Manufacturer

Haier

Model Number

DE65EAL

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0800-143 AC-0800-143 BOX-ELECTRICAL
AC-0850-157 AC-0850-157 BRACKET-MOTOR
AC-1400-166 AC-1400-166 CAPACITOR
AC-1470-61 AC-1470-61 CASE
AC-1800-169 AC-1800-169 CONDENSER-ASSEMBLY
AC-2650-139 AC-2650-139 EVAPORATOR-ASSEMBLY
AC-5100-17 AC-5100-17 PAD-TOP
AC-5211-27 AC-5211-27 PARTITION-LOWER
AC-5211-26 AC-5211-26 PARTITION-TOP
AC-5255-294 AC-5255-294 PIPE-AIR DISCHARGE
AC-5255-295 AC-5255-295 PIPE-SUCTION
AC-5300-200 AC-5300-200 PLATE-BOTTOM
AC-6250-37 AC-6250-37 SENSOR-HUMIDITY
AC-7100-42 AC-7100-42 SWITCH
