Model Image
Manufacturer

Electrolux

Model Number

SM230PXW3

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
3161076 3161076 BAFFLE-DRUM
3016466 3016466 BASE
3204405 3204405 BEARING,OUTER TUB
5303161099 5303161099 BELT
3205019 3205019 BLOCK
3205035 3205035 BRACKET
5303284141 5303284141 BRACKET
3016464 3016464 BRACKET NLA
3017901 3017901 BRACKET-DRUM-RH
3204981 3204981 BUMPER
5303131079 5303131079 BURNER ASSY-TOP,REAR
5303204154 5303204154 BURNER-TOP FRONT
5308004087 5308004087 BUZZER
5303208455 5303208455 CHANNEL-LINT-HSG.
5364154013 5364154013 CLAMP
3016472 3016472 CLAMP
3204456 3204456 CLAMP-HOSE COUPLER
5308002293 5308002293 CLIP
5303283052 5303283052 CLIP-SHIELD
5308015078 5308015078 COUPLING
3205029 3205029 COVER-TUB
3204999 3204999 DIAL
3204983 3204983 DISPENSER
3204951 3204951 DUCT-REAR
5308015778 5308015778 GASKET
5303209445 5303209445 GASKET
5373565000 5373565000 GASKET-AGIT.CAP
5303208743 5303208743 GROMMET-HINGE
3205013 3205013 GUIDE
5303285455 5303285455 HANDLE
5303161050 5303161050 HEATER
131658100 131658100 HEATER-THERMOSTAT
3204959 3204959 HINGE
5303292372 5303292372 HOSE-DRAIN
5303283078 5303283078 HOSE-PUMP TO TUB
5303209767 5303209767 HOUSING-BLOWER
5303280324 5303280324 HUB-DRIVE
3205948 3205948 KNOB-ROTARY
3205947 3205947 KNOB-TIMER
3205033 3205033 LIDLOCK
3161203 3161203 NUT
5303016473 5303016473 NUT-STRAIN RELEIF
3005242 3005242 OIL-TRANSMISSION
5303917590 5303917590 PAN-DEFROST DRAIN, ORIG COMPRESSOR (IF COMPRESSOR HAS BE
5303207100 5303207100 PANEL
3204973 3204973 PANEL-FRONT
3204961 3204961 PANEL-FRONT NLA
3017111 3017111 PANEL-REAR
3016426 3016426 PANEL-VENTILATION
3016440 3016440 PIN
5303161227 5303161227 PIN
137107000 137107000 PLATE,LOCK
3016442 3016442 PLATE-STRIKE
5303161224 5303161224 PLUG-PIPE
5303211473 5303211473 PULLEY-MOTOR
5303292169 5303292169 PUMP -COMPLETE
5308015784 5308015784 RESISTOR
5303204987 5303204987 RETAINER-DRAIN HOSE
5303161307 5303161307 RETAINING RING
5303161223 5303161223 RETAINING RING (2)
5308015536 5308015536 RING
3161255 3161255 RING-RETAINER
3161237 3161237 RIVET
5303161187 5303161187 SCREW
3204368 3204368 SCREW
3161240 3161240 SCREW
3204269 3204269 SCREW
3205016 3205016 SCREW
3161274 3161274 SCREW
5303010202 5303010202 SCREW
5303283080 5303283080 SCREW
3205020 3205020 SCREW
5303206869 5303206869 SCREW
3205150 3205150 SCREW,TUB BEARING ,8-12B X 0.750
5303211089 5303211089 SCREW-HINGE LID
5303270023 5303270023 SCREW-SET
5303283072 5303283072 SCREW-SHIELD
5303283293 5303283293 SCREW-TRUNNION,UNC2AX.625 `.312-18
5303286418 5303286418 SEAL
5303161173 5303161173 SEAL
5308950197 5308950197 SEAL, TUB
5308004076 5308004076 SHAFT-DRUM
5308014905 5308014905 SHAFT-LOWER
5303283071 5303283071 SHIELD
5303161182 5303161182 SLEEVE
5303272073 5303272073 SLINGER WASHER
5308002385 5308002385 SNUBBER RING ASSY
5303207426 5303207426 SPACER
5308015493 5308015493 SPACER,TIMER SHAFT
5303161199 5303161199 SPEED CLIP (8)
5308015828 5308015828 SPRING
5303161133 5303161133 SPRING
5303161174 5303161174 SPRING
5308006573 5308006573 SPRING-HORIZONTAL
5308002456 5308002456 SPRING-TENSION
5303161131 5303161131 SPRING-VERTICAL-SHO
5303161300 5303161300 STRAP
3161250 3161250 STRAP-DRAIN HOSE
5303161221 5303161221 STUD BOLT
5303283054 5303283054 SUPPORT
5303935086 5303935086 SWITCH,ELEMENT ,6``
5303293588 5303293588 SWITCH-MOTOR
5303017895 5303017895 SWITCH-TEMP.
5379171000 5379171000 TERMINAL
5303211472 5303211472 THERMAL LIMITER
5308015856 5308015856 THERMOSTAT-SAFETY
5308015847 5308015847 THERMSTAT-CONTROL
3205944 3205944 TIMER
5303289594 5303289594 TIMER-WASHER
131033000 131033000 TUB-SPLASH
5300771996 5300771996 TUBE-PRESSURE
5303280326 5303280326 V-BELT
5308027515 5308027515 VALVE-CHECK
5308014555 5308014555 VALVE-CHECK
5308057430 5308057430 WASHER
5363602000 5363602000 WASHER
5308002468 5308002468 WASHER
5303161296 5303161296 WASHER,INLET HOSE
5308002401 5308002401 WASHER,SPIN BEARING ,UPPER
5303161306 5303161306 WASHER,SPRING TYPE
5303161226 5303161226 WASHER-THRUST
5303209769 5303209769 WHEEL - BLOWER
5303286384 5303286384 WHEEL,UPPER RACK
