Manufacturer
Electrolux
Model Number
ERMC2295AS03
Description
Refrigerator, French Door, Multi-drawer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
AIR FILTER, PURE AIR ULTRA2, ELUX |
|
|
AIR HANDLER HOUSING KIT, FDBM |
|
|
BADGE, ELECTROLUX, CHROME |
|
|
BAFFLE ASSEMBLY, AIR DAMPER, MIDDLE DRAWER |
|
|
BAR-DRIVE |
|
|
BASE, COMPRESSOR ASSY |
|
|
BASKET ASSEMBLY, FREEZER DRAWER, GRAY, W/DIVIDER |
|
|
BASKET ASSEMBLY, MIDDLE DRAWER, GRAY, W/DIVIDERS |
|
|
BEARING, PAD, GEAR |
|
|
BIN ASSEMBLY |
|
|
BIN ASSEMBLY, FLEX, DOOR, DAIRY |
|
|
BIN, FIXED, DOOR BOTTOM |
|
|
BIN, FIXED, LH DOOR |
|
|
BIN, FIXED, SMALL, DOOR, ICE CHUTE |
|
|
BIN, FLEX, 1/3 WIDTH, DOOR |
|
|
BIN, FLEX, 2/3 WIDTH, DOOR |
|
|
BLADE, EVAPORATOR FAN |
|
|
BRACKET, CANTILEVER SHLF, GREY, CENTER |
|
|
BRACKET, CANTILEVER SHLF, GREY, LH |
|
|
BRACKET, CANTILEVER SHLF, GREY, RH |
|
|
BRACKET, FAN MOUNTING, FF EVAPORATOR |
|
|
BRACKET, ICE MAKER, FREEZER |
|
|
BRACKET, LEVELING FOOT, LH |
|
|
BRACKET, LEVELING FOOT, RH |
|
|
BRACKET, REINFORCEMENT |
|
|
BUCKET ASSEMBLY, ICE CONTAINER, W/MOVING PARTS |
|
|
BUMPER, DOOR, BOTTOM |
|
|
CLAMP, CABLE, 1/4" |
|
|
CLAMP, COMPRESSOR |
|
|
CLAMP, COMPRESSOR, SINGLE HOLE |
|
|
CLAMP, FLEX DRIVE, CABLE |
|
|
CLAMP, NTC, EVAPORATOR |
|
|
CLAMP, TUBE/WIRING, 1/2", NYLON, BLACK/NATURAL |
|
|
CLAMP, TUBE/WIRING, 5/16" |
|
|
CLIP, HARNESS |
|
|
CLIP, HEATER/TUBING |
|
|
CLIP, RETAINER |
|
|
CLIP, TUBE, REAR |
|
|
CLIP, TUBING, 90 DEG ELBOW |
|
|
COMPRESSOR, ASSEMBLY, VND1113Y |
|
|
CONDENSER, ASSEMBLY, DYNAMIC |
|
|
CONNECTOR, HARNESS, EVAP COVER |
|
|
CONNECTOR, TUBING, QUICK CONNECT |
|
|
CONTAINER, DRAWER ICE, FREEZER |
|
|
CONTROL ASSEMBLY, FLEX DRIVE |
|
|
CONTROL ASSEMBLY, USER INTERFACE, GRAY, DOOR SIDE |
|
|
COVER |
|
|
COVER |
|
|
COVER |
|
|
COVER |
|
|
COVER ASSEMBLY |
|
|
COVER ASSEMBLY, AIR DUCT, FRESH FOOD, COMPLETE |
|
|
COVER ASSEMBLY, AIR DUCT, FRESH FOOD, COMPLETE |
|
|
COVER ASSEMBLY, AIR FLOW, MIDDLE DRAWER, W/FAN-HEATER |
|
|
COVER ASSEMBLY, EVAPORATOR, FREEZER, W/FAN ASSY |
|
|
COVER, AIR DUCT, STAINLESS, FRESH FOOD, W/GASKETS |
|
|
COVER, AIR FILTER, FRESH FOOD |
|
|
COVER, ASSEMBLY, PCB BOX |
|
|
COVER, DISP HOUSING, CHROME |
|
|
COVER, DIVIDER, GRAY, TOP |
|
|
COVER, EVAPORATOR, GRAY, FRESH FOOD |
|
|
COVER, FLEX DRIVE, SIDE, COMPRESSOR |
|
|
COVER, HARNESS, FF ICE MAKER |
|
|
COVER, ICE BLOCKER |
|
|
COVER, INLET TUBE, REAR |
|
|
COVER, MACHINE COMPT., REAR |
|
|
COVER, MULLION STORAGE, GLASS, LH |
|
|
COVER, MULLION STORAGE, GLASS, RH |
|
|
COVER, REED SWITCH, GRAY |
|
|
COVER, SCREW HOLE, WHITE |
|
|
COVER, SCREW, GRAY, SMALL |
|
|
COVER, WATER TANK |
|
|
COVER, WINDOW, GRAY, FRESH FOOD |
|
|
COVER, WINDOW, MIDDLE DRAWER |
|
|
CUSHION, RUBBER, FREEZER DRW |
|
|
DISPENSER ASSEMBLY |
|
|
DISPLAY ASSEMBLY, COMPLETE, GRAY, W/BOARD-OVERLAY |
|
|
DIVIDER, CRISPER COVER, GRAY |
|
|
DOOR ASMY |
|
|
DOOR ASSEMBLY |
|
|
DOOR ASSEMBLY |
|
|
DOOR ASSEMBLY, OUTER, STAINLESS, MIDDLE DRAWER |
|
|
DRAIN PAN, CONDENSER |
|
|
DRAIN TROUGH, EVAPORATOR, FREEZER |
|
|
DRAIN TROUGH, EVAPORATOR, FRESH FOOD |
|
|
DRAIN TUBE, CORRUGATED |
|
|
DRAWER ASSEMBLY, CRISPER, LH, W/ROLLERS |
|
|
DRAWER ASSEMBLY, CRISPER, RH, W/ROLLERS |
|
|
DRAWER ASSEMBLY, FREEZER, GRAY, W/ICE CONTAINER |
|
|
DRAWER ASSEMBLY,FREEZER,W/ROLL |
|
|
DUCT ASSEMBLY, AIR FLOW, MIDDLE DRAWER |
|
|
DUCT, ICE MAKER FAN |
|
|
EVAPORATOR ASSEMBLY, COMPLETE, ICE MAKER |
|
|
EVAPORATOR ASSEMBLY, ICE MAKER, COMPLETE |
|
|
EVAPORATOR, ASSEMBLY, FREEZER |
|
|
EVAPORATOR, ASSEMBLY, FRESH FOOD |
|
|
FAN ASSEMBLY, CONDENSER |
|
|
FAN ASSEMBLY, EVAPORATOR, FRESH FOOD |
|
|
FAN ASSEMBLY, MIDDLE DRAWER, W/SLEEVE |
|
|
FLAP BRACKET, COMPRESSOR BASE |
|
|
FOOT, LEVELING, STABILIZER |
|
|
FREEZER ICEMAKER KIT |
|
|
GASKET, AIR HANDLER, FRONT |
|
|
GASKET, CRISPER COVER |
|
|
GASKET, DOOR, 103MM, GRAY, SECONDARY |
|
|
GASKET, DOOR, 162MM, GRAY, SECONDARY |
|
|
GASKET, DOOR, GRAY, FREEZER |
|
|
GASKET, DOOR, GRAY, LH FRESH FOOD |
|
|
GASKET, DOOR, GRAY, MIDDLE |
|
|
GASKET, DOOR, GRAY, RH FRESH FOOD |
|
|
GEAR, PINION |
|
|
GROMMET, COMPRESSOR |
|
|
GROMMET, FAN |
|
|
GROMMET, FAN MOUNTING |
|
|
GROMMET, FAN SHROUND, FREEZER |
|
|
GUIDE ASSEMBLY, FLIP MULLION, GRAY, BASE |
|
|
GUIDE, FILTER MANIFOLD |
|
|
GUIDE, WATER TUBE, DISPENSER |
|
|
HANDLE, DOOR, STAINLESS, FRESH FOOD |
|
|
HARNESS, WIRING, AIR HANDLER |
|
|
HARNESS, WIRING, EYEBROW |
|
|
HARNESS, WIRING, MIDDLE DRAWER |
|
|
HARNESS, WIRING, POWER SUPPLY |
|
|
HEATER ASSEMBLY, MIDDLE DRAWER |
|
|
HEATER DEFROST, EVAPORATOR |
|
|
HEATER, FLIP MULLION |
|
|
HINGE, CENTER, LH |
|
|
HINGE, FLIP MULLION, GRAY |
|
|
HINGE, MIDDLE, RH |
|
|
HINGE, TOP, LH |
|
|
HINGE, TOP, RH |
|
|
HOLDER, WATER FILTER |
|
|
HOUSING ASSEMBLY, AUTO HUMIDITY, W/MEMBRANE |
|
|
HOUSING ASSEMBLY, ICE MAKER, GRAY, W/GASKETS |
|
|
HOUSING KIT, 2 CONNECTOR |
|
|
HOUSING, AIR HANDLER |
|
|
HOUSING, FAN, FRESH FOOD |
|
|
ICE MAKER, COMPLETE, 115 V, TWIST |
|
|
INSULATION, WATER TANK |
|
|
INSULATION, WINDOW, EPS, FRESH FOOD |
|
|
LENS, LED LIGHT |
|
|
LENS, LED LIGHT |
|
|
LENS, LED LIGHT, DOUBLE |
|
|
LENS, LED LIGHT, RH SIDE, LONG |
|
|
LH DOOR CLOSER W/O INNER WASHR |
|
|
LIGHT BOARD, 3 LED CLUSTER, 6500K |
|
|
MAGNET, REED SWITCH |
|
|
MANIFOLD, WATER FILTER, W/WATER LINE, TO MAIN VALVE |
|
|
MOTOR, AUGER |
|
|
MOTOR, FAN, FRZ EVAPORATOR |
|
|
MOTOR, FAN, ICE MAKER |
|
|
MULLION ASSEMBLY, FLIP, GRAY, W/HEATER |
|
|
OVERLAY |
|
|
PADDLE ASSEMBLY, DISPENSER, STAINLESS |
|
|
PC BOARD, AC LINE FILTER, EMC |
|
|
PC BOARD, AMBIENT, & HUMIDITY |
|
|
PC BOARD, CONTROL, MAIN |
|
|
PC BOARD, DISPLAY, LH DOOR |
|
|
PC BOARD, POWER SUPPLY |
|
|
PIN, ANTI TWIST, BUCKET |
|
|
PIN, INTERLOCK, GRAY, FLIP UP SHELF |
|
|
POWER CORD, ELECTRIC |
|
|
RAIL, CRISPER, GRAY, LH SIDE |
|
|
RAIL, CRISPER, GRAY, RH SIDE |
|
|
REED SWITCH HARNESS, ASSEMBLY |
|
|
RH DOOR CLOSER W/O INNER WASHR |
|
|
ROLLER, CABINET |
|
|
ROLLER, CRISPER GLIDE, GRAY |
|
|
SCREW, FLANGE PNHD PHL, 8G X 1/2" |
|
|
SCREW, HANDLE MOUNTING |
|
|
SCREW, HILO PHIL PN, 8-18 X 3/8 |
|
|
SCREW, M3.5 X 6 |
|
|
SCREW, PAN HEAD, 8-32 X 0.250 |
|
|
SCREW, PHIL PN HD, M4 X 8 |
|
|
SCREW, QUAD HILO, #8-18 X 0.380 |
|
|
SCREW, SELF TAPPING, M5 X 0.8 |
|
|
SCREW, SELF-TAPPING, 6 X 20 |
|
|
SCREW, SET, 10-32, HANDLE |
|
|
SCREW, TRILOB, M3 X 10 |
|
|
SCREW, TRILOB, M3 X 6 |
|
|
SCREW, TRILOB, M4 X 12 |
|
|
SCREW, TRILOB, M5 X 16 |
|
|
SCREW, TRILOBULAR, M4 X 12 |
|
|
SCREW, TRUSS, 4.2 X 13 |
|
|
SCREW, VT AF/2P, 5 X 16 |
|
|
SCREW,CONTROL MTG. |
|
|
SCREW-#8-32 X 3/8 |
|
|
SEAL, 6X20X450, FOAM |
|
|
SEAL, 6X8, FOAM TAPE, 154" ROLL |
|
|
SEAL, BAFFLE ASSEMBLY |
|
|
SHAFT, CABINET ROLLER |
|
|
SHAFT, SLIDER, TELESCOPIC |
|
|
SHELF ASSEMBLY, CANTILEVER, GLASS, GRAY, LH |
|
|
SHELF ASSEMBLY, CANTILEVER, GLASS, GRAY, RH |
|
|
SHELF ASSEMBLY, CANTILEVER, GLASS, GRAY, UPPER, SLIDE UNDER |
|
|
SHELF ASSEMBLY, FLIP UP, GLASS, GRAY, LH |
|
|
SHIELD, EYEBROW |
|
|
SHROUD, CONDENSER FAN |
|
|
SHROUD, FAN, FREEZER |
|
|
SLIDER, ASSEMBLY, GRAY, LH FREEZER |
|
|
SLIDER, ASSEMBLY, GRAY, LH MIDDLE DRW |
|
|
SLIDER, ASSEMBLY, GRAY, RH FREEZER |
|
|
SLIDER, ASSEMBLY, GRAY, RH MIDDLE DRW |
|
|
SOLENOID, ASSEMBLY |
|
|
SPRING, PADDLE ASSEMBLY |
|
|
SPRING, TUBE PROTECTION |
|
|
STEP VALVE, ASSEMBLY, W/FILTER DRIER |
|
|
STICKER, PLASTIC CAP, GRAY |
|
|
STICKER, PLASTIC CAP, WHITE |
|
|
STOP, ASSEMBLY, LH DOOR |
|
|
STOP, ASSEMBLY, RH DOOR |
|
|
SUMP ASSEMBLY, STAINLESS |
|
|
SUPPORT, DRAWER SLIDER, GRAY, LH FREEZER |
|
|
SUPPORT, DRAWER SLIDER, GRAY, LH MIDDLE |
|
|
SUPPORT, DRAWER SLIDER, GRAY, RH FREEZER |
|
|
SUPPORT, DRAWER SLIDER, GRAY, RH MIDDLE |
|
|
SUPPORT, MAGNET, GRAY |
|
|
SUPPORT, WATER VALVE, & TANK |
|
|
SWITCH, DISP PADDLE |
|
|
SWITCH, LIGHT, GRAY |
|
|
TANK, WATER, DISP RESERVOIR |
|
|
TAPE, 3" X 1", FOIL |
|
|
THERMISTOR KIT, TEMPERATURE, NTC, W/CONNECTORS |
|
|
THERMISTOR KIT, TEMPERATURE, W/HOUSING |
|
|
THERMOSTAT KIT, DEFROST, W/CONNECTORS |
|
|
TUBE ASSEMBLY, INLET, W/CONNECTOR |
|
|
TUBE, SUCTION |
|
|
TUBE, VALVE, TO FRESH FOOD, ICE MAKER, IM 45 CUT |
|
|
TUBING, EXTRA, REFRIGERANT |
|
|
TUBING, VALVE, TO DOOR HINGE |
|
|
TUBING, VALVE, TO FZ ICE MAKER |
|
|
VALVE, WATER, SINGLE |
|
|
WASHER, FAN GROMMET |
|
|
WASHER, FLAT |
|
|
WASHER, SLINGER, NYLON |
|
|
WATER FILTER,ELUX PA ULTRA |
|
|
WATER VALVE, ASSEMBLY, TRIPLE |
