Manufacturer
Electrolux
Model Number
PRDA1922AF1
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSY-ERF2004 MAIN PCBA+HOUSING |
|
|
BASE ASSEMBLY, COMPRESSOR, W/LEG LEVELERS |
|
|
BASE, LEVELER LEG, FRONT |
|
|
BEARING, DOOR, LOWER |
|
|
BIN, DOOR, 2 LITER |
|
|
BIN, DOOR, GALLON |
|
|
BIN, DOOR, TALL ITEMS |
|
|
BRACKET, FAN MOUNTING |
|
|
BRACKET, WATER FILTER |
|
|
CLAMP, COMPRESSOR |
|
|
CLAMP, DISPENSER TUBE, 7/16 |
|
|
CLAMP-WIRING HARNESS,STRAIN RELIEF ,GALV STEEL |
|
|
CLIP, PLASTIC, W/ADHESIVE |
|
|
CLIP, WIRING HARNESS, PLASTIC, W/ADHESIVE |
|
|
CLOSER ASSEMBLY, DOOR, RH UPPER |
|
|
COMPRESSOR, ASSEMBLY, VTH1111Y, 230V, W/GROMMETS |
|
|
CONDENSER FAN, ASSEMBLY, 29 #, W/SHROUD |
|
|
CONDENSER, DYNAMIC |
|
|
CONTROL PANEL, ASSEMBLY, W/LIGHT UI-PCB |
|
|
COVER ASSEMBLY, AIR TOWER, W/AIR DUCT |
|
|
COVER ASSEMBLY, EVAP FAN, W/AIR DUCT |
|
|
COVER ASSEMBLY, EVAPORATOR, GREY |
|
|
COVER CRISPER |
|
|
COVER, ABSORBER, 320*, ETHYLENE |
|
|
COVER, ACCESS, MACHINE COMPT. |
|
|
COVER, AIR FILTER, FRIG PRO |
|
|
COVER, DOOR CAP, GRAY, RH, CLOSER SIDE |
|
|
COVER, DRAIN JUMPER |
|
|
COVER, HINGE, RH LOWER |
|
|
COVER, REED SWITCH, GREY |
|
|
COVER, SENSOR, GREY |
|
|
DISPENSER, ASSEMBLY, WATER, W/SWITCHES |
|
|
DIVIDER-BIN 2 LITER |
|
|
DIVIDER-BIN GALLON |
|
|
DIVIDER-BIN TALL ITEM |
|
|
DIVIDER-LOWER DRAWER LH TT |
|
|
DIVIDER-LOWER DRAWER RH TT |
|
|
DOOR ASSEMBLY, COMPLETE, STAINLESS, RH SWING |
|
|
DRAIN JUMPER, ASSEMBLY, W/SEAL |
|
|
DRAWER ASSEMBLY, FULL WIDTH, LOWER, W/DIVIDERS |
|
|
DRAWER ASSEMBLY, UPPER, W/TRIM |
|
|
ELECT PUREPOUR, WF-1, WATER FILTER |
|
|
EVAPORATOR, COIL |
|
|
FILTER, AIR |
|
|
FILTER, DRIER, SERVICE |
|
|
FOOT, LEG LEVELER |
|
|
FRAME, POWER SUPPLY |
|
|
FRIG FRESHNESS BOOSTER REFILL |
|
|
GASKET, DOOR, GREY |
|
|
GROMMET, CMPRSR MTG, 34 |
|
|
HANDLE ASMY |
|
|
HARNESS ASSEMBLY, DEFROST NTC |
|
|
HARNESS, JUMPER, LED |
|
|
HARNESS, WIRING, MACHINE COMPT. |
|
|
HEATER, DEFROST |
|
|
HINGE ASSEMBLY, LOWER, RH |
|
|
HINGE, DOOR, RH UPPER |
|
|
HOSE, FILTER INLET |
|
|
HOSE, FILTER OUTLET |
|
|
INVERTER, FLEXDRIVE 2.2 |
|
|
LIGHT ASSEMBLY, LED, 1X, SINGLE, PCB, HARN, W/LENS |
|
|
LIGHT ASSEMBLY, LED, 2X UPPER, W/LENS, PCB |
|
|
LIGHT ASSEMBLY, LED, 3X, W/LENS, PCB, HARNESS |
|
|
LIGHT ASSEMBLY, LED, DISPENSER |
|
|
MANIFOLD |
|
|
MOTOR-FAN, EVAP RADIAL |
|
|
NUT, LEG LEVELER |
|
|
PAN, DRAIN |
|
|
PC BOARD, ASSEMBLY, POWER SUPPLY, W/HOUSING |
|
|
PC BOARD, LED POLARIS, 6500K |
|
|
RAIL, SHELF, SUPPORT, ASSEMBLY |
|
|
SCREW, 8-18 X .500 |
|
|
SCREW, DOOR STOP, LOWER |
|
|
SCREW, HEX HD, #8-18 X 5/8 |
|
|
SCREW, HEX WASH HD, M4 X 10 |
|
|
SCREW, HEX WASHER HEAD, 8-18 X 5/16 |
|
|
SCREW, HEX WSH HD QUAD, M5 X 16 |
|
|
SCREW, HEX WSH HD, M4.2 X 16, GREY |
|
|
SCREW, HX WASH HD, M4.2 X 12 |
|
|
SCREW, LEVELING FOOT, PLASTIC, ADJUSTABLE |
|
|
SCREW, QUAD HILO, #8-18 X 0.380 |
|
|
SCREW, QUAD HILO, 4.2X1.41X15.9, SLIDE MTG |
|
|
SCREW, SHOULDER, #8-18 X 5/8 |
|
|
SCREW, SHOULDER, M4.2 HI-LO QDRX |
|
|
SCREW,CONTROL MTG. |
|
|
SCREW-SET,10-32 X 0.650 |
|
|
SEAL, DRAIN PAN, FOAM |
|
|
SENSOR, MAGNET, SWITCH, REED |
|
|
SHELF ASSEMBLY, GLASS, W/TRIM |
|
|
SHELF ASSEMBLY, SLIDE OUT, W/GLASS |
|
|
SLIDE ASSEMBLY, 8 INCH, GREY, LH |
|
|
SLIDE ASSEMBLY, 8 INCH, GREY, RH |
|
|
SLIDE ASSEMBLY, 9 INCH, GREY, LH |
|
|
SLIDE ASSEMBLY, 9 INCH, GREY, RH |
|
|
SPACER, SHELF/WTR TUBE |
|
|
STOP, DOOR, LOWER BEARING |
|
|
STRAP-EVAP/HEATER, ALUMINUM, (2) |
|
|
SUPPORT, EVAPORATOR, LH |
|
|
SUPPORT, EVAPORATOR, RH |
|
|
SUPPORT, WATER FILTER |
|
|
THERMISTOR KIT, TEMPERATURE, NTC, W/CONNECTORS |
|
|
TROUGH, DRAIN, EVAPORATOR |
|
|
TUBE, DRAIN, EXTENSION |
|
|
TUBE, SUCTION JUMPER |
|
|
TUBE, WATER, DISPENSER |
|
|
VALVE, WATER, TRIPLE SOLENOID |
|
|
WIRE TIE |
|
|
WRENCH |
