Model Image
Manufacturer

Electrolux

Model Number

FAL123H1A3

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
5303301247 5303301247 ACCORDIAN (2)
5303211056 5303211056 BRACKET
5303316595 5303316595 CAPACITOR
5308017120 5308017120 CAPILLARY TUBE,CUT TO LENGTH
5303012110 5303012110 CLAMP
309100401 309100401 CLIP
316080011 316080011 CLOCK/TIMER,SLEW
5303307470 5303307470 CONDENSER
5303316618 5303316618 CORD-ELECTRIC POWER
309605902 309605902 COVER
309330201 309330201 DETENT
309328602 309328602 DOOR
5300265301 5300265301 DRIER-FILTER,SERVICE KIT
309606101 309606101 EVAPORATOR
309609502 309609502 FILTER-AIR
5303002035 5303002035 GASKET
5303283877 5303283877 GROMMET
309605702 309605702 HOUSING
309307006 309307006 KNOB-CONTROL(2005;W/7005)
309630602 309630602 MOTOR,FAN ,115 V
3007759 3007759 NUT
5308006948 5308006948 NUT
5303307245 5303307245 OVERLOAD PROTECTOR
309605802 309605802 PLATE
5304415076 5304415076 RAIL
5303301250 5303301250 RETAINER
5303281649 5303281649 SCREW
3007756 3007756 SCREW
3002801 3002801 SCREW
5303007754 5303007754 SCREW
5303015427 5303015427 SCREW
5304410881 5304410881 SCREW-FRONT PANEL
3002803 3002803 SCREW-WOOD
5304407729 5304407729 SEAL
5303276728 5303276728 SEAL
5303207200 5303207200 SEAL
3202953 3202953 SEAL
3202951 3202951 SEAL
5314949603 5314949603 SEAL
5303002600 5303002600 SLEEVE
5303001775 5303001775 SPACER
5303002036 5303002036 SPRING
5303317601 5303317601 START KIT
309313204 309313204 SUPPORT
5303301254 5303301254 SUPPORT
3001815 3001815 SUPPORT
5304408360 5304408360 SWITCH-SELECTOR
309606001 309606001 TRAY-EVAPORATOR
5303295516 5303295516 WASHER
309112501 309112501 WASHER
