Model Image
Manufacturer

Electrolux

Model Number

FEB798CCBF

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
5303310511 5303310511 BAR
318145002 318145002 BASE
5303311203 5303311203 BLADE
318022001 318022001 BOARD-RELAY (NOT ILLUSTRATED)
318022002 318022002 BOARD-RELAY,TRANSFORMER
318015110 318015110 BRACKET
318039511 318039511 BRACKET
5303317198 5303317198 BRACKET
3016303 3016303 CLIP
318010501 318010501 CLOCK/TIMER,EOC
5303310526 5303310526 COVER
5303318711 5303318711 COVER
318406100 318406100 COVER, GLASS LITE
5303317197 5303317197 DUCT
3201150 3201150 END CAP-SHELF,PROTECTOR ,FRZR SHELF
318056104 318056104 FRONT
318042300 318042300 GLASS
318024744 318024744 HINGE
5303297484 5303297484 INDICATOR LIGHT
5303311218 5303311218 INSULATION
318065100 318065100 LATCH-DOOR
5303311202 5303311202 MOTOR,CONVECTION
318070600 318070600 PANEL
318070601 318070601 PANEL
318030015 318030015 PANEL-CONTROL
5303320846 5303320846 PLATE
318080000 318080000 PLATE
3202113 3202113 PLUG
318328010 318328010 RECEPTACLE,HINGE
5303311222 5303311222 ROD
5303307406 5303307406 SCREW
5303311528 5303311528 SCREW
5303211311 5303211311 SCREW
5303323130 5303323130 SCREW
5303320422 5303320422 SCREW
5303307980 5303307980 SCREW
5303308456 5303308456 SCREW
5303311217 5303311217 SCREW
5303300265 5303300265 SCREW,8-18 X 0.500 ,CHROME ,(3)
318293502 318293502 SEAL
318053100 318053100 SEAL
5303304699 5303304699 SHIELD
5303300414 5303300414 SPACER
318014300 318014300 SPACER
318042000 318042000 SPACER
5303210003 5303210003 SPACER-HANDLE MTG
5303311164 5303311164 SPRING
5303302286 5303302286 SUPPORT
5303302287 5303302287 SUPPORT
5303317199 5303317199 SUPPORT
318284201 318284201 SUPPORT
5303307563 5303307563 SUPPORT-ELEMENT
318005200 318005200 SWITCH
5303275924 5303275924 SWITCH-DOOR
318004900 318004900 SWITCH-THERMAL, UPPER
318028700 318028700 TRIM,BASE ,BLACK
318072545 318072545 TUBE
5303304015 5303304015 WASHER
