Model Image
Manufacturer

Haier

Model Number

CWDH11W

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WD-0100-03 WD-0100-03 ARM - CAM FOLLOWER
WD-0100-02 WD-0100-02 ARM-DIVERTER PIVOT 1
WD-0100-04 WD-0100-04 ARM-DIVERTER PIVOT 1
WD-0100-01 WD-0100-01 ARM-OPERATING
WD-0350-04 WD-0350-04 BELT-V (LONG - V1245
WD-0595-01 WD-0595-01 BLOCK-TERMINAL
WD-0700-01 WD-0700-01 BODY
WD-0700-02 WD-0700-02 BODY - FILTER
WD-0750-09 WD-0750-09 BOLT
WD-0750-10 WD-0750-10 BOLT
WD-0750-13 WD-0750-13 BOLT-ASSY
WD-0750-15 WD-0750-15 BOLT-ASSY
WD-0750-14 WD-0750-14 BOLT-HEX-HEAD
WD-0750-12 WD-0750-12 BOLT-MOTOR
WD-0850-12 WD-0850-12 BRACKET - CAPACITOR
WD-0850-13 WD-0850-13 BRACKET - TUB YOKE
WD-0850-14 WD-0850-14 BRACKET-HOSE
WD-0850-15 WD-0850-15 BRACKET-OUTLET HOSE
WD-0850-40 WD-0850-40 BRACKET-YOKE W/BEARI
WD-1050-01 WD-1050-01 BULB - INDICATOR
WD-1150-04 WD-1150-04 BUSHING-PULLEY
WD-1150-01 WD-1150-01 BUSHING-RUBBER
WD-1150-02 WD-1150-02 BUSHING-VIBRATION
WD-1200-01 WD-1200-01 BUTTON-PUSH
WD-1330-01 WD-1330-01 CAM-TIMER
WD-1400-04 WD-1400-04 CAPACITOR
WD-1640-12 WD-1640-12 CLAMP - PUMP HOUSING
WD-1640-09 WD-1640-09 CLAMP - TANK FRONT
WD-1640-10 WD-1640-10 CLAMP-BELLOWS
WD-1640-14 WD-1640-14 CLAMP-DRAIN HOSE
WD-1640-13 WD-1640-13 CLAMP-HOSE
WD-1640-11 WD-1640-11 CLAMP-WIRING
WD-1650-03 WD-1650-03 CLIP-AIR TRAP
WD-1650-02 WD-1650-02 CLIP-RETAINING
WD-1800-01 WD-1800-01 CONDENSER - STEAM
WD-1830-01 WD-1830-01 CONNECTOR
WD-1900-03 WD-1900-03 CORD-POWER
WD-1930-03 WD-1930-03 COUNTERWEIGHT - FRON
WD-1930-13 WD-1930-13 COUNTERWEIGHT - FRON
WD-1930-02 WD-1930-02 COUNTERWEIGHT - UPPE
WD-1945-03 WD-1945-03 COUPLING-Y
WD-1950-01 WD-1950-01 COVER - ADDITIVE
WD-1950-22 WD-1950-22 COVER-DISPENSER
WD-2240-01 WD-2240-01 DISPENSER-COLD WATER
WH01X27845 WH01X27845 DOOR STRIKE DOOR LATCH
WD-2300-02 WD-2300-02 DOOR-ASSY
WD-2300-01 WD-2300-01 DOOR-FILTER
WD-2370-01 WD-2370-01 DRAWER - DETERGENT
WD-2500-01 WD-2500-01 ELEMENT - HEATER
WD-2500-02 WD-2500-02 ELEMENT-FILTER
WH01X27860 WH01X27860 FAN - BLOWER
WD-2840-04 WD-2840-04 FLANGE
WD-2900-01 WD-2900-01 FOOT
WD-2950-09 WD-2950-09 FRAME
WH01X27880 WH01X27880 GASKET - CONDENSER T
WD-3100-06 WD-3100-06 GASKET - TUB
WD-3150-01 WD-3150-01 GRILL
WD-3300-01 WD-3300-01 GUIDE-AIR [TOP]
WH01X27909 WH01X27909 HANDLE - DOOR
WD-3350-04 WD-3350-04 HANDLE-FILTER
WD-3450-08 WD-3450-08 HINGE
WD-3570-19 WD-3570-19 HOSE
WD-3570-10 WD-3570-10 HOSE
WD-5255-35 WD-5255-35 HOSE - CONDENSER TAN
WD-3570-18 WD-3570-18 HOSE - DRAIN HOSE
WD-3570-17 WD-3570-17 HOSE - INLET
WD-3570-13 WD-3570-13 HOSE-150MM
WD-3570-14 WD-3570-14 HOSE-180MM
WD-3570-15 WD-3570-15 HOSE-380MM
WD-3570-11 WD-3570-11 HOSE-AIR TRAP
WD-3570-20 WD-3570-20 HOSE-DETERGENT RECYC
WD-3570-08 WD-3570-08 HOSE-PRESSURE SWITCH
WD-3570-12 WD-3570-12 HOSE-PRESSURE SWITCH
WD-3570-22 WD-3570-22 HOSE-TANK-TO-VALVE
WD-3600-02 WD-3600-02 HOUSING - DISPENSER
WD-3600-07 WD-3600-07 HOUSING - DISPENSER
WD-3800-01 WD-3800-01 INSERT-PLASTIC
WD-3890-01 WD-3890-01 JUNCTION-Y
WD-4000-10 WD-4000-10 KNOB - DRY CYCLE
WD-4000-41 WD-4000-41 KNOB-PROGRAM CONTROL
WH01X27862 WH01X27862 MANIFOLD - BLOWER (B
WD-4453-02 WD-4453-02 MANIFOLD - BLOWER [
WD-4545-02 WD-4545-02 MODULE-ELECTRONIC
WD-4550-26 WD-4550-26 MOTOR - DRYER BLOWER
WD-4550-88 WD-4550-88 MOTOR-DRYER BLOWER (
WD-4720-10 WD-4720-10 NUT
WD-5100-07 WD-5100-07 PAD-SHOCK ABSORBER
WD-5100-06 WD-5100-06 PAD-SHOCK ABSORBER
WD-5100-05 WD-5100-05 PAD-SHOCK ABSORBER
WD-5200-05 WD-5200-05 PANEL - LOWER FRONT
WD-5200-03 WD-5200-03 PANEL - REAR
WD-5200-04 WD-5200-04 PANEL-FRONT
WD-5250-04 WD-5250-04 PIN-PIVOT [LATCH]
WD-5300-04 WD-5300-04 PLATE - BOTTOM
WD-5300-05 WD-5300-05 PLATE-COVER
WD-5450-01 WD-5450-01 PULLEY - DRUM
WD-5585-01 WD-5585-01 REGULATOR - PRESSURE
WD-5800-05 WD-5800-05 RING - SEALING
WD-6100-01 WD-6100-01 SCREEN - DOOR
WD-6150-24 WD-6150-24 SCREW
WD-6150-26 WD-6150-26 SCREW
WD-6150-23 WD-6150-23 SCREW-SELF-THREADING
WD-6190-01 WD-6190-01 SEAL - BELLOWS
WD-6190-03 WD-6190-03 SEAL-FILTER
WD-6190-02 WD-6190-02 SEAL-OIL
WD-6450-05 WD-6450-05 SHOCK-ABSORBER
WD-6500-02 WD-6500-02 SHROUD - LOWER
WD-6750-11 WD-6750-11 SPRING
WD-6750-14 WD-6750-14 SPRING-DISPENSER
WD-6750-13 WD-6750-13 SPRING-HANDLE
WD-6750-10 WD-6750-10 SPRING-MANIFOLD
WH01X27845 WH01X27845 STRIKER-DOOR LATCH
WD-7000-02 WD-7000-02 SUPPORT
WD-7000-01 WD-7000-01 SUPPORT - SHOCK ABSO
WD-7000-03 WD-7000-03 SUPPORT-CORD AND HOS
WD-7000-04 WD-7000-04 SUPPORT-DRAIN HOSE
WD-7100-19 WD-7100-19 SWITCH - LOAD
WD-7100-09 WD-7100-09 SWITCH - PRESSURE [
WD-7100-13 WD-7100-13 SWITCH - WATER SAVER
WD-7270-01 WD-7270-01 TERMINAL
WH01X27846 WH01X27846 THERMOSTAT-ASSY KIT
WD-7400-12 WD-7400-12 TIMER-DRYING
WD-7565-01 WD-7565-01 TRAP-AIR
WD-7700-01 WD-7700-01 TRIM - WORKTOP
WD-7750-01 WD-7750-01 TUBE-MOTOR SUPPORT
WD-3570-63 WD-3570-63 VALVE - COLD WATER
WD-7950-09 WD-7950-09 WASHER
WD-7950-11 WD-7950-11 WASHER-SPRING
WD-8100-01 WD-8100-01 WORKTOP
