Model Image
Manufacturer

Goodman

Model Number

GCVC960804CN

Description

96% Ecm Counterflow Furna Comfortnet Counterflow 0

Interactive Exploded View

Parts List

Part Number Description
0121F00315 0121F00315 ANGLE, DECK
0121F00313 0121F00313 ANGLE, SIDE
0270F03139 0270F03139 BAG ASSY CF
0163F00017 0163F00017 BECKETT BURNER
A4002702 A4002702 BLOWER MOTOR GROMMET
0271F00161 0271F00161 BLOWER SHELL WHEEL ASSY
0121F00389 0121F00389 BRACKET, DOOR SWITCH
0121F00454 0121F00454 BRACKET-BURNER 4
M0570808 M0570808 BUTTON PLUG
M0570807 M0570807 BUTTON PLUG
M0570806 M0570806 BUTTON PLUG
M0310345 M0310345 BUTTON PLUG
A1781105 A1781105 CAP-VINYL .500
0270F03515 0270F03515 CF DRAIN TUBE ASSY
0270F03126 0270F03126 CF DRAIN TUBE ASSY
0163M00049 0163M00049 CLAMP HOSE
0259F00040 0259F00040 CONTROL HARNESS
0161F00037 0161F00037 COUPLING
0121F00318 0121F00318 COVER, REAR
0130F00381 0130F00381 DATA, FURNACE PCB
0154F00021 0154F00021 DECK GASKET
0121F00433 0121F00433 DECK-BLOWER, 21-INCH CF
0121F00292DG 0121F00292DG DOOR, ACCESS 21 PNT
0121F00289DG 0121F00289DG DOOR, BLOWER 21 PNT
0270F03141 0270F03141 DRAIN PART BAG ASSY CF
0161F00046 0161F00046 DRAIN TRAP
0164F00004 0164F00004 ELBOW-FLUE, 21-INCH CFLOW
0130F00010 0130F00010 FLAME SENSOR
M0274008 M0274008 FLAT WASHER
0161F00030 0161F00030 FRONT COVER
0151M00027 0151M00027 GAS VALVE
0154F00025 0154F00025 GASKET
0154F00024 0154F00024 GASKET
0154F00016 0154F00016 GASKET
0154F00015 0154F00015 GASKET
0154F00012 0154F00012 GASKET, FRONT
0154F00009 0154F00009 GASKET, REAR CVR
20179310 20179310 GASKET-FA
0161F00000P 0161F00000P GOODMAN NAMEPLATE
0159F00051 0159F00051 HARNESS-WIRING
0257F00359 0257F00359 HEAT EXCHANGER ASSY
0164M00019 0164M00019 HOSE-PRESSURE SW 6-INCH
0130F00008 0130F00008 IGNITOR-SINI 17 SEC
0130M00141 0130M00141 INDUCTOR, 5.9 AMPS GMPE100-4
0160F00016 0160F00016 INSULATION, HT EXCHANGER 21-INCH
0160F00018 0160F00018 INSULATION, SIDE
0160F00013 0160F00013 INSULATION-BACK 21-INCH
10690402 10690402 INTERLOCK SWITCH
0161F00043 0161F00043 JUNCTION BOX LID
0161F00042 0161F00042 JUNCTION BOX PLA
M0282015 M0282015 KEPS NUT
M0267144 M0267144 MACHINE SCREW
0130F00123 0130F00123 MANUAL RESET LIMIT
10441501 10441501 MOTOR MOUNT ARM
10441601 10441601 MOTOR MOUNT BAND
0131M00271 0131M00271 MOTOR, 3/4 HP, SERIAL ECM
0171M00002 0171M00002 MOTOR-ID, BLOWER
0121F00464 0121F00464 MOUNTING PLATE-CONTROLS
0163F00004 0163F00004 ORIFICE
0121F00467 0121F00467 ORIFICE BURNER BRACKET 4B
0121F00435DG 0121F00435DG PAINTED BASE PAN-21-INCH C
PCBKF104 PCBKF104 PCB, CONTROL, FURNACE
M0501301 M0501301 PIPE GROMMET
0161F00064 0161F00064 PIPE, STRAIGHT CF
B1392021 B1392021 PLASTIC PLUG, 1-INCH 2713-BLK
0161M00027 0161M00027 PLUG, HOLE
0259F00041 0259F00041 POWER HARNESS HIGH VOLTAGE
0130F00474 0130F00474 PRESSURE SWITCH -.72 / -1.47
0130F00038 0130F00038 PRIMARY LIMIT - LT BLUE 120 AUX
0121F00439 0121F00439 PRIMARY LIMIT-HEAT SHIELD
20162904 20162904 PRIMARY LIMIT-TEMPERATURE CONTROL
0121F00355 0121F00355 SHIELD, COIL
0130F00481 0130F00481 SWITCH, PRESSURE
M0221461 M0221461 TC SCREW
0121F00434DG 0121F00434DG TOP, PAINTED FURNACE 21-INCH CF
0130M00140 0130M00140 TRANSFORMER 120V TO 24V, 40VA
M0326804 M0326804 TUBE PLUG
B1392104 B1392104 UNIVERSAL BUSHING UB 875
B1392139 B1392139 VIEW PORT BUSHING-BLOWER DOOR
B1392820 B1392820 WASHER, SPLIT LOCK 1/4 BZ
0259F00024 0259F00024 WIRE HARNESS-BLOWER
