Model Image
Manufacturer

Electrolux

Model Number

LGHB2867PF7A

Description

Refrigerator, French Door, Bottom Freezer, W/dispe

Interactive Exploded View
Exploded View

Parts List

Part Number Description
242037201 242037201 APPLIANCE BIN
241807605 241807605 BAR
241829001 241829001 BARDRIVE
242136901 242136901 BARTIMING
241602112 241602112 BASECOMPRESSOR
242009602 242009602 BASEWATER FILTER
241780810 241780810 BASKETFRZR
241872201 241872201 BEAMCRISPER COVER
241760401 241760401 BEARING
242071401 242071401 BIN
242011701 242011701 BINDOOR
241639502 241639502 BLADE
242029301 242029301 BLOCK
241838402 241838402 BLOCKEVAP COIL
241838401 241838401 BLOCKEVAP COIL
240335006 240335006 BOLT-ROLLER ADJ
241778701 241778701 BRACKETANTI TIP
241972302 241972302 BRACKETFREEZER DRA
242041701 242041701 BRACKETICE MAKER
241761301 241761301 BRACKETUPPER HINGE
242127901 242127901 BUCKET
242068601 242068601 BUMPER
241979601 241979601 BUMPER
242075602 242075602 BUSHING
242075601 242075601 BUSHING
241518301 241518301 BUSHING
242075701 242075701 CAM-LOWER HINGE
241657701 241657701 CAN DISPENSER
241969001 241969001 CAP
241842301 241842301 CAPTHERMISTOR
242122202 242122202 CHANNEL
242122001 242122001 CHANNELSHELF MTG
242122301 242122301 CHANNELSHELF MTG
242122101 242122101 CHANNELSHELF MTG
240396801 240396801 CLAMP-TUBE
241949502 241949502 CLIP
242135301 242135301 CLIP
218515401 218515401 CLIP
242036801 242036801 CLIPPLASTIC
241706202 241706202 COMPRESSOR
241862903 241862903 CONDENSER
241516901 241516901 CORD-SERVICE
242095002 242095002 COVER
242072002 242072002 COVER
242072101 242072101 COVER
242157801 242157801 COVER
242157601 242157601 COVER
242157501 242157501 COVER
242072201 242072201 COVER
241733902 241733902 COVER
808456301 808456301 COVER,WIRING
241860402 241860402 COVEREVAP COIL
241860601 241860601 COVEREVAPORATOR
241518501 241518501 DAMPER
241987301 241987301 DEFLECTORAIR
5303918410 5303918410 DEFROST HEATER KIT
242131301 242131301 DIVIDER
242130901 242130901 DIVIDER
241780904 241780904 DIVIDER
242037202 242037202 DOOR BIN
241987921 241987921 DOOR FREEZER
241868402 241868402 DOOR STOP
241868401 241868401 DOOR STOP
242185617 242185617 DOORREFR
241963102 241963102 DUCTAIR
242006902 242006902 DUCTAIR
3205266 3205266 EDGE PROTECTOR
242094603 242094603 EVAPORATOR
5303918569 5303918569 EVAPORATOR KIT
241509402 241509402 EVAPORATOR MOTOR
5308000010 5308000010 FAN BLADE
241778811 241778811 FLIPPER MULLION ASS
5303918578 5303918578 GASKET
5303918784 5303918784 GASKET
242095406 242095406 GASKET
241860101 241860101 GASKET
241928201 241928201 GASKETAIR DUCT
241860105 241860105 GASKETCOIL COVER
241860104 241860104 GASKETCOIL COVER
241860112 241860112 GASKETEVAP
241860111 241860111 GASKETEVAP
241860103 241860103 GASKETEVAP
241860102 241860102 GASKETEVAP
5303918737 5303918737 GASKETEVAP HOUSING
242082303 242082303 GLASS
242054804 242054804 GRILL
241929902 241929902 GROMMET
241929901 241929901 GROMMET
218513300 218513300 GROMMET-COMPR MTG
808274201 808274201 GUIDE
5304521784 5304521784 HARNESS
242095805 242095805 HARNESS-WIRING
241510904 241510904 HARNESSDISPENSER
242119001 242119001 HARNESSWIRING
241788401 241788401 HARNESSWIRING
242094802 242094802 HEATERDEFROST
241779401 241779401 HINGE
241779801 241779801 HINGEMULLION
242291001 242291001 HOUSING
242047901 242047901 HOUSINGAIR FILTER
242095702 242095702 HOUSINGAIR HANDLER
241983816 241983816 HOUSINGWATER FILTR
242093009 242093009 ICE CONTAINER ASSEMBLY,W/MAGNE
243297609 243297609 ICE MAKER ASSEMBLY
242253002 242253002 ICE MAKER WATER VALVE
242096001 242096001 INSULATION
242072501 242072501 INSULATION
242072401 242072401 INSULATION
242004802 242004802 INSULATIONAIR DUCT
241577505 241577505 INVERTOR
242202701 242202701 LENS
242196204 242196204 LIGHT BOARD,3 LED CLUSTER
241812202 241812202 MAGNET
241779101 241779101 MAGNET
242270102 242270102 MODULE
241816602 241816602 MOTOR AUGER THREADS ARE LEFT H
242018304 242018304 MOTORCONDENSER FAN
241998302 241998302 MOUNTWATER FILTER
242190501 242190501 MULLION
242096802 242096802 PAN
241801802 241801802 PANCRISPER
241920606 241920606 PANDEFROST
242095501 242095501 PINANTI TWIST BUCK
242011101 242011101 PINLOCK
241752703 241752703 RETAINER
242216301 242216301 RETAINERBASKET
5304455655 5304455655 RIVET
5304418225 5304418225 ROLLER
242236801 242236801 ROLLER
242010901 242010901 ROLLER ASSEMBLY
5304455852 5304455852 SCREW
241953907 241953907 SCREW
242025601 242025601 SCREW
134549700 134549700 SCREW
241953904 241953904 SCREW
241853202 241853202 SCREW
5304455650 5304455650 SCREW
242017501 242017501 SCREW
240451503 240451503 SCREW
242077302 242077302 SCREW
242015001 242015001 SCREW
241899703 241899703 SCREW
242039701 242039701 SCREW
242039702 242039702 SCREW
242146401 242146401 SCREW
241953901 241953901 SCREW
5304515677 5304515677 SCREW
241690602 241690602 SCREW
240383412 240383412 SCREW
241695904 241695904 SCREW
241710601 241710601 SCREW
218362501 218362501 SCREW
241732101 241732101 SCREW
241500303 241500303 SCREW
240383407 240383407 SCREW
218252201 218252201 SCREW
241641502 241641502 SCREW
241695906 241695906 SCREW
241690701 241690701 SCREW
240555004 240555004 SCREW#832 X 3/8 B
240442706 240442706 SCREW-#10-32 X 3/4
240363402 240363402 SCREW-#8-18 X 1/2
240555002 240555002 SCREW-#8-32 X 3/8
240491503 240491503 SCREW-COMPRESSOR MT
240359403 240359403 SCREW-FAN SHROUD
240578902 240578902 SCREW-HINGE MTG
216396900 216396900 SCREW-LEG
218755504 218755504 SCREW-SHOULDER
218709101 218709101 SCREWHDL MTG
240363602 240363602 SCREWSHOULDER
241810104 241810104 SEAL
241518601 241518601 SEAL-DAMPER
240597203 240597203 SENSOR
242068703 242068703 SHELF
242200501 242200501 SHELFSPILLSAFE
242235501 242235501 SHELFSPILLSAFE
242072704 242072704 SHIELD-LIGHT,REFR
241946106 241946106 SHROUDCOND FAN
242197901 242197901 SLIDE
241894224 241894224 SLIDE ASSEMBLY
241894223 241894223 SLIDE ASSEMBLY
5303918689 5303918689 SLIDE ASSEMBLY,BASKET LOWER
242240101 242240101 SNAP BUCKET,WIDE SHIELD
241947701 241947701 SPACER
241868202 241868202 SPACER
241868201 241868201 SPACER
240409302 240409302 SPACER-COND TUBE
242139201 242139201 SPRINGCOMPRESSION
5308000110 5308000110 STRAP-EVAP/HEATER
242176503 242176503 SUMP
242071201 242071201 SUMP
242082401 242082401 SUPPORT
242067901 242067901 SUPPORT
242067801 242067801 SUPPORT
242200002 242200002 SUPPORT
242200001 242200001 SUPPORT
242072601 242072601 SUPPORT
807854301 807854301 SUPPORT,HOUSING,MAIN BOARD
241872203 241872203 SUPPORTBEAM
242139301 242139301 SUPPORTBEAM
242060202 242060202 SWITCHLIGHT/LAMP
240346701 240346701 TAPE-FOAM SEAL
242147601 242147601 TAPPING PLATE
808137001 808137001 THERMISTOR,DEFROST TEMP
5304521781 5304521781 THERMOSTAT,DEFROST SAFETY
5303918568 5303918568 THERMOSTATDEFROST
242048002 242048002 TRAYICE NO GRID
242194301 242194301 TRIM
242116801 242116801 TRIMBASKET
240337616 240337616 TRIMCABINET CORNER
241791201 241791201 TROUGHDRAIN
242220204 242220204 TUBE-WATER INLET
242220202 242220202 TUBE-WATER INLET
241871501 241871501 TUBECONNECTOR
215346900 215346900 TUBEPROCESS
241964707 241964707 TUBEWATER
241965906 241965906 TUBEWATER
218976436 218976436 TUBEWATER
242058230 242058230 USER INTERFACE
241868301 241868301 WASHER
215474201 215474201 WASHER
ULTRAWF ULTRAWF WATER FILTER
5304467131 5304467131 WRENCH
