Model Image
Manufacturer

Electrolux

Model Number

FPEW3077RFA

Description

Frigidaire Professional 30'' Single Electric Wall

Interactive Exploded View
Exploded View

Parts List

Part Number Description
139009100 139009100 BLADE
318394442 318394442 BOX & WIRES ASSEMBLY
139021100 139021100 BRACKET
318579001 318579001 BRACKET
318946500 318946500 BULB
316136900 316136900 CLEANER
318167300 318167300 CLIP
139000900 139000900 ELEMENT
316502601 316502601 GLASS
318126401 318126401 INSERT
139009000 139009000 LAMP ASSEMBLY
139008503 139008503 MOTOR,CONVECTION FAN,2400 RPM
316136600 316136600 NUT
316205500 316205500 NUT
318138801 318138801 PAN
139011600 139011600 RACK
139012400 139012400 RACK
139013308 139013308 RACK ASSEMBLY,GLIDING,W/HANDLE
316021105 316021105 SCREW
316021109 316021109 SCREW
316021110 316021110 SCREW
5303323129 5303323129 SCREW
5303324184 5303324184 SCREW
5303289910 5303289910 SCREW
316418900 316418900 SCREW
316001003 316001003 SCREW
5303310510 5303310510 SCREW
5304470882 5304470882 SCREW
807597603 807597603 SCREW
809136201 809136201 SCREW,TRUSS HEAD,#8-32 X 3/8
318562500 318562500 SENSOR
139000600 139000600 SHIELD
318531800 318531800 SPACER
316517600 316517600 SPACER
318165800 318165800 SPACER
316502101 316502101 SPACER
5303311164 5303311164 SPRING
318172904 318172904 SUPPORT
139021700 139021700 TUBE
