Model Image
Manufacturer

GE

Model Number

ESA412K

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WJ01X23761 WJ01X23761 BAG-SCREW ASSY
AC-0750-049 AC-0750-049 BOLT-BOTTOM
AC-0800-118 AC-0800-118 BOX-ELECTRIC
AC-0850-200 AC-0850-200 BRACKET
AC-0850-156 AC-0850-156 BRACKET-FRESH AIR
AC-1400-37 AC-1400-37 CAPACITOR-FAN MOTOR
AC-1405-084 AC-1405-084 CAPILLARY
AC-1450-198 AC-1450-198 CARTON - PACKAGING B
AC-1300-089 AC-1300-089 CHASSIS
AC-1620-32 AC-1620-32 CHASSIS-BOTTOM
WJ03X10093 WJ03X10093 CLIP-CAPACITOR
AC-1650-67 AC-1650-67 CLIP-POWER CORD
AC-1750-299 AC-1750-299 COMPRESSOR
AC-1800-221 AC-1800-221 CONDENSER
AC-1950-337 AC-1950-337 COVER-ELECTRIC BOX
AC-2650-190 AC-2650-190 EVAPORATOR
AC-2750-136 AC-2750-136 FAN-CONDENSER
WJ85X23968 WJ85X23968 FILTER-STATIC
WJ65X23649 WJ65X23649 FRAME-ACCORDIAN LEFT
WJ65X23780 WJ65X23780 FRAME-ACCORDIAN RIGH
WJ43X22906 WJ43X22906 GASKET-WINDOW
WJ86X21742 WJ86X21742 GUIDE-TOP
WJ35X23903 WJ35X23903 HARNESS-WIRE
AC-0850-75 AC-0850-75 HOLDER-FILTER
WJ82X20077 WJ82X20077 KNOB
WJ76X20093 WJ76X20093 PARTITION
WJ86X23762 WJ86X23762 SCREEN-ACCORDIAN
WJ27X23476 WJ27X23476 TRANSFORMER
AC-7750-292 AC-7750-292 TUBE
AC-7750-291 AC-7750-291 TUBE
AC-7900-028 AC-7900-028 VENT
