Haier

Model Number

ESA3247

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0255-14 AC-0255-14 BASEPAN-ANGLE
WJ73X10211 WJ73X10211 BLADE-FAN
WJ73X10212 WJ73X10212 BLOWER-FAN
AC-0750-35 AC-0750-35 BOLT-2.5"
AC-0800-49 AC-0800-49 BOX-ELECTRIC
AC-0850-75 AC-0850-75 BOX-PHOTOCATALYST FI
WJ76X10318 WJ76X10318 CASE-SCROLL
AC-1620-25 AC-1620-25 CHASSIS-BOTTOM
AC-1650-16 AC-1650-16 CLIP-CAPACITOR
AC-0668-23 AC-0668-23 COVER-TOP BOARD
WJ29X10045 WJ29X10045 DISPLAY BOARD ONLY
AC-2650-135 AC-2650-135 EVAPORATOR-ASSEMBLY
WJ85X23968 WJ85X23968 FILTER-STATIC
AC-2950-42 AC-2950-42 FRAME-ACCORDIAN SCRE
AC-3100-99 AC-3100-99 GASKET-FOAM
AC-5200-249 AC-5200-249 KEYPAD
A0010401514D A0010401514D MOTOR
AC-4720-70 AC-4720-70 NUT
WJ76X10319 WJ76X10319 PARTITION-EVAPORATOR
WJ76X10324 WJ76X10324 PARTITION-FRONT
WJ79X10257 WJ79X10257 PARTITION-REAR
AC-5255-112 AC-5255-112 PIPE
0011800335 0011800335 POWER BOARD
AC-3300-17 AC-3300-17 RAIL-TOP
WJ01X10438 WJ01X10438 SCREW-SHORT 13/32"
AC-6150-67 AC-6150-67 SCREW-WOOD 31/32"
AC-7750-237 AC-7750-237 TUBE-CONDENSER EXIT
AC-7750-245 AC-7750-245 TUBE-CONDENSER INLET
AC-7750-214 AC-7750-214 TUBE-SUCTION
