Manufacturer
Goodman
Model Number
GMES920603BNAA
Description
92% Afue 60000 Btu Gas Furnace Heater
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
*PRIMARY LIMIT-TEMPERATURE CONTROL (M8) |
|
|
ANGLE, DECK (M2, M3) |
|
|
BAFFLE, AIR FURN |
|
|
BASEPAN, 17.5 (M2, M3) |
|
|
BECKETT BURNER (QTY 2) |
|
|
BLOWER BLOCK-OFF 10 X 8 (M2, M3) |
|
|
BLOWER HSG ASSY (M2, M3) |
|
|
BRACKET, DOOR SWITCH |
|
|
BRACKET-BURNER 3 (M2) |
|
|
BUTTON PLUG |
|
|
BUTTON PLUG |
|
|
BUTTON PLUG (QTY 2) |
|
|
BUTTON PLUG (QTY 3) |
|
|
CAP-VINYL .500 |
|
|
CIRCUIT BOARD |
|
|
CLAMP-HOSE (QTY 2) |
|
|
COUPLING |
|
|
COUPLING, HOSE BARBED |
|
|
COVER, FRONT (M2) |
|
|
COVER, REAR (M2, M3) |
|
|
DECK-BLOWER 17.5" (M2, M3) |
|
|
DOOR, ACCESS 17.5 PNT (M2, M3) |
|
|
DOOR, BLOWER 17.5 PNT (M2, M3) |
|
|
DRAIN KIT ASSY UF |
|
|
DRAIN TRAP |
|
|
ELBOW-FLUE, UPFLOW |
|
|
FLAME SENSOR |
|
|
FLUE PIPE W/BEND |
|
|
FRESH AIR GASKET (QTY 2) |
|
|
GAS VALVE |
|
|
GASKET (M2, M3) |
|
|
GASKET (QTY 2) |
|
|
GASKET (QTY 2) |
|
|
GASKET (QTY 2) |
|
|
GASKET FRONT COVER (M2, M3) |
|
|
GASKET, DECK (M2, M3) |
|
|
GASKET, ID BLOWER |
|
|
GASKET, REAR CVR (M2, M3) |
|
|
HARNESS, WIRING (M1, M2, M3) |
|
|
HEAT EXCHANGER ASSY (M2) |
|
|
HEX HEAD ALL THREAD TAP BOLT |
|
|
HEX NUT-INSERT (QTY 3) |
|
|
HOSE, COVER/TRAP (M2, M3, M4, M5, M6, M7, M8) |
|
|
HOSE-ELBOW/TRAP |
|
|
IGNITOR-SINI 17 SEC |
|
|
INSULATION, HT EXCHANGER 17.5" (M2, M3) |
|
|
INSULATION, RETAINER (M2, M3) |
|
|
INTERLOCK SWITCH |
|
|
JUNCTION BOX LID |
|
|
JUNCTION BOX PLA |
|
|
LIMIT, PRIMARY, 180, PINK (M2, M4) |
|
|
LOCKNUT, NYLON, INSERT 1/4,20 |
|
|
MANIFOLD (M2) |
|
|
MANUAL RESET LIMIT - ROS (M2) |
|
|
MOTOR X-13, BLOWER 1/2 H.P. (M1, M2, M3) |
|
|
MOTOR X-13, BLOWER 3/4 H.P. |
|
|
MOTOR, PROGRAM-X13 (M2) |
|
|
MOTOR-ID, BLOWER (M2, M3, M4, M5, M6, M7, M8) |
|
|
MOUNT ARM, MOTOR (HEAVY DUTY) (QTY 3) |
|
|
MOUNT BAND, MOTOR (HEAVY DUTY) |
|
|
MOUNTING PLATE-CONTROLS |
|
|
NAMEPLATE, GOODMAN |
|
|
ORIFICE (QTY 2) |
|
|
ORIFICE BRACKET-BURNER 3 (M2) |
|
|
PAINTED TOP, FURNACE 17.5 (M2, M3) |
|
|
PIPE GROMMET |
|
|
PLASTIC PLUG, 1" (2713-BLK) (QTY 4) |
|
|
PLUG, HOLE (M1, M2, M3, M6, M7) |
|
|
PLUG-TUBE |
|
|
PRESSURE SWITCH (M2, M4, M5, M8) |
|
|
PRESSURE SWITCH HOSE |
|
|
PRESSURE SWITCH HOSE (M2, M3, M4, M5, M6, M7, M8) |
|
|
PRIMARY LIMIT - LT BLUE 120 (QTY 2) |
|
|
PRIMARY LIMIT-HEAT SHIELD |
|
|
RETAINER-SCREW (QTY 3) |
|
|
SCREW-DECORATIVE (QTY 3) |
|
|
SCREW-TC 1.25" (QTY 3) |
|
|
SHEILD, BURNER (M2) |
|
|
SHIELD, COIL (QTY 2) |
|
|
SIDE ANGLE (QTY 2) |
|
|
TRANSFORMER 120V TO 24V, 40VA |
|
|
UNIVERSAL BUSHING UB 875 |
|
|
VIEW PORT BUSHING-BLOWER DOOR (QTY 2) |
|
|
WASHER, FLAT 1/4 ID X 1 OD (QTY 3) |
|
|
WHEEL, BLOWER (10 X 8) (M2, M3) |
|
|
WIRING HARNESS |
