Model Image
Manufacturer

Electrolux

Model Number

FGS379DBA

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
318120711 318120711 + SWITCH
5304405244 5304405244 ANTI-TIP & ACCESSOR
318265000 318265000 BOX
318180312 318180312 BRACKET
318180310 318180310 BRACKET
318043100 318043100 BRACKET
318263100 318263100 BRACKET
5303304030 5303304030 BRACKET
318262800 318262800 BRACKET
5303013071 5303013071 BULB/LAMP,OVEN LIGHT
318266900 318266900 BURNER
318283700 318283700 BURNER
316212300 316212300 BURNER,SEALED ,11K
316223400 316223400 BURNER,SEALED ,14K
316206401 316206401 BURNER,SEALED ,5K
316212400 316212400 BURNER,SEALED ,9.5K
318233400 318233400 BUSHING
5303325174 5303325174 CAP
316242800 316242800 CAP,11K BURNER ,BLACK
316219800 316219800 CAP,14K BURNER ,BLACK
316206500 316206500 CAP,5K BURNER ,BLACK
316242900 316242900 CAP,9.5K BURNER ,BLACK
5303311130 5303311130 CHANNEL
5303311129 5303311129 CHANNEL
318167300 318167300 CLIP
5304400195 5304400195 CLIP
318235300 318235300 CONNECTOR ASSEMBLY.
318235021 318235021 CONSOLE,ASSY. ,BLACK ,W/ END CAPS
318269100 318269100 COVER
318229900 318229900 COVER
318269200 318269200 COVER
5303310526 5303310526 COVER
318406100 318406100 COVER, GLASS LITE
318056815 318056815 DEFLECTOR
318223900 318223900 GASKET
318053103 318053103 GASKET,OVEN DOOR SEAL
318041603 318041603 GLASS-OVEN DOOR, HEAT BARRIER
318231300 318231300 GRATE
318268600 318268600 HARNESS
318222400 318222400 HOUSING,OVEN LIGHT
318177710 318177710 IGNITOR,BURNER
318221314 318221314 IGNITOR/ORIFICE ASS
318221312 318221312 IGNITOR/ORIFICE ASS
318221311 318221311 IGNITOR/ORIFICE ASS
318221310 318221310 IGNITOR/ORIFICE ASS
318268100 318268100 INSULATION
318229311 318229311 KNOB
5303310536 5303310536 LATCH
318262401 318262401 LINER
318186907 318186907 LP CONVERSION KIT
318267800 318267800 MIXER ELBOW
316135702 316135702 MODULE,SPARK
318095957 318095957 MOTOR,LATCH ASSY ,W/BRKT & SWITCH
5304441056 5304441056 NUT
318233800 318233800 NUT
316237901 316237901 ORIFICE,TOP BURNER ,11K
316237900 316237900 ORIFICE,TOP BURNER ,14K
316237903 316237903 ORIFICE,TOP BURNER ,5K
316237902 316237902 ORIFICE-TOP BURNER,9.5K
316220805 316220805 OVERLAY,CLOCK ,BLACK ,ES300
318187714 318187714 PANEL
318121402 318121402 PANEL
318225101 318225101 PANEL
318066415 318066415 PANEL
318272600 318272600 PANEL
318265400 318265400 PANEL
318225200 318225200 PANEL
5303310515 5303310515 PANEL
318235169 318235169 PANEL
318224402 318224402 PANEL
318227502 318227502 PLATE
807108202 807108202 POWER CORD
316217002 316217002 PROBE,OVEN TEMP
318328010 318328010 RECEPTACLE,HINGE
318250210 318250210 ROD
5303307980 5303307980 SCREW
5304415832 5304415832 SCREW
5303323129 5303323129 SCREW
318175503 318175503 SCREW
316215600 316215600 SCREW
5303300195 5303300195 SCREW
5303323134 5303323134 SCREW
5303211311 5303211311 SCREW
5303311174 5303311174 SCREW,10-24 X 3/8
5303300265 5303300265 SCREW,8-18 X 0.500 ,CHROME ,(3)
316240600 316240600 SCREW`ASSY MTG ,IGNITOR/ORIFICE
316242001 316242001 SEAL
316242000 316242000 SEAL,14K BURNER
316242003 316242003 SEAL-BURNER
316242002 316242002 SEAL-BURNER
318236200 318236200 SHIELD
316241701 316241701 SKIRT
316264901 316264901 SKIRT
316241901 316241901 SKIRT-BURNER
316241801 316241801 SKIRT-BURNER
5303311164 5303311164 SPRING
318192400 318192400 SPRING
5303311142 5303311142 SUPPORT
318394803 318394803 SWITCH,LIGHT
318003606 318003606 THERMOSTAT,SAFETY
318176647 318176647 TRIM
318187815 318187815 TRIM
318187814 318187814 TRIM
318225902 318225902 TRIM
318224313 318224313 TRIM
318267200 318267200 TUBE
318267000 318267000 TUBE
318267100 318267100 TUBE
318233910 318233910 VALVE
318233900 318233900 VALVE
5304475797 5304475797 VALVE
318233930 318233930 VALVE
318233920 318233920 VALVE
3051063 3051063 WASHER
5304436864 5304436864 WASHER
