Model Image
Manufacturer

Electrolux

Model Number

FFHT1513LWA

Description

Refrigerator

Interactive Exploded View
Exploded View

Parts List

Part Number Description
241665605 241665605 BASECOMPRESSOR
240527101 240527101 BEARING-HINGE
241639501 241639501 BLADE
240357006 240357006 BRACKET-CTR HINGE
5303292397 5303292397 BRACKET-MOTOR MTG
5303292396 5303292396 BRACKET-MOTOR MTG
240357106 240357106 BRACKETLOWER HINGE
240356903 240356903 BRACKETUPPER HINGE
241555401 241555401 BULB-LAMP
297286803 297286803 CAPACITORRUN
218931001 218931001 CLAMP-MOTOR WIRING
240396801 240396801 CLAMP-TUBE
5304456288 5304456288 CLAMP-WIRING HARNES
297030500 297030500 CLIP
218515401 218515401 CLIP
240542601 240542601 CLIP-WIRING HARNESS
242037701 242037701 CLIPCOMPRESSOR MTG
240550937 240550937 COMPRESSOR
241785404 241785404 CONDENSER
241613501 241613501 CONTROL-HUMIDITY
241613502 241613502 CONTROL-HUMIDITY
241733906 241733906 COVER ACCESS
241652215 241652215 COVER-EVAP COIL
240354401 240354401 COVER-UPPER HINGE
242120508 242120508 COVERCRISPER PAN
241523701 241523701 DAMPER-FAN COVER
241542001 241542001 DEFLECTOR
240362601 240362601 DIFFUSER
240415401 240415401 DOOR
240415501 240415501 DOOR
240535101 240535101 DOOR RACK FOR REFRIGERATOR
240312403 240312403 DOOR STOP
240312414 240312414 DOOR STOP
240337701 240337701 DOOR-DAIRY
242028519 242028519 ENERGY GUIDE
5308000010 5308000010 FAN BLADE
240368301 240368301 GRILLE/KICKPLATE
240405201 240405201 GROMMET
5304500407 5304500407 GROMMET
218513300 218513300 GROMMET-COMPR MTG
218428101 218428101 HANDLE-DOOR
242019701 242019701 HARNESSWIRING
5303918263 5303918263 HEAT EXCHANGER KIT
242044019 242044019 HEATERDEFROST
5303918222 5303918222 HOT TUBE REPAIR KIT
241551902 241551902 INSULATION BLOCK
240360801 240360801 KNOB
240367001 240367001 KNOB-DAMPER CONTROL
242062801 242062801 NAMEPLATE
240364501 240364501 PAN
240516502 240516502 PIN-LOWER HINGE
240494001 240494001 PLUG-BUTTON
240381301 240381301 PLUG-BUTTON
215774901 215774901 PLUG-BUTTON
241586701 241586701 PLUG-FOAM-WTR-INLET
5303208309 5303208309 PLUG-HOLE
240374401 240374401 PLUG-WTR INLET TUBE
242193602 242193602 PLUGHOLE
240535301 240535301 RACK-DOOR
240535001 240535001 RACK-DOOR
240535201 240535201 RACK-DOOR
5304455655 5304455655 RIVET
5304418225 5304418225 ROLLER
241889002 241889002 ROLLER ASSEMBLY
5304455649 5304455649 SCREW
5304455650 5304455650 SCREW
215503203 215503203 SCREW
240521303 240521303 SCREW
240383406 240383406 SCREW
218252201 218252201 SCREW
241500302 241500302 SCREW
241710601 241710601 SCREW
240433204 240433204 SCREW
241500304 241500304 SCREW
240569202 240569202 SCREW
5304456287 5304456287 SCREW,HEX WASHER HEAD,8-15A X
240442706 240442706 SCREW-#10-32 X 3/4
240359403 240359403 SCREW-FAN SHROUD
240578902 240578902 SCREW-HINGE MTG
5303282284 5303282284 SHELF-FREEZER
242050601 242050601 SHROUD
241559801 241559801 SOCKET-LIGHT
240409302 240409302 SPACER-COND TUBE
240336802 240336802 SPACER-HINGE
241941005 241941005 STARTER
5308000110 5308000110 STRAP-EVAP/HEATER
241554901 241554901 SWITCH-LIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
242161201 242161201 TRIMCABINET CORNER
241801302 241801302 TROUGHDRAIN
240500801 240500801 TUBE-DRAIN
241871503 241871503 TUBECONNECTOR
240311303 240311303 WASHER
215474201 215474201 WASHER
241812301 241812301 WASHERCOMPR MTG
5303321319 5303321319 WHITE TOUCHUP PAINT
242099701 242099701 WIRING HARNESS
240388701 240388701 WIRING HARNESS
