Model Image
Manufacturer

Electrolux

Model Number

MFU16F3BW5

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
216443600 216443600 BEARING
5308012843 5308012843 BRACKET-HINGE TOP
216085800 216085800 BREAKER
5303013071 5303013071 BULB/LAMP,OVEN LIGHT
316057100 316057100 BURNER-TOP (4)
215012000 215012000 CLAMP
215003300 215003300 CLIP, GRILLE, (2)
5303212828 5303212828 CLIP,PANEL MTG ,(1)
5303284616 5303284616 CLIP-THERMOSTAT
5300083897 5300083897 CONDENSER
5303212918 5303212918 CONTAINER-ICE,34,FOR 178675-0
5303200810 5303200810 CONTROL TEMP
216230300 216230300 COVER
5308005500 5308005500 DRAIN
5303051140 5303051140 ELEMENT,BROIL ,2950 W
216334100 216334100 END CAP-LH-RACK-DOO
216334000 216334000 END CAP-RH-RACK-DOO
3201150 3201150 END CAP-SHELF,PROTECTOR ,FRZR SHELF
216195900 216195900 EVAPORATOR
5308000010 5308000010 FAN BLADE,RED ,EVAPORATOR FAN
216396900 216396900 FOOT-ADJUSTABLE
215366301 215366301 FRAMENAMEPLATE
216204900 216204900 GASKET
3206251 3206251 GASKET-DOOR
5303276826 5303276826 GASKET-FRZR DOOR,ALMOND ,MAGNETIC
3051162 3051162 GLIDE,DRAWER ,FRONT
316084503 316084503 GRATE,BLACK ,(4)
5304500407 5304500407 GROMMET,SHELF MTG ,1.25`` ,LH ,(4)
5303001609 5303001609 GROMMET-SHELF MOUNTING
5303001296 5303001296 HANDLE, END (2)
5317842502 5317842502 HEATER DEFROST
216254600 216254600 HEATER-DEFROST
318222400 318222400 HOUSING,OVEN LIGHT
5303917276 5303917276 INSULATION-DOOR
5316651102 5316651102 INSULATOR PLASTIC
216008801 216008801 KNOB-CONTROL
318406100 318406100 LENS,OVEN LIGHT ,GLASS
216394050 216394050 N/L/A 07/13/09
5303013272 5303013272 NUT, BAFFLE
5303294372 5303294372 NUT-INSERT
5303276514 5303276514 OVERLOAD PROTECTOR
5303916001 5303916001 PAN RETAINER, KIT, SERVICE
5308000184 5308000184 PIN CENTER HINGE
5303208309 5303208309 PLUG-HOLE, FACTORRY TEST
216403700 216403700 PLUGBUTTON
5303281388 5303281388 RACK, DOOR
316091706 316091706 REGULATOR,PRESSURE
5308000124 5308000124 RNG-FAN ORIFICE
5303272328 5303272328 SCREW
5303205738 5303205738 SCREW
5308011745 5308011745 SCREW
216022800 216022800 SCREW
216036601 216036601 SCREW
218188000 218188000 SCREW, PAN HD, 10-32X0.625, HINGE/MULL, THRD FORM
5303300265 5303300265 SCREW,8-18 X 0.500 ,CHROME ,(3)
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
131168200 131168200 SCREW,PAN HEAD ,8-18B X 0.31
5300052943 5300052943 SCREW-CLAMP
241710601 241710601 SCREW-HINGE MTG,HEX HD ,1/4-20 X 0.875
216858001 216858001 SCREW-SUPPORT
216266800 216266800 SHELFBOTTOM
5303001037 5303001037 SHIM -UPPER HINGE
5306594529 5306594529 SLEEVE-COMPRESSOR
5303298960 5303298960 SPACER-TUBE
5308000110 5308000110 STRAP - EVAPORATOR/HEATER
5303007295 5303007295 SUPPORT RH (3)
5303205987 5303205987 SUPPORT, CRISPER COVER, ADJUSTABLE
316203400 316203400 SUPPORT,ELEMENT ,BROIL
5303288973 5303288973 SUPPORT-COVER, CRISPER
5303007297 5303007297 SUPPORT-DOOR RACK, LH
316032001 316032001 SWITCH, IGNITOR (4)
5309918806 5309918806 SWITCH-LIGHT/ LAMP
216254500 216254500 SWITCH-TERMINATION
216388600 216388600 TRAPDRAIN
215667501 215667501 TRAY,ICE CUBE ,PLASTIC
216278900 216278900 TRIVET
5303916855 5303916855 TUBE
316065003 316065003 TUBE ALUM 3/8 VALVE/REG
316065002 316065002 TUBE,VALVE TO MIXER
5303208499 5303208499 VALVE,SAFETY ,DUAL
5308000186 5308000186 WASHER , .34 X .62 X .10, NYLON
