Manufacturer
Electrolux
Model Number
LA450JXW3
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
+ ORIFICE,NATURAL GAS ,SIZE 44 |
|
|
BI, METAL ASSY |
|
|
BOLT-ROLLER ADJ,HEX WASHER HEAD ,1/4-20 X 4.020,(2) ,SPECIAL |
|
|
CLIP,(2) ,TUBE MTG. |
|
|
CLOCK/TIMER,EOC |
|
|
CLOCK/TIMER,EOC |
|
|
COVER-UPPER HINGE,BLACK |
|
|
GASKET,TUB |
|
|
GROMMET-SHELF MTG,.875`` LONG |
|
|
HARNESS-WIRING-INTERNAL IM-W/ PLUG |
|
|
KNOB,TIMER ,BLACK |
|
|
PAN,SURFACE ELEMENT ,BLACK ,SML/6 INCH ,(2),W/CLIP |
|
|
PLATE-DOOR CLOSER |
|
|
PLUG-HOLE, FACTORRY TEST |
|
|
RIVET,FLAT HEAD `1/4 OD X 1-3/4 `ROLLER PIN |
|
|
ROLLER ASSY,FRONT ,(2) |
|
|
ROLLER,COMPRESSOR BASE ,REAR ,(2) |
|
|
SCREW, NO.8 TRUSS HD, 10-32CA X 0.500 |
|
|
SCREW,HEX WASHER HEAD ,8-15A X 0.625 , |
|
|
SCREW,NO.10 PAN HD 8-18 X .5 |
|
|
SCREW,PAN HEAD ,8-18B X 0.31 |
|
|
SCREW-HINGE MTG,HEX HEAD ,1/4-20 X 5/8 |
|
|
SCREW-NO.10-32 X 1/4 FLAT HD |
|
|
SENSOR,RADIANT |
|
|
SHIM-LOWER HINGE |
|
|
SLINGER,PUMP |
|
|
SUPPORT,CRISPER COVER ,FRONT ,(4) |
|
|
SUPPORT,CRISPER COVER ,REAR ,(4) |
|
|
SWITCH,LIGHT/LAMP |
|
|
TRIM-CABINET CORNER,BLACK ,(2) |
|
|
VALVE,GAS |
