Model Image
Manufacturer

Haier

Model Number

ESA415K

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0255-14 AC-0255-14 BASEPAN-ANGLE
AC-0600-12 AC-0600-12 BLOWER-FAN
AC-0750-35 AC-0750-35 BOLT-2.5"
AC-0750-049 AC-0750-049 BOLT-BOTTOM
WJ66X20132 WJ66X20132 BRACKET
AC-0850-155 AC-0850-155 BRACKET-MOTOR
AC-1400-37 AC-1400-37 CAPACITOR-FAN MOTOR
AC-1405-087 AC-1405-087 CAPILLARY
WJ90X10141 WJ90X10141 CHASSIS
WJ01X22166 WJ01X22166 CLIP-CAPACITOR
AC-1650-80 AC-1650-80 CLIP-CAPACITOR
AC-1750-302 AC-1750-302 COMPRESSOR
AC-1800-252 AC-1800-252 CONDENSER
AC-1900-61 AC-1900-61 CORD-POWER
AC-1950-336 AC-1950-336 COVER-ELECTRIC BOX
AC-2650-131 AC-2650-131 EVAPORATOR-ASSEMBLY
WJ73X10213 WJ73X10213 FAN-AXIAL
WJ85X23968 WJ85X23968 FILTER-STATIC
AC-1950-335 AC-1950-335 FOAM
AC-2950-82 AC-2950-82 FRAME-LEFT
AC-2950-83 AC-2950-83 FRAME-RIGHT
AC-3100-99 AC-3100-99 GASKET-FOAM
AC-3300-047 AC-3300-047 GUIDE
AC-3300-046 AC-3300-046 GUIDE
WJ35X21771 WJ35X21771 HARNESS-WIRE
AC-3500-162 AC-3500-162 HOLDER-ELECTRIC BOX
AC-0850-75 AC-0850-75 HOLDER-FILTER
AC-4440-65 AC-4440-65 LOUVER-HORIZONTAL
AC-4550-312 AC-4550-312 MOTOR-FAN
WJ29X10045 WJ29X10045 P.C.B.
WJ76X10322 WJ76X10322 PARTITION-FRONT
WJ01X10439 WJ01X10439 PARTITION-REAR
WJ29X10046 WJ29X10046 PARTITION-REAR TOP
AC-5211-13 AC-5211-13 PARTITION-TOP
AC-5255-612 AC-5255-612 PIPE
WJ62X10031 WJ62X10031 PIPE
AC-5255-466 AC-5255-466 PIPE-SUCTION
AC-5300-353 AC-5300-353 PLATE-BOTTOM
AC-6150-66 AC-6150-66 SCREW-FRAME 13/32"
AC-6150-67 AC-6150-67 SCREW-WOOD 31/32"
WJ27X23476 WJ27X23476 TRANSFORMER
WJ62X10043 WJ62X10043 TUBE
AC-7750-266 AC-7750-266 TUBE-DISCHARGE
AC-7750-198 AC-7750-198 TUBE-ENTRY
AC-5255-679 AC-5255-679 TUBE-ENTRY
WJ62X10041 WJ62X10041 TUBE-ENTRY
WJ62X10024 WJ62X10024 TUBE-EVAPORATOR GAS-
AC-7900-027 AC-7900-027 VENT
