Model Image
Manufacturer

Electrolux

Model Number

LFFU17F5HWG

Description

Freezer

Interactive Exploded View
Exploded View

Parts List

Part Number Description
216970800 216970800 BEARING
297006800 297006800 BEARING-HINGE
297177200 297177200 BOLT
297344000 297344000 BOTTOM BASKET
297164651 297164651 BRACKET
297164650 297164650 BRACKET
216394050 216394050 BRACKET
297200800 297200800 BREAKER KIT
297200600 297200600 BREAKER KIT W/CORNE
297200100 297200100 BREAKER KIT W/CORNE
5305878546 5305878546 BUMPER-BASKET
218909912 218909912 CAPACITOR
297315800 297315800 CLIP
5304406520 5304406520 CLIP
297213300 297213300 CLIP
216327800 216327800 CLIP
5304472186 5304472186 CLIP
216649200 216649200 CLIP GE CONTROLLER
5300083897 5300083897 CONDENSER
216954224 216954224 CONTROLLER
297098851 297098851 COVEREVAPORATOR
297164400 297164400 COVERHINGE
297257000 297257000 DOOR STOP
5308005500 5308005500 DRAIN
216524201 216524201 GASKET
216204900 216204900 GASKET
216522359 216522359 GASKETDOOR
297293302 297293302 GROMMET
216502400 216502400 GROMMET-SHELF MTG
297217900 297217900 HEAT EXCHANGER
297283800 297283800 HINGE-UPPER
297283900 297283900 HINGEBOTTOM
297001704 297001704 INSULATION
297078701 297078701 INSULATOREVAP
297078801 297078801 INSULATOREVAP
297147700 297147700 KEY
297241400 297241400 LABEL
216846400 216846400 LIGHT BULB/LAMP
297318600 297318600 LOCK ASSEMBLY
297250000 297250000 MOTOR
242062801 242062801 NAMEPLATE
240537301 240537301 NUT-ANCHOR
297272100 297272100 PANDRAIN
216527816 216527816 PANELINNER DOOR
297316501 297316501 PANELOUTER DOOR
216403700 216403700 PLUGBUTTON
297014702 297014702 PLUGSUCTION LINE
216951600 216951600 RACK-DOOR
216503300 216503300 RAMP
216503100 216503100 SCREENDRAIN
297146820 297146820 SCREW
297174300 297174300 SCREW
297236200 297236200 SCREW
297197500 297197500 SCREW
216912401 216912401 SCREW
216036601 216036601 SCREW
240555002 240555002 SCREW-#8-32 X 3/8
216396900 216396900 SCREW-LEG
218755402 218755402 SCREW-SET
218755504 218755504 SCREW-SHOULDER
297119501 297119501 SHELF
297184400 297184400 SHIELDLIGHT
216502500 216502500 SLEEVE
297139500 297139500 SOCKET
216486500 216486500 STOP-BASKET
5308000110 5308000110 STRAP-EVAP/HEATER
297244700 297244700 SUPPORT
216822900 216822900 SWITCH
297018400 297018400 THERMISTOR
297216600 297216600 THERMOSTAT
297273900 297273900 TRIMCABINET CORNER
297280400 297280400 VALVE
