Manufacturer
Goodman
Model Number
GMV80703BXA
Description
Gas Furnace
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACCESS DOOR 17.5-INCH |
|
|
AUXILIARY LIMIT, AUTO RESET |
|
|
BLOWER BLOCK-OFF 10 X 8 |
|
|
BLOWER DOOR 17.5-INCH |
|
|
BLOWER HOUSING 10 X 8 |
|
|
BLOWER WHEEL 10 X 8 |
|
|
BOARD, HSI, 2-STAGE MINI |
|
|
BOX, FLUE COLLECTOR 1.75-INCH DIA. 17.5-INCH |
|
|
BURNER BOX TOP 3 CELL |
|
|
BURNER RACK 3 CELL |
|
|
CHIMNEY ASSEMBLY |
|
|
CONTROL MOUNT PANEL |
|
|
DOOR SWITCH |
|
|
ECM MTR POWER HARNESS |
|
|
FLAME SENSOR |
|
|
GAS MANIFOLD 3 CELL |
|
|
GAS VALVE - WHITE-RODGERS 2-STAGE |
|
|
HOMEOWNER'S INSTRUCTIONS |
|
|
IGNITOR |
|
|
INDUCTOR-5.9 AMP |
|
|
INSERT-MESH TUBES, 5 CELL |
|
|
INSHOT BURNER ASSY 3-INCH |
|
|
INSTALLATION INSTRUCTIONS |
|
|
J-BOX COVER |
|
|
JUNCTION BOX |
|
|
LOCKNUT, NYLON, INSERT 1/4, 20 |
|
|
MACHINE SCREW HWH 1/4-20 X 1-1/2 BZ |
|
|
MOTOR MOUNT ARM |
|
|
MOTOR MOUNT BAND |
|
|
MOTOR, 3/4 HP |
|
|
ORIFICE |
|
|
ORIFICE SHIELD 3 CELL |
|
|
PRESSURE SWITCH HOSE |
|
|
PRIMARY LIMIT SWITCH 170 F |
|
|
REPAIR PARTS MANUAL |
|
|
ROLLOUT SWITCH BRACKET |
|
|
ROLLOUT SWITCH, 300 W/O BRACKET |
|
|
SCREW, 1/4 X 1-1/2, A, BZ, SLOT |
|
|
SIDE PLATE, BURNER BOX |
|
|
SPRAY TOUCH-UP PAINT, ARCH. GRAY DARK |
|
|
SUB-ASSY, HEAT EXCHANGER 3 CELL, 17.5-INCH |
|
|
SWITCH, AIR PRESSURE 2-STAGE |
|
|
TECHNICAL MANUAL |
|
|
TOP 17.5-INCH |
|
|
TRANSFORMER 120V TO 24V, 40 VA |
|
|
VENT MOTOR GASKET 17.5-INCH |
|
|
VENT MOTOR, 2-STAGE |
|
|
VIEW PORT BUSHING-BLOWER DOOR |
|
|
WARRANTY CERTIFICATE |
|
|
WASHER, FLAT 1/4 ID X 1 OD |
|
|
WASHER, SPLIT LOCK 1/4 BZ |
|
|
WIRING HARNESS ECM INTERFACE 16 PIN CONNECTOR |
|
|
WRAPPER/INSULATION ASM.,17.5-INCH |
