Manufacturer
Electrolux
Model Number
EFDE210TIW01
Description
Laundry, Residential, Electric Dryer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BASEMENT,CONDENSOR P10 |
|
|
BELT, DRIVE, L=1886.7MM |
|
|
BELT, DRIVE, L=267.5MM, REDUCTION GEAR |
|
|
BLOWER WHEEL |
|
|
BOARD, CONTROL, CONFIGURED |
|
|
BOLT, 5, 5X38 |
|
|
BULKHEAD KIT, REAR, PLASTIC, W/INSL MAT |
|
|
BUSHING KIT, MOTOR, FRONT & REAR |
|
|
BUSHING, HINGE |
|
|
BUSHING, SUPPORT, ROLLER |
|
|
BUSHING, TANK |
|
|
BUTTON, DOOR, WHITE |
|
|
BUTTON, RECT ON/OFF, SILVER |
|
|
CATCH, DOOR LOCK, GLASS DOOR |
|
|
CONDENSER, STEAM ASMY |
|
|
CONE, AGITATOR, ANTI-ENTANGLE |
|
|
CONE, ANTI-ENTANGLE, BASE |
|
|
CONNECTOR, UPPER TANK |
|
|
COVER KIT, HEATING ELEMENT, W/GASKET |
|
|
COVER PLATE, DOOR LOCK, WHITE |
|
|
COVER, BASEMENT |
|
|
COVER, FAN WHEEL, BACK |
|
|
COVER, FAN WHEEL, FRONT |
|
|
COVER, MAIN BOARD, WHITESHARK |
|
|
COVER, METAL, ROLLER |
|
|
COVER, PUMP, FLOAT SWITCH |
|
|
COVER,KICKPLATE |
|
|
DIFFUSER, SUPPORT, LUMINOUS DIODE |
|
|
DOOR |
|
|
DOOR, CONDENSER, BASEMENT |
|
|
DOOR, INNER, WHITE, SUPPORT |
|
|
DRUM, COMPLETE |
|
|
DUCT, AIR, FRONT, LAMP |
|
|
FAN, WHEEL, COOLING, BACK |
|
|
FELT, DISC, ?24/?12MM |
|
|
FILTER, ANTI-INTERFER, POWER CABLE |
|
|
FILTER, FLUFF |
|
|
FITTINGS, DRAIN, CONDENSE, KIT, DK11 |
|
|
FIXING BRACKET, MAIN MOTOR FRNT |
|
|
FIXING BRACKET, MAIN MOTOR FRNT |
|
|
FRAME, INNER DOOR, 0457.4MM, WHITE |
|
|
FRAME, OUTER DOOR, 0458MM, WHITE |
|
|
GASKET |
|
|
GASKET, DOOR, BASEMENT |
|
|
GASKET, DRUM, BACK, 1683MM |
|
|
GASKET, FILTER |
|
|
GASKET, FT, LG OPENING, 17.5X20X1683MM |
|
|
GASKET, HEAT EXCHANGER, NEX4 COND, FRONT |
|
|
GASKET, HEATER, BASEMENT |
|
|
GLASS |
|
|
GLASS, OUTER DOOR, ?414MM |
|
|
GRATING, PROTECTION, HEATING ELEMENT |
|
|
HANDLE, STEAM CONDENSOR |
|
|
HARNESS, ANTI-INTERFER |
|
|
HARNESS, DRUM LIGHTING |
|
|
HARNESS, EARTH, 130+180+420MM |
|
|
HARNESS, H AT ELEMENT |
|
|
HARNESS, HEAT ELEMENT |
|
|
HARNESS, HUMIDITY SENSOR |
|
|
HARNESS, MOTOR, TO MAIN BOARD |
|
|
HARNESS, TEMP PROBE |
|
|
HARNESS, UI BOARD |
|
|
HARNESS, UI BOARD |
|
|
HEATER |
|
|
HINGE PIN, DOOR, PLINTH |
|
|
HINGE, CONDENSER DOOR |
|
|
HINGE, DOOR, GLASS |
|
|
HOSE |
|
|
HOSE, OVERFLOW, 1040MM |
|
|
KNOB, DOOR LOCK, BASEMENT |
|
|
LAMP, LED, 0.5W, UL |
|
|
LEG, LEVEL, ADJUST |
|
|
LOCK |
|
|
MOTOR, REDUCTION GEAR, 200V, 267HZ, 207W |
|
|
PANEL, BACK ASMY, P10, SAHARA |
|
|
PANEL, CONTROL, WHITE, W/HANDLE |
|
|
PANEL, FRONT, WHITE |
|
|
PANEL, TOP ASSY., 597X501.6MM, WHITE |
|
|
PANEL-SIDE |
|
|
PC BOARD, CONTROL, USER INTERFACE, ASSEMBLY |
|
|
PIPE, DISCHARGE, L=331.5MM |
|
|
PIVOT, DOOR HINGE |
|
|
PUMP, CONDENSATION, 240V, 60HZ, 15W |
|
|
ROLLER,SUPPORT,DRUM |
|
|
SEALING, AIR DUCT, BASEMENT |
|
|
SEALING, TEMP SENSOR |
|
|
SENSOR, HUMIDITY |
|
|
SPRING, BUTTON, ON/OFF |
|
|
SPRING, DOOR, PLINTH |
|
|
SUPPORT KIT, BUTTON, DOOR, W/SPRING |
|
|
SUPPORT, HUMIDITY SENSOR |
|
|
SUPPORT, PUMP |
|
|
SUPPORT, TANK |
|
|
SUPPORT, TENSION SPRING |
|
|
SWITCH, DOOR |
|
|
SWITCH, MICRO, FLOAT |
|
|
TANK, UPPER |
|
|
TAPPET, DOOR, UL |
|
|
TEMPERATURE PROBE, NTC |
|
|
TENSION SPRING, MTR, ENV06 CRM |
|
|
TERMINAL BLOCK, ASMY, WIRING, UL |
|
|
TUBE, HOLDER |
|
|
VANE, DRUM, 298.3MM, GREY |
