Model Image
Manufacturer

Electrolux

Model Number

UL5000ECW5

Description

Freezer

Interactive Exploded View
Exploded View

Parts List

Part Number Description
216269500 216269500 ADAPTER
216157200 216157200 BASKET
216443600 216443600 BEARING
216603300 216603300 BREAKER KIT W/CORNE
216603600 216603600 BREAKER KIT W/CORNE
216604100 216604100 BREAKER KIT W/CORNE
5305878546 5305878546 BUMPER-BASKET
3201513 3201513 CLIP
216273000 216273000 CLIP
5303212828 5303212828 CLIP,PANEL MTG ,(1)
216731900 216731900 CLIPCONTROLLER
5300083897 5300083897 CONDENSER
216649309 216649309 CONTROLLER
5303288184 5303288184 COVER-CONTROL HOUSI
5308005500 5308005500 DRAIN
3206044 3206044 END CAP
297286000 297286000 EVAP SHELF MIDDLE
216396900 216396900 FOOT-ADJUSTABLE
216522312 216522312 GASKET-DOOR
08009560 08009560 GLIDE-BASKET,(4)
216498900 216498900 GROMMET
216225700 216225700 GROMMETSPACER
216762900 216762900 HARNESSWIRING
216468300 216468300 HEAT EXCHANGER
216313502 216313502 HOSEDRAIN
5303294372 5303294372 NUT-INSERT
216528103 216528103 PANEL-INNER DOOR
216502600 216502600 PLUG
216403700 216403700 PLUGBUTTON
216503300 216503300 RAMP
5300119930 5300119930 RETAINER-HANDLE
5303272328 5303272328 SCREW
216022800 216022800 SCREW
216036601 216036601 SCREW
216313000 216313000 SCREW
216138900 216138900 SCREW
5300052943 5300052943 SCREW-CLAMP
216858001 216858001 SCREW-SUPPORT
216077201 216077201 SHELFDRY
5308002706 5308002706 SIGNAL-LIGHT-AMBER
5306594529 5306594529 SLEEVE-COMPRESSOR
5300136117 5300136117 SOCKET-LIGHT/LAMP
3201514 3201514 SOLENOID 302605
216474600 216474600 SUPPORT-REAR SHELF
5303212703 5303212703 SWITCH-ROCKER
216380500 216380500 SWITCHDEFROST
297048400 297048400 USE 297048400
5309950074 5309950074 VALVE
