Manufacturer
Electrolux
Model Number
FFTR1821TW1
Description
18 Cu. Ft. Top Freezer Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BASE-COMPRESSOR, W/ROLLERS |
|
|
BEARING-HINGE, NATURAL, (8) |
|
|
BLADE-CONDENSER FAN |
|
|
BLOCK, EVAPORATOR, LH |
|
|
BLOCK, EVAPORATOR, RH |
|
|
BRACKET-CTR HINGE, WHITE |
|
|
BRACKET-LOWER HINGE, WHITE |
|
|
BRACKET-UPPER HINGE |
|
|
CAPACITOR-RUN |
|
|
CLAMP, TUBE/WIRING, NYLON, BLACK/NATURAL |
|
|
CLAMP-WIRING HARNESS, STRAIN RELIEF, GALV STEEL |
|
|
CLIP, CONTROLLER |
|
|
CLIP-COMPRESSOR MTG |
|
|
CLIP-GRILLE |
|
|
CLIP-WIRE |
|
|
CLIP-WIRING HARNESS |
|
|
COMPRESSOR, W/O ELECTRICALS |
|
|
CONDENSER, HIGH EFFICIENCY |
|
|
CONTROL BOX |
|
|
CONTROL BOX |
|
|
CONTROL-HUMIDITY, LH |
|
|
CONTROL-HUMIDITY, RH |
|
|
CONTROL-TEMPERATURE |
|
|
CONTROLLER, COMPRESSOR |
|
|
COVER, COIL |
|
|
COVER, CONNECTION, ICE MAKER |
|
|
COVER, EVAPORATOR FAN |
|
|
COVER-ACCESS, W/LABEL |
|
|
COVER-CRISPER PAN |
|
|
COVER-UPPER HINGE, WHITE |
|
|
DAMPER, FAN COVER |
|
|
DIFFUSER, AIR, BOTTOM |
|
|
DIFFUSER, AIR, TOP |
|
|
DOOR STOP, WHITE, FRZR |
|
|
DOOR STOP, WHITE, REF |
|
|
DOOR-DAIRY |
|
|
DOOR-FRZR, WHITE, COMPLETE ASSEMBLY |
|
|
DOOR-REFR, WHITE, COMPLETE ASSEMBLY |
|
|
DRYER-FILTER, W/PROCESS TUBE |
|
|
EVAPORATOR KIT |
|
|
FAN BLADE, EVAPORATOR |
|
|
FRAME, SLIDING SHELF, FULL WIDTH |
|
|
FRAME, SLIDING SHELF, FULL WIDTH, W/HANGER TABS |
|
|
GASKET-FRZR DOOR, WHITE, MAGNETIC |
|
|
GASKET-REFR DOOR, WHITE, MAGNETIC |
|
|
GLASS-SHELF, 23.78-INCH X 16.34-INCH |
|
|
GRILLE/KICKPLATE, WHITE |
|
|
GROMMET, EVAPORATOR FAN, FRONT |
|
|
GROMMET, EVAPORATOR FAN, REAR |
|
|
GROMMET, RUBBER, BLACK, 23 # |
|
|
GROMMET, SHELF MTG |
|
|
GROMMET-COMPR MTG, (4) |
|
|
HANDLE-DOOR, WHITE, W/BLOCK & SCREW |
|
|
HARNESS-WIRING, MACHINE COMPT |
|
|
HEAT EXCHANGER KIT, SUCTION LINE |
|
|
HEATER-DEFROST |
|
|
HOT TUBE REPAIR KIT, SERVICE |
|
|
INSERT-PAN COVER, 23.82-INCH X 15.50-INCH, GLASS |
|
|
KNOB, SLIDING, DAMPER |
|
|
KNOB, TEMP CONTROL |
|
|
LABEL-ENERGY/ENERGUIDE |
|
|
LIGHT BULB |
|
|
MOTOR-BLOWER |
|
|
MOTOR-CONDENSER FAN |
|
|
NAMEPLATE, WHITE |
|
|
PAN-CRISPER, CLEAR, (2), NO GRAPHICS |
|
|
PAN-DEFROST |
|
|
PAN-MEAT, W/O GRAPHICS, CLEAR |
|
|
PIN-CENTER HINGE |
|
|
PIN-LOWER HINGE |
|
|
PLUG, ROUND, FOAM, ICE MAKER, WATER INLET |
|
|
PLUG-BUTTON, WHITE, CAB LINER HOLES |
|
|
PLUG-BUTTON, WHITE, HINGE BRG HOLE, (2) |
|
|
PLUG-BUTTON, WHITE, UPR HINGE HOLES |
|
|
PLUG-HOLE, FACTORY TEST |
|
|
RACK-DOOR |
|
|
RACK-DOOR |
|
|
RACK-DOOR, 4B |
|
|
RING, LOCKING, (2) |
|
|
RIVET, FLAT HEAD, 1/4 OD X 1-3/4, ROLLER PIN |
|
|
ROLLER ASSEMBLY, FRONT LH, (2) |
|
|
ROLLER ASSEMBLY, FRONT RH, (2) |
|
|
ROLLER, COMPRESSOR BASE, REAR |
|
|
SCREW, #10-16 X 1/2 |
|
|
SCREW, #8 TRUSS HD, 10-32CA X 0.500 |
|
|
SCREW, 8-18 X .500 |
|
|
SCREW, HANGER/RLR MTG, 8-10 X 7/16 |
|
|
SCREW, HEX HEAD, 1/4-20 X 5/8, WHITE |
|
|
SCREW, HEX WASHER HD, 1/4 X 7/8, HINGE MTG |
|
|
SCREW, HEX WASHER HEAD, 8-15A X 0.625, LOW PROFILE |
|
|
SCREW, HEX WASHER HEAD, 8-18 X 5/16 |
|
|
SCREW, HEX WASHER HEAD, 8-18AB X 0.625 |
|
|
SCREW, QUAD HILO, #8-18 X 0.50, (2) |
|
|
SCREW, TRUSS HD QUAD, 10 X 16, BLACK |
|
|
SCREW-#10-32 X 3/4, WHITE |
|
|
SCREW-FAN SHROUD, (2) |
|
|
SCREW-TIMER MTG, PAN HD, 6-20 X 0.438 |
|
|
SEAL |
|
|
SEAL-COIL COVER |
|
|
SHELF, FREEZER |
|
|
SHIELD, HEAT, EVAP BLOCK |
|
|
SHROUD BRACKET, EVAPORATOR FAN |
|
|
SHROUD, CONDENSER FAN |
|
|
SOCKET-LIGHT |
|
|
SPACER-HINGE, CENTER, WHITE |
|
|
SPACER-SHELF |
|
|
STRAP-EVAP/HEATER, ALUMINUM, (2) |
|
|
SWITCH-LIGHT/LAMP |
|
|
TAPE-FOAM SEAL, SHROUD |
|
|
THERMOSTAT KIT, DEFROST, W/CONNECTOR |
|
|
TIMER-DEFROST |
|
|
TRACK, MEAT PAN HANGER, LH |
|
|
TRACK, MEAT PAN HANGER, RH |
|
|
TRIM-CABINET CORNER, WHITE, (2) |
|
|
TRIM-SHELF, FRONT |
|
|
TRIM-SHELF, REAR |
|
|
TROUGH-DRAIN |
|
|
TUBE, SENSOR SLEEVE, 31-INCH, PLASTIC, WHITE |
|
|
TUBE-CONNECTOR, SUCTION |
|
|
TUBE-DRAIN, RUBBER, LOWER |
|
|
WASHER, HINGE, NYLON, (2) |
|
|
WASHER-COMPR MTG |
