Model Image
Manufacturer

Electrolux

Model Number

FFSC2323LP8

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
241676101 241676101 ACTUATORSOLENOID
241726501 241726501 BAR-DRIVE
241513202 241513202 BASE
240330012 240330012 BASECOMPRESSOR
242009602 242009602 BASEWATER FILTER
241515001 241515001 BASKET-SLIDING
241760401 241760401 BEARING
241760403 241760403 BEARING
241990301 241990301 BEARING-HINGE
241990302 241990302 BEARINGHINGE(FRZ)
241511601 241511601 BIN-DOOR
241505506 241505506 BIN-DOOR
241511706 241511706 BIN-DOOR
241639502 241639502 BLADE
241684107 241684107 BLADE
241684102 241684102 BLADE
241684103 241684103 BLADE
218679614 218679614 BLOCKEVAP COIL
240335006 240335006 BOLT-ROLLER ADJ
241684602 241684602 BRACKET-CONTROL ROD
218990801 218990801 BRACKET-EVAP/CVR MT
5304458374 5304458374 BRACKETICE MAKER
241761301 241761301 BRACKETUPPER HINGE
316538904 316538904 BULB-LAMP
241518301 241518301 BUSHING
241685201 241685201 CAM-DRIVE
297286803 297286803 CAPACITORRUN
241532401 241532401 CHANNEL
241674401 241674401 CHANNEL
241674402 241674402 CHANNEL
241812502 241812502 CHANNEL
241513001 241513001 CHANNEL-SHELF MTG
5304455846 5304455846 CLAMP
241650901 241650901 CLAMP
5304458398 5304458398 CLIP
242135301 242135301 CLIP
241852501 241852501 CLIP
241595202 241595202 CLIP
240362101 240362101 CLIP
241716801 241716801 CLIP
241519401 241519401 CLIP
216649200 216649200 CLIP GE CONTROLLER
218515403 218515403 CLIPGRILLE
242036801 242036801 CLIPPLASTIC
5304458401 5304458401 CLIPRETAINER
241515801 241515801 COMPARTMENT
241982802 241982802 COMPRESSOR
5304458399 5304458399 CONDUCTOR-HEAT
241515202 241515202 CONTAINER-ICE
241973711 241973711 CONTROL
241684402 241684402 CONTROL ROD
240362201 240362201 CONTROL-HUMIDITY
241516901 241516901 CORD-SERVICE
241733902 241733902 COVER
240599301 240599301 COVER
240326304 240326304 COVER
241515301 241515301 COVER
240350903 240350903 COVER-CRISPER PAN
241675502 241675502 COVER-MOTOR
241509804 241509804 COVERAIR DUCT
241719711 241719711 COVEREVAP COIL
5304458376 5304458376 COVERICE MAKER
240599803 240599803 COVERMEAT PAN
241946806 241946806 COVERMODULE
241946701 241946701 COVERUPPER HINGE
241946702 241946702 COVERUPPER HINGE
240351207 240351207 CRISPER PAN
5304458378 5304458378 CUPWATER INLET
241853801 241853801 DAMPER ASSEMBLY
241583301 241583301 DEFLECTOR-AIR
241890601 241890601 DEFLECTORAIR
241755401 241755401 DIFFUSERAIR
241515601 241515601 DOOR-CHEESE BUTTER
241993804 241993804 DOORFRZR
241837279 241837279 DOORREFR
5303305677 5303305677 DRIER-FILTER
241947001 241947001 DRIP TRAY
241684501 241684501 DRIVE BLADE
241690201 241690201 E-RING
5304458377 5304458377 EJECTORICE
241615481 241615481 ENERGY GUIDE
5303918284 5303918284 EVAPORATOR KIT
241509402 241509402 EVAPORATOR MOTOR
241720601 241720601 EXTENSION
5308000010 5308000010 FAN BLADE
241684203 241684203 FIXED BLADE
241684301 241684301 FIXED BLADE
241510202 241510202 GASKET-FRZR DOOR
241510201 241510201 GASKET-REFR DOOR
5304458380 5304458380 GEAR
241969401 241969401 GRILLE/KICKPLATE
240405201 240405201 GROMMET
218513300 218513300 GROMMET-COMPR MTG
241550701 241550701 GROMMET-SHELF MTG
241550801 241550801 GROMMET-SHELF MTG
241675601 241675601 GUIDE-SOLENOID
241514501 241514501 HANGER-BASKET
241514601 241514601 HANGER-BASKET
241522901 241522901 HARNESS-ELECTRICAL
241519902 241519902 HARNESSELECTRICAL
5304458379 5304458379 HARNESSWIRING
241987601 241987601 HARNESSWIRING
241891901 241891901 HARNESSWIRING
241834703 241834703 HARNESSWIRING
241835801 241835801 HARNESSWIRING
242141102 242141102 HARNESSWIRING MACH
5303918327 5303918327 HEAT EXCHANGER KIT
242044113 242044113 HEATER-DEFROST
5304458395 5304458395 HOUSING
241983804 241983804 HOUSING
241861301 241861301 HOUSINGDAMPER
241753701 241753701 HOUSINGLIGHT
241845401 241845401 HOUSINGSENSOR
241914702 241914702 ICE CONTAINER ASSEMBLY
5304458390 5304458390 ICE STRIPPER
240350649 240350649 INSERT-GLASS
240350603 240350603 INSERT-PAN COVER
240443391 240443391 INSERTPAN COVER
241755501 241755501 INSULATIONAIR DUCT
5304458381 5304458381 INSULATOR
242125501 242125501 INSULATOR
240562101 240562101 INSULATOR
5304458391 5304458391 LEVER ARM
5304517886 5304517886 LIGHT BULB
241890604 241890604 LOUVER
241515901 241515901 LUG-DAIRY COMPARTME
242018304 242018304 MOTORCONDENSER FAN
5304458382 5304458382 MOTORICE MAKER SVO
241998302 241998302 MOUNTWATER FILTER
241685001 241685001 NUT-AUGER
241697501 241697501 PAN-DEFROST DRAIN
240351061 240351061 PANCRISPER
241974601 241974601 PANMEAT
241690402 241690402 PIN-SPIRAL
241684001 241684001 PLATE-FRONT
241504601 241504601 PLATE-MOUNTING
5304456681 5304456681 PLATE-VALVE SWITCH
241917801 241917801 PLATEDOOR CLOSER
5304458383 5304458383 PLATEMOUNTING
240494001 240494001 PLUG
5303208309 5303208309 PLUG-HOLE
5303918637 5303918637 POWER BOARD
241516101 241516101 RACK-CAN
241676501 241676501 RAIL ASSEMBLY
241504701 241504701 RAIL-ICE CREAM SHEL
241504702 241504702 RAIL-ICE CREAM SHEL
241622802 241622802 RECEPTACLE
5304458403 5304458403 RETAINER-THERMOSTAT
5304455655 5304455655 RIVET
5304418225 5304418225 ROLLER
241676301 241676301 ROTATION STOP
242125401 242125401 SCOOP CRISPER AIR S
5304456678 5304456678 SCREW
5304455651 5304455651 SCREW
5304458386 5304458386 SCREW
5304458389 5304458389 SCREW
5304458385 5304458385 SCREW
5304458384 5304458384 SCREW
5304456684 5304456684 SCREW
5304456676 5304456676 SCREW
5304456660 5304456660 SCREW
5304458394 5304458394 SCREW
5304458393 5304458393 SCREW
5304458387 5304458387 SCREW
5304455650 5304455650 SCREW
240451503 240451503 SCREW
241695904 241695904 SCREW
241548003 241548003 SCREW
218781101 218781101 SCREW
241500303 241500303 SCREW
241710601 241710601 SCREW
218252201 218252201 SCREW
218493101 218493101 SCREW
215503203 215503203 SCREW
241690501 241690501 SCREW
241690701 241690701 SCREW
241551602 241551602 SCREW
218359202 218359202 SCREW
215005101 215005101 SCREW
240442706 240442706 SCREW-#10-32 X 3/4
240363402 240363402 SCREW-#8-18 X 1/2
240555002 240555002 SCREW-#8-32 X 3/8
240491503 240491503 SCREW-COMPRESSOR MT
240359403 240359403 SCREW-FAN SHROUD
240578902 240578902 SCREW-HINGE MTG
218755402 218755402 SCREW-SET
218709101 218709101 SCREWHDL MTG
240363602 240363602 SCREWSHOULDER
218249808 218249808 SEALCOIL COVER
241781601 241781601 SEALRETURN AIR
240561702 240561702 SEALWATER INLET
240597203 240597203 SENSOR
241657505 241657505 SHELF-FREEZER
241657506 241657506 SHELF-FREEZER
241657605 241657605 SHELF-FREEZER
241691701 241691701 SHELF-ICE CREAM
240350160 240350160 SHELFSPILLSAFE
241753601 241753601 SHIELDLIGHT
242204501 242204501 SHROUD-EVAP FAN MTG
241946106 241946106 SHROUDCOND FAN
5304458375 5304458375 SHUT-OFF ARM
240349801 240349801 SLIDE CLIP
241861201 241861201 SLIDEDAMPER
241559801 241559801 SOCKET-LIGHT
241689801 241689801 SPACER
241684802 241684802 SPACER
240409302 240409302 SPACER-COND TUBE
241684901 241684901 SPACER-FIXED BLADES
5304458388 5304458388 SPACER-HOLD SWITCH
5304456682 5304456682 SPRING
5304459922 5304459922 SPRING,SHUT-OFF ARM
241731801 241731801 SPRINGCONTROL ROD
241675902 241675902 SPRINGVALVE
241707712 241707712 STARTER
241942603 241942603 STOPDOOR/FF BLACK
241942604 241942604 STOPDOOR/FRZR BLAC
5308000110 5308000110 STRAP-EVAP/HEATER
241993101 241993101 SUPPORTCRISPER CVR
241993001 241993001 SUPPORTCRISPER CVR
241911703 241911703 SWITCH
241547901 241547901 SWITCH-LIGHT/LAMP
5304456667 5304456667 SWITCH-MICRO
242167026 242167026 SWITCHMEMBRANE
240346701 240346701 TAPE-FOAM SEAL
240346703 240346703 TAPEFOAM
5304458400 5304458400 THERMAL CUTOFF
5304456665 5304456665 THERMOSTAT
241510605 241510605 TRIM-BASKET
240337608 240337608 TRIM-CABINET CORNER
240430709 240430709 TRIM-SHELF
240430710 240430710 TRIM-SHELF
218976409 218976409 TUBE
218976429 218976429 TUBE
242014601 242014601 TUBECONNECTOR
241856903 241856903 TUBECONNECTOR
218976421 218976421 TUBEWATER INLET
242252702 242252702 VALVE
5304456689 5304456689 WASHER
215474201 215474201 WASHER
241690306 241690306 WASHER
WF3CB WF3CB WATER FILTER
5303321319 5303321319 WHITE TOUCHUP PAINT
