP-WIRING HARNESS
241613501 241613501 CONTROL-HUMIDITY
241613502 241613502 CONTROL-HUMIDITY
241733907 241733907 COVER
240364718 240364718 COVER-CRISPER PAN
240354404 240354404 COVER-UPPER HINGE
241523701 241523701 DAMPER-FAN COVER
240362601 240362601 DIFFUSER
240545901 240545901 DIFFUSER-AIR
240337901 240337901 DOOR BIN FOR REFRIGERATOR
240338101 240338101 DOOR BIN SHELF
240312405 240312405 DOOR STOP
240312406 240312406 DOOR STOP
240450366 240450366 DSP DOOR
240450478 240450478 DSP DOOR-COMPLETE
241615436 241615436 ENERGY GUIDE
5303918274 5303918274 EVAPORATOR KIT
5308000010 5308000010 FAN BLADE
241872514 241872514 GASKET
241872511 241872511 GASKET-FRZR DOOR
241839407 241839407 GRILLE/KICKPLATE
240405201 240405201 GROMMET
5304500407 5304500407 GROMMET
218513300 218513300 GROMMET-COMPR MTG
240339203 240339203 HANDLE-DOOR
5303918330 5303918330 HEAT EXCHANGER KIT
5304421289 5304421289 HOT TUBE REPAIR KIT
241551902 241551902 INSULATION BLOCK
240360801 240360801 KNOB
240367001 240367001 KNOB-DAMPER CONTROL
241560701 241560701 LIGHT BULB
241854501 241854501 MOTOREVAP FAN
5303212803 5303212803 NUT
240343803 240343803 PAN
240516502 240516502 PIN-LOWER HINGE
240494001 240494001 PLUG
240383603 240383603 PLUG-BUTTON
241586701 241586701 PLUG-FOAM-WTR-INLET
5303208309 5303208309 PLUG-HOLE
240374401 240374401 PLUG-WTR INLET TUBE
215774918 215774918 PLUGBUTTON
240338001 240338001 REFRIG DOOR SHELF BAR
5304455655 5304455655 RIVET
5304418225 5304418225 ROLLER
240335006 240335006 ROLLER ASSEMBLY
5304455649 5304455649 SCREW
5304455650 5304455650 SCREW
218252201 218252201 SCREW
240383406 240383406 SCREW
241710601 241710601 SCREW
218362501 218362501 SCREW
240433204 240433204 SCREW
241500303 241500303 SCREW
218897004 218897004 SCREW
215005101 215005101 SCREW
240442707 240442707 SCREW-#10-32 X 3/4
240555002 240555002 SCREW-#8-32 X 3/8
240491503 240491503 SCREW-COMPRESSOR MT
240359403 240359403 SCREW-FAN SHROUD
240578902 240578902 SCREW-HINGE MTG
218709101 218709101 SCREWHDL MTG
240568606 240568606 SEAL-COIL COVER
240355228 240355228 SHELF-SPILL-SAFE
240354302 240354302 SHIELDLIGHT
241559801 241559801 SOCKET-LIGHT
240336803 240336803 SPACER-HINGE
241932402 241932402 STARTERPTC
5308000110 5308000110 STRAP-EVAP/HEATER
240505801 240505801 SWITCH
241554901 241554901 SWITCH-LIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
240356501 240356501 TRACK
240365401 240365401 TRACK
240337610 240337610 TRIMCABINET CORNER
241801301 241801301 TROUGH-DRAIN
241871501 241871501 TUBECONNECTOR
240311303 240311303 WASHER
215474201 215474201 WASHER
241537701 241537701 WIRING HARNESS
240388701 240388701 WIRING HARNESS
