Manufacturer
Goodman
Model Number
HDP241B
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
5/8 SERVICE VALVE |
|
|
BOTTOM PAN ASSEMBLY |
|
|
BRACKET, FAN MOTOR, 25 |
|
|
BRACKET, VALVE |
|
|
CAPACITOR 35U/5U/370V |
|
|
COMPRESSOR GROMMET |
|
|
COMPRESSOR, 208/230-60-1, BRISTOL H29B24UABCB |
|
|
CONTACTOR, 25 AMP, 125 LRA, 1 POLE, 208/240 V COIL |
|
|
CONTROL PANEL |
|
|
FAN BLADE 18-INCH |
|
|
FAN GRILL GUARD 18-INCH |
|
|
FILTER DRIER |
|
|
FLOWRATOR .071 |
|
|
HANDLE, PLASTIC, LEFT, BLACK |
|
|
HANDLE, PLASTIC, RIGHT, BLACK |
|
|
INSTALLATION INSTRUCTIONS |
|
|
MOTOR, 208/230-60-1, 1 SPD, 900 RPM, 1/15 HP |
|
|
MUFFLER 3/8 X 3/8 |
|
|
PANEL, BACK GRILLE, 25 |
|
|
PANEL, COMPRESSOR END, 25 |
|
|
PANEL, FRONT, 25.0 |
|
|
PANEL, PARTITION, 25 |
|
|
PANEL, TOP |
|
|
REPAIR PART MANUAL |
|
|
SPECIFICATION SHEET |
|
|
SPRAY TOUCH-UP PAINT, ARCH. GRAY DARK |
|
|
TERMINAL BLOCK |
|
|
THERMISTOR SENSOR |
|
|
TUBING ASSY, COND COIL |
|
|
VALVE, BASE, LIQUID LINE, 3/8, PISTON .059 |
|
|
VALVE, REVERSING |
