Manufacturer
Electrolux
Model Number
FFTR1813VB0
Description
Top-mount Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACCESS COVER,REAR |
|
|
BAFFLE,DIVIDER ,HIGH SIDE |
|
|
BAFFLE,DRAIN PAN ,AIR BLOCK |
|
|
BASE ASSEMBLY,COMPRESSOR ,W/ROLLERS |
|
|
BEARING,HINGE ,BLACK |
|
|
BIN,DOOR ,4" ,WHITE ,REFRIGERATOR |
|
|
BIN,DOOR ,6" ,WHITE ,REFRIGERATOR |
|
|
BIN,DOOR ,WHITE ,FREEZER |
|
|
BULB,LIGHT ,E17/12 LED |
|
|
CAPACITOR,RUN ,10UF |
|
|
CLAMP |
|
|
CLIP,WIRE SHELF ,LH |
|
|
CLIP,WIRE SHELF ,RH |
|
|
CLIP,WIRING HARNESS |
|
|
COLD CONTROL,ASSEMBLY ,W/CAPILLARY |
|
|
COMPRESSOR,ASSEMBLY ,TH1114HY ,W/GROMMETS |
|
|
CONDENSER,DYNAMIC |
|
|
CONTROLLER,COMPRESSOR PTC |
|
|
COVER ASSEMBLY,CRISPER ,GLASS ,W/TRIM |
|
|
COVER ASSEMBLY,EVAPORATOR ,W/FRZ SLIDE |
|
|
COVER,ELECTRICALS ,COMPRESSOR |
|
|
COVER,HINGE ,BLACK ,LOWER ,NON HINGED |
|
|
COVER,HINGE BEARING ,BLACK |
|
|
COVER,HINGE SIDE ,BLACK ,LOWER |
|
|
COVER,I/M CONNECTOR |
|
|
COVER,UPPER HINGE ,GREY |
|
|
DIFFUSER,CONTROL BOX ,BOTTOM |
|
|
DIFFUSER,CONTROL BOX ,TOP |
|
|
DOOR ASSEMBLY,FREEZER ,TEXTURED ,BLACK |
|
|
DOOR ASSEMBLY,REFRIGERATOR ,TEXTURED ,BLACK |
|
|
EVAPORATOR,ASSEMBLY |
|
|
FAN ASSEMBLY,CONDENSER ,W/SHROUD-FOAM |
|
|
GASKET,DOOR ,BLACK ,FREEZER |
|
|
GASKET,DOOR ,BLACK ,FREEZER |
|
|
GROMMET |
|
|
HARNESS,WIRING ,CONTROL BOX |
|
|
HARNESS,WIRING ,MACHINE COMPT. |
|
|
HEATER,EVAP DEFROST ,W/THERMOSTAT |
|
|
HINGE ASSEMBLY,BOTTOM ,BLACK ,RH ,W/PIN-CLOSER |
|
|
HINGE ASSEMBLY,BOTTOM ,LH |
|
|
HINGE,DOOR ,BLACK ,CENTER |
|
|
HINGE,DOOR ,UPPER |
|
|
HOOK,DOOR CLOSER ,BLACK |
|
|
HOUSING,CONTROL BOX |
|
|
KNOB,CONTROL |
|
|
MOTOR,EVAPORATOR FAN ,BLOWER |
|
|
NAMEPLATE,BLACK |
|
|
PAN ASSEMBLY,CRISPER ,W/SLIDERS |
|
|
PAN,DRAIN |
|
|
PIN,CENTER HINGE ,DOOR |
|
|
PLATE,DIFFUSER |
|
|
REFRIGERATOR EVAPORATOR FAN BLADE |
|
|
REFRIGERATOR EVAPORATOR FAN MOTOR GROMMET, REAR |
|
|
REFRIGERATOR EVAPORATOR FAN SHAFT WASHER |
|
|
REFRIGERATOR SCREW |
|
|
REFRIGERATOR STRAP |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW,FLT HD QDRX ,M5 X 16 ,BLACK |
|
|
SCREW,HEX WSH HD QUAD ,M5 X 16 |
|
|
SCREW,HX WASH HD ,M4.2 X 12 |
|
|
SCREW,PAN HD QDRX TRI ,M5 X 12 ,BLACK |
|
|
SEAL,AIR DUCT ,TOP |
|
|
SEAL,FOAM ,AIR BLOCK |
|
|
SEAL,FOAM ,DRAIN PAN |
|
|
SHELF |
|
|
SHELF ASSEMBLY,FREEZER ,GLASS ,W/TRIM |
|
|
SHIELD,ELECTRICAL ,FRONT |
|
|
SHIELD,ELECTRICAL ,REAR |
|
|
SHROUD,EVAPORATOR FAN |
|
|
SOCKET,LED LIGHT |
|
|
SUPPORT,EVAPORATOR ,LH |
|
|
SUPPORT,EVAPORATOR ,RH |
|
|
SWITCH,DOOR |
|
|
TIMER,DEFROST |
|
|
TROUGH,EVAP DRAIN |
|
|
TUBE,DRAIN EXTENSION |
|
|
TUBE,SUCTION JUMPER |
|
|
TUBING,CAPILLARY ,PLASTIC |
|
|
WIRING CLAMP |
