Model Image
Manufacturer

Electrolux

Model Number

FRS23LH5DBN

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
218888001 218888001 ADAPTER
218676004 218676004 BAND-DECORATIVE
240330007 240330007 BASE-COMPRESSOR MTG
240564301 240564301 BASKET-SLIDING
240328404 240328404 BEARING-HINGE
240328203 240328203 BEARING-HINGE
240328403 240328403 BEARING-HINGE
240359001 240359001 BIN-DOOR
240367301 240367301 BIN-DOOR
240324502 240324502 BIN-DOOR
5304404348 5304404348 BLADE
218679613 218679613 BLOCK-EVAP COIL
240335502 240335502 BOLT-ROLLER ADJ
240369501 240369501 BOX-CONTROL
5304404340 5304404340 BRACKET-CONTROL ROD
218990801 218990801 BRACKET-EVAP/CVR MT
218721500 218721500 BRACKETLEVELING
241555401 241555401 BULB-LAMP
241563601 241563601 BUSHING-MOTOR MTG
240542901 240542901 CAP-WATER VALVE
241630701 241630701 CHANNEL
240430501 240430501 CHANNEL
218659500 218659500 CHANNEL-SHELF MTG
241525101 241525101 CHUTE-ICE
3206315 3206315 CLAMP
5303001193 5303001193 CLAMP
218973501 218973501 CLAMP
5308000133 5308000133 CLAMP
240396801 240396801 CLAMP-TUBE
5303001199 5303001199 CLAMP-WIRING HARNES
240362101 240362101 CLIP
218515401 218515401 CLIP
218515402 218515402 CLIP
240542601 240542601 CLIP-WIRING HARNESS
242039203 242039203 CONDENSER
240351101 240351101 CONTROL-AIR FLOW
240354602 240354602 COVER
240435903 240435903 COVER-AIR DUCT
240354502 240354502 COVER-CRISPER PAN
240475906 240475906 COVER-EVAP COIL
240327007 240327007 COVER-UPPER HINGE
240376002 240376002 COVER-WATER FILTER
240434401 240434401 CUP
241600902 241600902 DAMPER
240507202 240507202 DEFLECTOR-ICE CONTA
240374301 240374301 DIFFUSER-AIR
240335006 240335006 DISCONTINUED
5303918256 5303918256 DISPENSER HEATER KI
5303918455 5303918455 DOOR STOP
240537105 240537105 DOOR STOP
241649003 241649003 DRIP TRAY
240380101 240380101 DUCT-ICE MAKER
240545201 240545201 ELBOW-WATER TUBE
5303918286 5303918286 EVAPORATOR KIT
5308000010 5308000010 FAN BLADE
240405201 240405201 GROMMET
218513300 218513300 GROMMET-COMPR MTG
241550701 241550701 GROMMET-SHELF MTG
241550801 241550801 GROMMET-SHELF MTG
240368701 240368701 GUIDE-CONTROL BULB
218762703 218762703 HANDLE-DOOR
240343002 240343002 HANGER-BASKET
240343102 240343102 HANGER-BASKET
241686001 241686001 HARNESS-WIRING
240552101 240552101 HARNESS-WIRING
241537802 241537802 HARNESS-WIRING
241651601 241651601 HARNESS-WIRING
241586801 241586801 HARNESS-WIRING
5303918222 5303918222 HOT TUBE REPAIR KIT
240434301 240434301 HOUSING
240350614 240350614 INSERT
240394102 240394102 INSULATION-WATER FI
5304469406 5304469406 INSULATOR
240360801 240360801 KNOB
3206299 3206299 LABEL
240570206 240570206 LABEL-MODULE COVER
5304421616 5304421616 LIGHT BULB/LAMP
215782300 215782300 LOCK-HANDLE TRIM
218904301 218904301 O-RING
240354705 240354705 PAN
240354807 240354807 PAN
240355506 240355506 PAN-MEAT
240518802 240518802 PIN-PUSH
240457702 240457702 PLATE
3206303 3206303 PLATE-MOUNTING
3206343 3206343 PLATE-VALVE SWITCH
240494001 240494001 PLUG
5303208309 5303208309 PLUG-HOLE
5304404880 5304404880 RAIL ASSEMBLY
5303316859 5303316859 RIVET
5304418225 5304418225 ROLLER
5304408581 5304408581 SCREW
5304459910 5304459910 SCREW
3206336 3206336 SCREW
3206323 3206323 SCREW
5304420655 5304420655 SCREW
5304408585 5304408585 SCREW
5304408582 5304408582 SCREW
5304420652 5304420652 SCREW
5303207328 5303207328 SCREW
241690501 241690501 SCREW
241500301 241500301 SCREW
240569501 240569501 SCREW
218897004 218897004 SCREW
240402701 240402701 SCREW-#10-32 X 1/4
240555002 240555002 SCREW-#8-32 X 3/8
5304404364 5304404364 SCREW-BRACKET
240491503 240491503 SCREW-COMPRESSOR MT
240359403 240359403 SCREW-FAN SHROUD
5304455670 5304455670 SCREW-GROUND WIRE
5304421830 5304421830 SCREW-MICRO SWITCH
240363601 240363601 SCREW-SHOULDER
5304404331 5304404331 SCREW-SOLENOID
5304458387 5304458387 SCREW-TIMING ADJ
3206339 3206339 SCREW-TIMING STOP
215188300 215188300 SCREWCONTROL BOX M
240355211 240355211 SHELF-SPILL-SAFE
240349801 240349801 SLIDE CLIP
240548901 240548901 SOCKET
241559801 241559801 SOCKET-LIGHT
5304469396 5304469396 SPRING
5308000110 5308000110 STRAP-EVAP/HEATER
5304420653 5304420653 SUPPORT
240505801 240505801 SWITCH
241547901 241547901 SWITCH-LIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
3206319 3206319 THERMAL CUTOFF
3206322 3206322 THERMOSTAT ASSEMBLY
240365401 240365401 TRACK
240356501 240356501 TRACK
240337603 240337603 TRIM-CABINET CORNER
240430701 240430701 TRIM-SHELF
240430705 240430705 TRIM-SHELF
240429401 240429401 TROUGH-DRAIN
218976409 218976409 TUBE
218976901 218976901 TUBE
241844801 241844801 TUBE-CONNECTOR
218976904 218976904 TUBE-WATER INLET
218976907 218976907 TUBE-WATER INLET
218709101 218709101 USE 218709101
215474201 215474201 WASHER
240545302 240545302 WATER TANK ASSEMBLY
241578401 241578401 WIRING HARNESS
218710300 218710300 WRENCH-FILTER
