Model Image
Manufacturer

Electrolux

Model Number

TGO336BFD1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
316099800 316099800 BALLAST-LAMP
5303289320 5303289320 BEARING, HINGE
3204405 3204405 BEARING,OUTER TUB
3018603 3018603 BRACKET
316091600 316091600 BRACKET
316066301 316066301 BRACKET-HINGE
3131275 3131275 BUKB-FLUORESCENT
5303131634 5303131634 BURNER-OVEN
3200502 3200502 BURNER-OVEN
316057100 316057100 BURNER-TOP (4)
5308010401 5308010401 BUSHING-CONTROL PAN
5303290772 5303290772 CHANNEL
316007001 316007001 CHANNEL, DOOR HINGE (2)
3131153 3131153 CHANNEL-BROILER
3011813 3011813 CLIP
5303284616 5303284616 CLIP-THERMOSTAT
316090000 316090000 CLOCK/TIMER
5303212918 5303212918 CONTAINER-ICE,34,FOR 178675-0
5303015372 5303015372 COVER
3131570 3131570 COVER
5303943073 5303943073 DISPENSER ASSY
3201150 3201150 END CAP-SHELF,PROTECTOR ,FRZR SHELF
3131387 3131387 FASTENER-SPACER
3131904 3131904 FLUE
3200505 3200505 FLUE
215357609 215357609 FRONT-CRISPER PAN
215357813 215357813 FRONT-MEAT PAN
131901400 131901400 GASKET-TUB COVER
316088600 316088600 GLASS,OVEN DOOR ,INNER
3018610 3018610 GLIDE, BROILER (6)
316084503 316084503 GRATE,BLACK ,(4)
218971202 218971202 HANGER-MEAT PAN,LH
218971302 218971302 HANGER-MEAT PAN,RH
5303051166 5303051166 HINGE-OVEN DOOR
5303290130 5303290130 HINGE-OVEN DOOR
5303200508 5303200508 IGNITER-OVEN
5303935066 5303935066 IGNITOR,OVEN KIT ,W/NUT & INSTR
316081701 316081701 IGNITOR-TOP BURNER,50``
5303281398 5303281398 INSERT-PAN COVER,24.60`` X 12.75`` ,GLASS
3017142 3017142 INSULATION
316029008 316029008 KNOB-CLOCK
316023020 316023020 KNOB-CONTROL
5303275221 5303275221 KNOB-TEMP CONTROL
316019165 316019165 KNOB-THERMOSTAT
316019161 316019161 KNOB-THERMOSTAT,UPPER
318090310 318090310 LATCH
5308037896 5308037896 LIGHT/LAMP
316066610 316066610 LINER
3131455 3131455 MAIN TOP
316066201 316066201 MANIFOLD PIPE
3013279 3013279 NUT
5303288460 5303288460 NUT
3131386 3131386 NUT
5303013272 5303013272 NUT, BAFFLE
3206438 3206438 PAN, CRISPER (2)
316011403 316011403 PAN-BURNER-SQUARE
3204424 3204424 PIN - ROLL
3018614 3018614 PIN-HINGE
318116701 318116701 PLATE
3018607 3018607 PLATE
137107000 137107000 PLATE,LOCK
3206216 3206216 PLUG-BUTTON
3204423 3204423 PULLEY MOTOR
316067902 316067902 RACK,OVEN
5303282715 5303282715 RECEPTACLE-STARTER
5303208612 5303208612 REFLECTOR
316091706 316091706 REGULATOR,PRESSURE
3016993 3016993 RETAINER
3205396 3205396 RETAINER
3200519 3200519 RETAINER
3161433 3161433 RING,RETAINING
316066900 316066900 ROD
316021108 316021108 SCREW
316089500 316089500 SCREW
316048200 316048200 SCREW
5303211311 5303211311 SCREW
316116000 316116000 SCREW
316021105 316021105 SCREW
3131732 3131732 SCREW
5303285179 5303285179 SCREW
218188000 218188000 SCREW, PAN HD, 10-32X0.625, HINGE/MULL, THRD FORM
215005101 215005101 SCREW,HANGER/RLR MTG ,8-10 X 0.438
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
3205150 3205150 SCREW,TUB BEARING ,8-12B X 0.750
316001001 316001001 SCREW-HANDLE MTG
5303203397 5303203397 SCREW-LEVELING
3204396 3204396 SEAL,AGITATOR CAP
5303202011 5303202011 SEAL,OVEN DOOR ,NON SELF CLEAN
5303001449 5303001449 SEAL-AIR DEFLECTOR, FOAM PLASTIC
316055500 316055500 SHIELD
3204426 3204426 SLEEVE,IDLER PIVOT
3014099 3014099 SPACER
5303299664 5303299664 SPACER,SHELF
3204425 3204425 SPRING,TORSIONAL
134885900 134885900 SPRING,VERTICAL
134886600 134886600 SPRING,VERTICAL ,SHORT
3018619 3018619 SPRING-BROILER
3206218 3206218 STARTER-LAMP
5303935001 5303935001 STRIKE-DOOR
316064600 316064600 SUPPORT
5303205987 5303205987 SUPPORT, CRISPER COVER, ADJUSTABLE
5308015487 5308015487 SWITCH
316032000 316032000 SWITCH-IGNITOR,(4)
5309918806 5309918806 SWITCH-LIGHT/ LAMP
5303269995 5303269995 THERMOSTAT-OVEN
5303269996 5303269996 THERMOSTAT-OVEN
215667501 215667501 TRAY,ICE CUBE ,PLASTIC
316067802 316067802 TRIM
316084301 316084301 TRIM-VENT
5304466677 5304466677 TRUNION
316065005 316065005 TUBE
316065003 316065003 TUBE ALUM 3/8 VALVE/REG
218731104 218731104 TUBE, PVC, WHITE @ AIR DEFLECTOR, INSULATOR
316051402 316051402 TUBE-BURNER
316051403 316051403 TUBE-BURNER
316051400 316051400 TUBE-BURNER
316051401 316051401 TUBE-BURNER
316065001 316065001 TUBING-MIXER
5303208499 5303208499 VALVE,SAFETY ,DUAL
316098701 316098701 VALVE-TOP BURNER
5303161296 5303161296 WASHER,INLET HOSE
5303261031 5303261031 WASHER,PIVOT SHAFT
5308002401 5308002401 WASHER,SPIN BEARING ,UPPER
5303161306 5303161306 WASHER,SPRING TYPE
316008401 316008401 WASHER`3/4 OD X 1/4 ID ,STEEL
