Model Image
Manufacturer

Haier

Model Number

AH183

Description

18000 Btu Heat Cool 9.7 Eer

Interactive Exploded View

Parts List

Part Number Description
AC-0200-04 AC-0200-04 BAR-VERT LOUVER GANG
AC-0010-21 AC-0010-21 BRACKET-MOTOR (1)
AC-1400-243 AC-1400-243 CAPACITOR-COMPRESSOR
AC-1470-13 AC-1470-13 CASE-SCROLL
AC-1650-48 AC-1650-48 CLIP
AC-1650-16 AC-1650-16 CLIP-CAPACITOR
WJ01X23351 WJ01X23351 CLIP-THERMO-INDUCTIO
AC-1800-24 AC-1800-24 CONDENSER
AC-1950-41 AC-1950-41 COVER-CONDENSER
AC-1950-34 AC-1950-34 COVER-ELECTRIC BOX
AC-2015-26 AC-2015-26 CUSHION
AC-2015-27 AC-2015-27 CUSHION
AC-2300-07 AC-2300-07 DOOR-VENT
AC-2600-04 AC-2600-04 ESCUTCHEON
AC-2650-26 AC-2650-26 EVAPORATOR
AC-2750-23 AC-2750-23 FAN-BLOWER WHEEL
AC-3100-87 AC-3100-87 GASKET
AC-3300-13 AC-3300-13 GUIDE-TOP
AC-5150-15 AC-5150-15 PAN-DRAIN
AC-5200-29 AC-5200-29 PANEL-BACK
AC-5200-30 AC-5200-30 PANEL-EVAPORATOR PAR
AC-5255-98 AC-5255-98 PIPE-COOLING
AC-5255-99 AC-5255-99 PIPE-SUCTION
AC-5255-97 AC-5255-97 PIPE-SUCTION
AC-5255-84 AC-5255-84 PIPE-SUCTION ASSY
AC-5300-19 AC-5300-19 PLATE-COVER
AC-5550-11 AC-5550-11 RAIL-BOTTOM
AC-5950-07 AC-5950-07 ROD-CONNECTING
AC-6150-54 AC-6150-54 SCREW
AC-6150-11 AC-6150-11 SCREW
AC-6150-14 AC-6150-14 SCREW-10MM
AC-6150-55 AC-6150-55 SCREW-BOTTOM
AC-6899-02 AC-6899-02 STOP
AC-7350-08 AC-7350-08 THERMOSTAT
