Model Image
Manufacturer

Electrolux

Model Number

FFU20F6BW1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
5303212700 5303212700 AIR DUCT
216154400 216154400 BASKET
216085800 216085800 BREAKER
5305878546 5305878546 BUMPER-BASKET
5303015102 5303015102 CAP-WATER VALVE
3206315 3206315 CLAMP
5303001193 5303001193 CLAMP
215012000 215012000 CLAMP
5308000133 5308000133 CLAMP
5303212828 5303212828 CLIP,PANEL MTG ,(1)
5300154167 5300154167 CLIP-RETAINER
5300083897 5300083897 CONDENSER
3206321 3206321 CONNECTOR PLUG
216230300 216230300 COVER
5304469385 5304469385 COVER-ICE MAKER,36,MID-SOUTH
5303207442 5303207442 DATA SHEET
5308005500 5308005500 DRAIN
5304469384 5304469384 EJECTOR-ICE,18,MID-SOUTH ELEC
216087400 216087400 END CAP, WHITE
5303207445 5303207445 ENVELOPE-DATA SHEET
216195900 216195900 EVAPORATOR
205363701 205363701 FOOT-ADJUSTABLE
3206261 3206261 GASKET, DOOR, WHITE
216204901 216204901 GASKET-COVER EVAP
5304469403 5304469403 GEAR
08009560 08009560 GLIDE-BASKET,(4)
3206349 3206349 HARNESS-WIRING-INTERNAL IM-W/ PLUG
5308009754 5308009754 HEATER DEFROST
216254600 216254600 HEATER-DEFROST
5304469378 5304469378 ICE STRIPPER,21,MID-SOUTH ELE
216209001 216209001 INSERT, HANDLE BOTTOM
5304469406 5304469406 INSULATOR
5316651102 5316651102 INSULATOR PLASTIC
216008801 216008801 KNOB-CONTROL
3206299 3206299 LABEL
5304456675 5304456675 LEVER ARM,24,MID-SOUTH ELEC
240436702 240436702 LIGHT BULB/LAMP,A-15 ,CLEAR ,40 W ,120 V,MINIATURE
5303918277 5303918277 MOTOR ASSY
216313200 216313200 NLAHARNESS-ELECTR
5303294372 5303294372 NUT-INSERT
5303270406 5303270406 OVERLOAD SERVICE COMPRESSOR
5303916001 5303916001 PAN RETAINER, KIT, SERVICE
216048807 216048807 PANEL-INNER DOOR/LI
3206303 3206303 PLATE-MOUNTING
3206343 3206343 PLATE-VALVE SWITCH
5303208663 5303208663 PLUG INDICATOR
5308013640 5308013640 RACK-DOOR, FULL-WIDTH, NARROW
215516220 215516220 RACK-DOOR, FULL-WIDTH, WIDE
5300091170 5300091170 REINFORCEMENT
3206336 3206336 SCREW
3206323 3206323 SCREW
5304459910 5304459910 SCREW
5303207328 5303207328 SCREW
5303272328 5303272328 SCREW
5303205738 5303205738 SCREW
216022800 216022800 SCREW
216036601 216036601 SCREW
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5303015671 5303015671 SCREW,HEX WASHER HEAD ,8-18 X 0 .375 ,CUP POINT
131168200 131168200 SCREW,PAN HEAD ,8-18B X 0.31
5300052943 5300052943 SCREW-CLAMP
5304455670 5304455670 SCREW-GROUND WIRE
3206345 3206345 SCREW-MTG PLATE/SPR
3206340 3206340 SCREW-MTR & SW/PLAT
3206334 3206334 SCREW-SUP/MOLD BODY
216858001 216858001 SCREW-SUPPORT
5304458387 5304458387 SCREW-TIMING ADJ
3206339 3206339 SCREW-TIMING STOP
131751500 131751500 SCREWSOLENOID VALV
5303288196 5303288196 SLEEVE
5303208489 5303208489 SLEEVE 301446
5306594529 5306594529 SLEEVE-COMPRESSOR
5303001191 5303001191 SLEEVE-TUBE INSERT
5300136117 5300136117 SOCKET-LIGHT/LAMP
5304469401 5304469401 SPRING
5303937141 5303937141 STACKING KIT,WASHER/DRYER
5308000110 5308000110 STRAP - EVAPORATOR/HEATER
5309918806 5309918806 SWITCH-LIGHT/ LAMP
216254500 216254500 SWITCH-TERMINATION
3206319 3206319 THERMAL CUTOFF ASSEMBLY
3206322 3206322 THERMOSTAT ASSY-ICE MAKER
134237200 134237200 TIMER,WASHER ,5 OFF
216211200 216211200 TRIM-HANDLE, UPPER
5309950074 5309950074 VALVE
5300114366 5300114366 WASHER-SEALING
5308000205 5308000205 WATER SUPPLY ADAPTER KIT
