Model Image
Manufacturer

Electrolux

Model Number

FFH1767GWZ

Description

Freezer

Interactive Exploded View
Exploded View

Parts List

Part Number Description
218676001 218676001 BAND-DECORATIVE
216211700 216211700 BASKET
216974500 216974500 BEARING
216970800 216970800 BEARING
216974600 216974600 BEARING
216394050 216394050 BRACKET
216603300 216603300 BREAKER KIT W/CORNE
216604200 216604200 BREAKER KIT W/CORNE
5305878546 5305878546 BUMPER-BASKET
218909912 218909912 CAPACITOR
241544101 241544101 CLAMP
297048400 297048400 CLIP
5304406520 5304406520 CLIP
5303212828 5303212828 CLIP
5300083897 5300083897 CONDENSER
216954212 216954212 CONTROLLER
297098802 297098802 COVER-EVAPORATOR
216974400 216974400 DOOR STOP
5308005500 5308005500 DRAIN
216204900 216204900 GASKET
216522309 216522309 GASKET-DOOR
297036900 297036900 GRILLE/KICKPLATE
216502400 216502400 GROMMET-SHELF MTG
297016600 297016600 HARNESSMAIN
216783200 216783200 HEAT EXCHANGER
216730700 216730700 HEATER-DEFROST
216978201 216978201 HINGE
216939100 216939100 HINGE-UPPER
297001704 297001704 INSULATION
297078800 297078800 INSULATOR-EVAP
297078700 297078700 INSULATOR-EVAP
216846400 216846400 LIGHT BULB/LAMP
216947300 216947300 NAMEPLATE
216994101 216994101 PAN-DRAIN
216527813 216527813 PANEL-INNER DOOR
216661600 216661600 PLATE
240494001 240494001 PLUG
297014702 297014702 PLUG-SUCTION LINE
216403700 216403700 PLUGBUTTON
216951600 216951600 RACK-DOOR
216503100 216503100 SCREENDRAIN
5304460607 5304460607 SCREW
08005520 08005520 SCREW
216629601 216629601 SCREW
216912401 216912401 SCREW
216036601 216036601 SCREW
216396900 216396900 SCREW-LEG
216816223 216816223 SHIELDLIGHT
216502500 216502500 SLEEVE
5306594529 5306594529 SLEEVE-COMPRESSOR
297102800 297102800 SPACER-TUBE
216486500 216486500 STOP-BASKET
5308000110 5308000110 STRAP-EVAP/HEATER
215870619 215870619 TRIM-HANDLE
297263717 297263717 USE 297263717
5309950074 5309950074 VALVE
