Model Image
Manufacturer

Electrolux

Model Number

FFTR1821QW3

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
240527101 240527101 BEARING-HINGE
242238301 242238301 BLOCK,EVAPORATOR,LH
242238401 242238401 BLOCK,EVAPORATOR,RH
240313802 240313802 BRACKET-CTR HINGE
241555401 241555401 BULB-LAMP
297286803 297286803 CAPACITORRUN
240396801 240396801 CLAMP-TUBE
5304456288 5304456288 CLAMP-WIRING HARNES
218515401 218515401 CLIP
5304497418 5304497418 CLIP,CONTROLLER
218990901 218990901 CLIP-WIRE
240542601 240542601 CLIP-WIRING HARNESS
242037701 242037701 CLIPCOMPRESSOR MTG
241613502 241613502 CONTROL-HUMIDITY
241613501 241613501 CONTROL-HUMIDITY
297259528 297259528 CONTROLLER
242249201 242249201 COVER,CONNECTION,ICE MAKER
241733911 241733911 COVER-ACCESS,W/LABEL
240354401 240354401 COVER-UPPER HINGE
240364787 240364787 COVERCRISPER PAN
242213901 242213901 DEFLECTOR
240312414 240312414 DOOR STOP
240312403 240312403 DOOR STOP
240337712 240337712 DOOR-DAIRY
240410201 240410201 DOOR-FRZR
240410301 240410301 DOOR-REFR
242190201 242190201 DRYER-FILTER,W/PROCESS TUBE
5303918274 5303918274 EVAPORATOR KIT
242219302 242219302 FAN BLADE,EVAPORATOR
240372410 240372410 FRAME
240372409 240372409 FRAME
242240602 242240602 GASKET,AIR DIFFUSER
242193203 242193203 GASKET-FRZR DOOR,WHITE,MAGNETI
242193206 242193206 GASKET-FRZR DOOR,WHITE,MAGNETI
240350620 240350620 GLASS-SHELF
241839405 241839405 GRILLE/KICKPLATE
240405201 240405201 GROMMET
242237301 242237301 GROMMET,EVAPORATOR FAN,FRONT
242287501 242287501 GROMMET,EVAPORATOR FAN,REAR
218513300 218513300 GROMMET-COMPR MTG
240530601 240530601 HANGER
242019701 242019701 HARNESSWIRING
5303918263 5303918263 HEAT EXCHANGER KIT
242044020 242044020 HEATERDEFROST
5303918222 5303918222 HOT TUBE REPAIR KIT
240350608 240350608 INSERT-PAN COVER
242217001 242217001 KNOB,COLD CONTROL
240337103 240337103 PAN-CRISPER
240530811 240530811 PAN-MEAT
241920605 241920605 PANDEFROST
240516502 240516502 PIN-LOWER HINGE
215774901 215774901 PLUG-BUTTON
240494001 240494001 PLUG-BUTTON
240381301 240381301 PLUG-BUTTON
241586701 241586701 PLUG-FOAM-WTR-INLET
240534801 240534801 RACK-DOOR
240534701 240534701 RACK-DOOR
240534901 240534901 REFRIG DOOR SHELF RACK BAR
5304497413 5304497413 RING,LOCKING,(2)
5304455655 5304455655 RIVET
5304418225 5304418225 ROLLER
241889002 241889002 ROLLER ASSEMBLY
241665606 241665606 S/APUR COMPR BASE
240569202 240569202 SCREW
215005101 215005101 SCREW
241500304 241500304 SCREW
240433204 240433204 SCREW
241710601 241710601 SCREW
218252201 218252201 SCREW
240383406 240383406 SCREW
240521303 240521303 SCREW
215503203 215503203 SCREW
241953901 241953901 SCREW
5304455650 5304455650 SCREW
240442708 240442708 SCREW#1032 X 3/4
240578904 240578904 SCREW,HEX HEAD,1/4-20 X 5/8
240359403 240359403 SCREW-FAN SHROUD
240597203 240597203 SENSOR
240358008 240358008 SHELF,FREEZER,FULL-WIDTH,WIRE
242320401 242320401 SHIELD
5304498462 5304498462 SHIELD,HEAT
242229301 242229301 SHROUD BRACKET,EVAPORATOR FAN
240336802 240336802 SPACER-HINGE
241705801 241705801 SPACERSHELF
5308000110 5308000110 STRAP-EVAP/HEATER
240530701 240530701 SUPPORT
241554901 241554901 SWITCH-LIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
5303918645 5303918645 THERMISTOR KIT,EVAPORATOR,W/CO
5303918638 5303918638 THERMOSTAT,ASSEMBLY,SAFETY
240561502 240561502 TRIM-SHELF
240357704 240357704 TRIM-SHELF
242161201 242161201 TRIMCABINET CORNER
241801301 241801301 TROUGH-DRAIN
241856908 241856908 TUBE-CONNECTOR,SUCTION
240500801 240500801 TUBE-DRAIN
240311303 240311303 WASHER
241812301 241812301 WASHERCOMPR MTG
