Model Image
Manufacturer

Electrolux

Model Number

GLRS234ZAQ1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
240451917 240451917 23 DOOR-REFR
241681902 241681902 ACTUATOR-ICE`BISQUE
241682002 241682002 ACTUATOR-WATER,BISQUE
218888001 218888001 ADAPTER-WATER SUPPLY,NUT & SLEEVE ,
242000501 242000501 BEARING-HINGE(FRZ),CLOSER
240328201 240328201 BEARING-HINGE(REF),CLOSER
240328401 240328401 BEARING-HINGE(REF),NATURAL ,UPPER
240328402 240328402 BEARING-HINGE,NATURAL ,UPPER
240359002 240359002 BIN-DOOR
240367302 240367302 BIN-DOOR
240363702 240363702 BIN-DOOR,2-LITER
240430303 240430303 BIN-DOOR,GALLON
241684101 241684101 BLADE
218396700 218396700 BLOCK
218679613 218679613 BLOCK-EVAP COIL
240335006 240335006 BOLT-ROLLER ADJ,HEX WASHER HEAD ,1/4-20 X 4.020,(2) ,SPECIAL
240374901 240374901 BOX
240369501 240369501 BOX-CONTROL
5303292397 5303292397 BRACKET, MOTOR MTG, REAR
5304404340 5304404340 BRACKET-CONTROL ROD
218990801 218990801 BRACKET-EVAP/CVR MT
5303918455 5303918455 BRACKET-LOWER HINGE
5303292396 5303292396 BRACKET-MOTOR MTG
240346501 240346501 BRACKET-SUPPORT
240327207 240327207 BRACKET-UPPER HINGE
218721500 218721500 BRACKETLEVELING
218397000 218397000 BUTTON-HANDLE MTG,DOVETAIL
240421701 240421701 BUTTON-HANDLE MTG,DOVETAIL
242227702 242227702 BYPASS,WATER FILTER ,OPTIONAL PART
241685201 241685201 CAM-DRIVE
241680301 241680301 CARRIER
218659500 218659500 CHANNEL-SHELF MTG
3206315 3206315 CLAMP
5303001193 5303001193 CLAMP
240396801 240396801 CLAMP-TUBE
5303001199 5303001199 CLAMP-WIRING HARNES
218515402 218515402 CLIP
240362101 240362101 CLIP-SLIDE,COVER-CRISPER
240349801 240349801 CLIP-SLIDE,PAN-CRISPER
242039203 242039203 CONDENSER
241734001 241734001 CONTAINER-ICE,BUCKET ONLY
240351101 240351101 CONTROL-HUMIDITY
5304496561 5304496561 CONTROL-THERMOSTAT
241719710 241719710 COVER-EVAP COIL
5304469385 5304469385 COVER-ICE MAKER,36,MID-SOUTH
240373805 240373805 COVER-WATER TUBE
241689301 241689301 DAMPER-ROTARY
5303918255 5303918255 DEFROST HEATER KIT
240374301 240374301 DIFFUSER-AIR
241688401 241688401 DOOR ASSY-ICE CHUTE
241688501 241688501 DOOR CENTER
241688701 241688701 DOOR SEAL
240338313 240338313 DOOR,DAIRY ,CLEAR
241684501 241684501 DRIVE BLADE
241685101 241685101 DRUM-ICE DISP
240380101 240380101 DUCT-ICE MAKER
3205266 3205266 EDGE PROTECTOR
5304469384 5304469384 EJECTOR-ICE,18,MID-SOUTH ELEC
240315401 240315401 FAN BLADE,GALV STEEL ,CONDENSER FAN
5308000010 5308000010 FAN BLADE,RED ,EVAPORATOR FAN
5304469403 5304469403 GEAR
240405201 240405201 GROMMET
240346601 240346601 GROMMET-BRACKET
218513300 218513300 GROMMET-COMPR MTG
241550701 241550701 GROMMET-SHELF MTG,.875`` LONG
215004800 215004800 GROMMETSILENCER
240368701 240368701 GUIDE-CONTROL BULB
241675601 241675601 GUIDE-SOLENOID
5304485331 5304485331 HANDLE-DOOR,BISQUE
240439901 240439901 HARNESS-ELECTRICAL
240346402 240346402 HARNESS-WIRING,MACHINE COMPT
3206349 3206349 HARNESS-WIRING-INTERNAL IM-W/ PLUG
5303918222 5303918222 HOT TUBE REPAIR KIT,SERVICE
241885001 241885001 HOUSING-CRUSHER
5304469378 5304469378 ICE STRIPPER,21,MID-SOUTH ELE
240350613 240350613 INSERT-PAN COVER,GLASS
240350614 240350614 INSERT-PAN COVER,GLASS
241688601 241688601 INSULATION-DOOR
240394203 240394203 INSULATION-WATER TU
5304469406 5304469406 INSULATOR
240360801 240360801 KNOB,TEMP CONTROL
3206299 3206299 LABEL
240398502 240398502 LABEL-CONTROL BOX
240323912 240323912 LABEL-MODULE COVER
5304456675 5304456675 LEVER ARM,24,MID-SOUTH ELEC
5304421616 5304421616 LIGHT BULB
240397601 240397601 LIGHT PIPE
241798224 241798224 MOLD-ICE MAKER,RADIUS CUBE ,WITH HEATER
5303918277 5303918277 MOTOR ASSY
242118803 242118803 MOTOR-AUGER
215004700 215004700 N/L/A 07/13/09
5303209814 5303209814 NUT
241685001 241685001 NUT-AUGER
5304414035 5304414035 PAINT,TOUCH-UP ,BISQUE
240354805 240354805 PAN-CRISPER,LOWER
240354705 240354705 PAN-CRISPER,UPPER
240355506 240355506 PAN-MEAT
241688801 241688801 PIN-HINGE
241684001 241684001 PLATE-FRONT
3206303 3206303 PLATE-MOUNTING
3206343 3206343 PLATE-VALVE SWITCH
5303208309 5303208309 PLUG-HOLE, FACTORRY TEST
5304421827 5304421827 POWER BOARD
240397401 240397401 RETAINER
240397501 240397501 ROD
5304418225 5304418225 ROLLER,COMPRESSOR BASE ,REAR ,(2)
5308000039 5308000039 SCREW
5304408581 5304408581 SCREW
5304459910 5304459910 SCREW
3206336 3206336 SCREW
3206323 3206323 SCREW
5304420655 5304420655 SCREW
5304408585 5304408585 SCREW
5304408582 5304408582 SCREW
5304420652 5304420652 SCREW
5304455852 5304455852 SCREW
241690501 241690501 SCREW
241500301 241500301 SCREW
218897004 218897004 SCREW
218897001 218897001 SCREW
218252201 218252201 SCREW, NO.8 TRUSS HD, 10-32CA X 0.500
218781101 218781101 SCREW, PAN HEAD, NO.8-18 X 5/8
215005101 215005101 SCREW,HANGER/RLR MTG ,8-10 X 0.438
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
218749600 218749600 SCREW,NO.10 PAN HD 8-18 X .5
5304404364 5304404364 SCREW-BRACKET
240359403 240359403 SCREW-FAN SHROUD
5304455670 5304455670 SCREW-GROUND WIRE
241710601 241710601 SCREW-HINGE MTG,HEX HD ,1/4-20 X 0.875
241689201 241689201 SCREW-MICRO SWITCH
240402701 240402701 SCREW-NO.10-32 X 1/4 FLAT HD
240363601 240363601 SCREW-SHOULDER
5304404331 5304404331 SCREW-SOLENOID
5304458387 5304458387 SCREW-TIMING ADJ
3206339 3206339 SCREW-TIMING STOP
240342901 240342901 SHELF-ICE CREAM
240355204 240355204 SHELF-SPILL-SAFE
240350103 240350103 SHELF-SPILL-SAFE
240315501 240315501 SHROUD-COND FAN
241675803 241675803 SOLENOID
240409302 240409302 SPACER-COND TUBE
5304469396 5304469396 SPRING,SHUT-OFF ARM
241689001 241689001 SPRING-ACTUATOR
241690101 241690101 SPRING-CONTROL ROD
240398401 240398401 SPRING-FILTER RELEASE ROD
241675902 241675902 SPRING-SOLENOID
5308000110 5308000110 STRAP - EVAPORATOR/HEATER
5304420653 5304420653 SUPPORT
241993101 241993101 SUPPORT,CRISPER COVER ,FRONT ,(4)
241993001 241993001 SUPPORT,CRISPER COVER ,REAR ,(4)
241547902 241547902 SWITCH-LIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
3206319 3206319 THERMAL CUTOFF ASSEMBLY
3206322 3206322 THERMOSTAT ASSY-ICE MAKER
240365401 240365401 TRACK,MEAT PAN HANGER ,LH
240356501 240356501 TRACK,MEAT PAN HANGER ,RH
241927003 241927003 TRIM-HANDLE,30.13`` ,BISQUE ,LOWER
240430701 240430701 TRIM-SHELF
240430705 240430705 TRIM-SHELF
240429401 240429401 TROUGH-DRAIN
241844801 241844801 TUBE-CONNECTOR,SUCTION
241957901 241957901 TUBE-DRAIN,LOWER
218976903 218976903 TUBE-WATER INLET,INLET VALVE ,TO FILTER
218976901 218976901 TUBE-WATER INLET,INLET VALVE ,TO ICE MAKER
218976907 218976907 TUBE-WATER INLET,VALVE TO DOOR
215474201 215474201 WASHER
WF2CB WF2CB WATER FILTER
218740800 218740800 WIRE BALE
5304404335 5304404335 WIRING HARNESS
240323201 240323201 WIRING HARNESS
241578401 241578401 WIRING HARNESS
