Model Image
Manufacturer

Electrolux

Model Number

FRT13CRHD0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
218519300 218519300 BEARING-HINGE
218396700 218396700 BLOCK
218871800 218871800 BLOCK-EVAP COIL
5308000296 5308000296 BRACKET
5308000107 5308000107 BRACKET-CONNECTOR
5304409595 5304409595 BRACKET-LOWER HINGE
5303322992 5303322992 BRACKET-MOTOR MTG
218397000 218397000 BUTTON-HANDLE MTG,DOVETAIL
5308000133 5308000133 CLAMP
5303001199 5303001199 CLAMP-WIRING HARNES
5308003596 5308003596 CLIP-COMPRESSOR MTG
5303270924 5303270924 CONDENSER
5303321455 5303321455 CONTROL BOX
5304404821 5304404821 CONTROL-TEMPERATURE
218448302 218448302 COVER
3206101 3206101 COVER - TOP HINGE - WHITE
218631001 218631001 COVER-AIR DEFLECTOR
5303270897 5303270897 COVER-CRISPER PAN
218832001 218832001 COVER-EVAP COIL
3206105 3206105 COVER-UPPER HINGE
5303001197 5303001197 COVER-WIRING
218722200 218722200 DAMPER-FAN COVER
218730000 218730000 DEFLECTOR-AIR
5308000716 5308000716 DISH
218249002 218249002 DOOR STOP
218730602 218730602 GASKET-REFR DOOR
5304464361 5304464361 HANDLE-DOOR W/BLOCK AND SCREW, ALMOND
297311201 297311201 HANDLE-DOOR,WHITE
218428101 218428101 HANDLE-DOOR,WHITE ,W/BLOCK & SCREW
218878400 218878400 HARNESS-WIRING
218429305 218429305 HEAT EXCHANGER
5304403171 5304403171 HEATER-DEFROST
218781001 218781001 HEATER-MULLION
3916557 3916557 HOT TUBE REPAIR KIT
5303917276 5303917276 INSULATION-DOOR
5316651102 5316651102 INSULATOR PLASTIC
5303307351 5303307351 KNOB-DAMPER CONTROL
5303275221 5303275221 KNOB-TEMP CONTROL
218917602 218917602 LABEL-NAMEPLATE
5303001348 5303001348 NUT
5308016567 5308016567 NUT-ANCHOR
5303916001 5303916001 PAN RETAINER, KIT, SERVICE
5303917815 5303917815 PANEL-EXT DOOR
5303917817 5303917817 PANEL-EXT DOOR
5303271483 5303271483 PANEL-INNER DOOR
5303271486 5303271486 PANEL-INNER DOOR
218251300 218251300 PIN, CENTER HINGE
218802500 218802500 PLATE-COMPR MTG
215774911 215774911 PLUG-BUTTON
240494004 240494004 PLUG-BUTTON
5303001308 5303001308 PLUG-BUTTON
5303208309 5303208309 PLUG-HOLE, FACTORRY TEST
215217703 215217703 PLUGBUTTON
215099711 215099711 PLUGBUTTON
5303283014 5303283014 ROLLER ASSY, METAL HOUSING, FRONT/REAR, (2)
5303001380 5303001380 SCREW
5308000039 5308000039 SCREW
218252201 218252201 SCREW, NO.8 TRUSS HD, 10-32CA X 0.500
218188000 218188000 SCREW, PAN HD, 10-32X0.625, HINGE/MULL, THRD FORM
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
5303001260 5303001260 SCREW-CONTROL MTG
241710601 241710601 SCREW-HINGE MTG,HEX HD ,1/4-20 X 0.875
3206141 3206141 SCREW-LEVELING
5303207353 5303207353 SEAL RING
5303001449 5303001449 SEAL-AIR DEFLECTOR, FOAM PLASTIC
5303282284 5303282284 SHELF-FREEZER, ``TABLE TYPE``
5303208866 5303208866 SPACER
5303324302 5303324302 SUPPORT-DOOR RACK,LH
218865000 218865000 SUPPORT-EVAP COVER
5303286905 5303286905 SWITCH-ENERGY SAVER
5309918806 5309918806 SWITCH-LIGHT/ LAMP
218845602 218845602 TAPPING PLATE
215667501 215667501 TRAY,ICE CUBE ,PLASTIC
5303321082 5303321082 TRIM-CABINET CORNER
5303916855 5303916855 TUBE
218731104 218731104 TUBE, PVC, WHITE @ AIR DEFLECTOR, INSULATOR
5303272327 5303272327 TUBE-DRAIN
5308009617 5308009617 WASHER
5308003633 5308003633 WASHER-COMPR MTG
218740800 218740800 WIRE BALE
