Manufacturer
Electrolux
Model Number
FGEH3047VDE
Description
Range/oven, Electric, Freestanding, 30 Inch
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ANTI TIP KIT, ASSY, W/TEMPLATE |
|
|
BACK, MAIN |
|
|
BASE, BAKE ELEMENT |
|
|
BOARD, PC, OVEN RELAY |
|
|
BRACKET, CABLE MTG |
|
|
BRACKET, MOTOR MTG. |
|
|
BRACKET, MOUNTING, LH, COOKTOP |
|
|
BRACKET, MOUNTING, RH, COOKTOP |
|
|
BRACKET, SUPPORT, BODY SIDE, (2) |
|
|
BRACKET, SUPPORT, REAR, CHASSIS |
|
|
BROIL PAN KIT, PAN & INSERT, SLATE BLUE, OPTIONAL, ACCESSORY |
|
|
BUMPER GUARD, ASSEMBLY, MAGNETIC |
|
|
BUMPER, FRONT, MAIN |
|
|
CHANNEL, ELEMENT SUPPORT |
|
|
CLIP, BODYSIDE |
|
|
CLIP, ELEMENT MTG |
|
|
CONTROL PANEL, FRONT, BLACK STAINLESS |
|
|
CONTROL, ELECTRONIC, BLACK, ES501E |
|
|
COVER, ACCESS |
|
|
COVER, FAN |
|
|
DEFLECTOR, MOISTURE, (2) |
|
|
DOOR CAP, ASSEMBLY, BLACK STAINLESS |
|
|
DRAWER, WARMER |
|
|
DUCT, COOLING, 60 |
|
|
DUCT, INLET AIR, FRONT |
|
|
DUCT, INLET AIR, REAR |
|
|
ELEMENT, BAKE, 3500W |
|
|
ELEMENT, BROIL |
|
|
ELEMENT, CONVECTION, 900W |
|
|
ELEMENT, DUAL, 9/6", SURFACE, 3200/1400W |
|
|
ELEMENT, SURFACE, 6", 1200, (2), RADIANT |
|
|
ELEMENT, TRIPLE, 1200/2000/3000W, 6"/9"/12" |
|
|
ELEMENT, WARMER, 100 W |
|
|
FAN ASSEMBLY, COOLING |
|
|
FAN BLADE |
|
|
GLASS ASSEMBLY, DOOR, BLACK, OUTER, W/FOIL |
|
|
GLASS, OVEN DOOR, INNER |
|
|
GLIDE, WARMER DRAWER, 77, (2) |
|
|
GLIDE, WARMER, INNER LH |
|
|
GLIDE, WARMER, INNER RH |
|
|
HANDLE, DOOR/DRAWER, BLACK STAINLESS |
|
|
HARNESS, WIRING, BACKSPLASH |
|
|
HARNESS, WIRING, LOW VOLTAGE |
|
|
HARNESS, WIRING, SURFACE |
|
|
HARNESS-MAIN FC ELECT, * # |
|
|
HINGE, DOOR, ORANGE, DUAL SPRING |
|
|
INSULATION, DOOR LINER, TOP |
|
|
INSULATION, DOOR, TOP CAP |
|
|
INSULATION, OVEN BACK |
|
|
INSULATION, OVEN BOTTOM |
|
|
INSULATION, OVEN DOOR |
|
|
INSULATION, OVEN SUMP |
|
|
INSULATION, OVEN WRAPPER |
|
|
INSULATOR |
|
|
INSULATOR, CONTROLLER, W/ADHESV TAPE |
|
|
KNOB, INFINITE SWITCH, BLACK STAINLESS, DUAL |
|
|
KNOB, INFINITE SWITCH, BLACK STAINLESS, SINGLE |
|
|
KNOB, INFINITE SWITCH, BLACK STAINLESS, TRIPLE |
|
|
LABEL, ANTI-TIP |
|
|
LAMP, OVEN LIGHT |
|
|
LATCH ASSEMBLY, OVEN DOOR |
|
|
LENS, OVEN LIGHT, GLASS |
|
|
LENS-LIGHT/LAMP, INDICATOR, CLEAR |
|
|
LEVELING LEG ASSY, METAL, FRONT, (2), BRACKET & LEG |
|
|
LIGHT/LAMP, INDICATOR, BLACK, 125 V |
|
|
LINER, DRAWER |
|
|
LINER, OVEN DOOR |
|
|
MOTOR, LATCH |
|
|
MOTOR-FAN |
|
|
NUT, FAN RETAINER |
|
|
NUT, HEX FLANGE, 3/8 10-32 |
|
|
PANEL, BODYSIDE, BLACK, LH |
|
|
PANEL, BODYSIDE, BLACK, RH |
|
|
PANEL, DRAWER, BLACK STAINLESS |
|
|
PANEL, OVEN BOTTOM |
|
|
PLATE, GROUNDING STRAP |
|
|
PLATE, OVEN VENT |
|
|
PROBE, OVEN TEMP |
|
|
RACK,OVEN |
|
|
REAR FILLER KIT, FCFS RANGE, BLACK |
|
|
RECEPTACLE, OVEN LIGHT, 24 # |
|
|
RECEPTACLE,HINGE ,(2) |
|
|
RETAINER, LENS |
|
|
ROD, AUTO LATCH |
|
|
SCREW, 10-16 X .486 |
|
|
SCREW, 6-20 X 0.312 |
|
|
SCREW, 8-18 X 0.5, CHROME |
|
|
SCREW, 8-18 X 11/16, BLACK, (3) |
|
|
SCREW, BRACKET, STIFFENER, (4) |
|
|
SCREW, CONCRETE, 1.75", ANTI-TIP BRKT |
|
|
SCREW, GROUNDING, 10-24 X 1.835, GREEN |
|
|
SCREW, HEX HD, #8-18 X 5/8 |
|
|
SCREW, HEX HEAD CUP PT, 8-18 X 0.375, BLACK |
|
|
SCREW, LEVELING, PLASTIC, REAR, (2) |
|
|
SCREW, LOCTITE, #10-24X1.94, (2) |
|
|
SCREW, SIMS LP, #8-32 X 5/16", BLACK |
|
|
SCREW, TR HD SQD AB, 8-18 X 0.25, (8) |
|
|
SCREW, TRUSS SQDR, 8-32 X 3/16, SWITCH MTG |
|
|
SCREW, TRUSS SQDR, 8A X 1", 62* |
|
|
SCREW, WAFER HD SQ DR, 8-18AB X 0.5 |
|
|
SCREW, WAFER HEAD, 8-32T X 0.500, BLACK, 44* |
|
|
SCREW,HANDLE MTG. |
|
|
SCREW,W/WASHER ,8-18 |
|
|
SEAL, CONTROL PANEL |
|
|
SEAL, MAINTOP, SILICONE, REAR |
|
|
SEAL, OVEN DOOR |
|
|
SHIELD, CHASSIS, LOWER |
|
|
SHIELD, REAR WALL, UPPER |
|
|
SHIELD, WARMER DRAWER |
|
|
SHIELD, WARMER SIDE, LH |
|
|
SHIELD, WARMER SIDE, RH |
|
|
SHIELD, WIRE, REAR |
|
|
SHIELD, WOOL |
|
|
SHIELD,BODYSIDE |
|
|
SMOOTHTOP, ASSEMBLY, GLASS/STEEL, BLACK |
|
|
SPACER, DOOR, LH |
|
|
SPACER, DOOR, RH |
|
|
SPACER, FOAM BLOCK, 2" X 1", W/ADHESIVE |
|
|
SPACER, GLASS |
|
|
SPACER, WIRE SHIELD, (2) |
|
|
SUPPORT, ELEMENT |
|
|
SUPPORT, ELEMENT, BROIL |
|
|
SUPPORT, OVEN BOTTOM |
|
|
SWITCH, INFINITE, DUAL |
|
|
SWITCH, INFINITE, SMALL ELEMENT |
|
|
SWITCH, OVEN LIGHT, DOOR FRAME |
|
|
SWITCH, TRIPLE, INFINITE |
|
|
TERMINAL BLOCK KIT |
|
|
THERMOSTAT, SAFETY, 105C |
|
|
TRIM KIT-DOOR, 3 SIDED, BLACK, W/TAPE |
|
|
TRIM, VENT, BLACK, REAR |
|
|
TUBE, OVEN VENT, UPPER |
