Model Image
Manufacturer

Haier

Model Number

CJ70E

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0255-19 AC-0255-19 BASEPAN
AC-0600-16 AC-0600-16 BLOWER-WHEEL
AC-0800-142 AC-0800-142 BOX-ELECTRIC
AC-0850-126 AC-0850-126 BRACKET-METAL
AC-0990-014 AC-0990-014 BUCKET
AC-1400-163 AC-1400-163 CAPACITOR-40UF 300V
AC-1400-164 AC-1400-164 CAPACITOR-6UF 250V
AC-1405-35 AC-1405-35 CAPILLARY
AC-1480-58 AC-1480-58 CASING-FAN FRONT
AC-1480-57 AC-1480-57 CASING-FAN REAR
WJ01X22291 WJ01X22291 CASTER
AC-1750-214 AC-1750-214 COMPRESSOR
AC-1800-166 AC-1800-166 CONDENSER-ASSEMBLY
AC-1900-59 AC-1900-59 CORD-POWER
AC-1950-344 AC-1950-344 COVER
AC-1950-346 AC-1950-346 COVER
AC-1950-348 AC-1950-348 COVER
AC-1950-345 AC-1950-345 COVER-CONTROL PANEL
AC-1950-427 AC-1950-427 COVER-DRAIN BUCKET
AC-1950-350 AC-1950-350 COVER-LIGHT
AC-2650-136 AC-2650-136 EVAPORATOR-ASSEMBLY
AC-2800-144 AC-2800-144 FILTER-AIR
AC-2868-06 AC-2868-06 FOAM-FLOAT
AC-3150-176 AC-3150-176 GRILL
AC-3350-42 AC-3350-42 HANDLE
AC-3350-43 AC-3350-43 HANDLE
AC-3350-41 AC-3350-41 HANDLE-TANK
AC-3500-169 AC-3500-169 HOLDER
AC-3500-168 AC-3500-168 HOLDER
WJ71X24133 WJ71X24133 HOSE-DRAIN
AC-4000-054 AC-4000-054 KNOB
AC-4000-053 AC-4000-053 KNOB
AC-4550-307 AC-4550-307 MOTOR-FAN
AC-5210-136 AC-5210-136 P.C.B.-CONTROL
AC-5210-137 AC-5210-137 P.C.B.-KEYPAD
AC-5200-601 AC-5200-601 PANEL
AC-5200-576 AC-5200-576 PANEL
AC-5200-575 AC-5200-575 PANEL-REAR
AC-5300-48 AC-5300-48 PLATE-METAL
WJ01X24010 WJ01X24010 PLUG-DRAIN
AC-5310-28 AC-5310-28 PLUG-DRAIN
AC-5550-20 AC-5550-20 RAIL
AC-5550-21 AC-5550-21 RAIL
AC-6250-36 AC-6250-36 SENSOR
AC-6250-35 AC-6250-35 SENSOR
WJ27X22317 WJ27X22317 SWITCH
AC-7250-04 AC-7250-04 TANK-FLOAT
AC-7550-34 AC-7550-34 TRANSFORMER
AC-7750-307 AC-7750-307 TUBE
AC-7750-216 AC-7750-216 TUBE-DISCHARGE
AC-7750-215 AC-7750-215 TUBE-SUCTION
AC-7750-217 AC-7750-217 TUBE-SUCTION
WJ71X24132 WJ71X24132 WASHER
