Model Image
Manufacturer

Haier

Model Number

HLT41E

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WD-0010-02 WD-0010-02 ACCESSORIES
WD-0155-03 WD-0155-03 BAG
WH01X27678 WH01X27678 BAND
WD-0595-04 WD-0595-04 BLOCK-GLIDING
WD-0595-06 WD-0595-06 BLOCK-SMALL
WD-0595-02 WD-0595-02 BLOCK-STABILIZING
WD-0595-08 WD-0595-08 BLOCK-WATER CHANNEL
WH02X27268 WH02X27268 BOLT
WD-0850-46 WD-0850-46 BRACKET-SWITCH
WD-1250-10 WD-1250-10 BUZZER
WD-1300-08 WD-1300-08 CABINET
WD-1330-02 WD-1330-02 CAM-SELECTOR
WD-1400-09 WD-1400-09 CAPACITOR
WD-1450-04 WD-1450-04 CARTON
WD-1640-31 WD-1640-31 CLAMP-CAPACITOR
WD-1640-35 WD-1640-35 CLAMP-DRAIN HOSE
WD-1640-38 WD-1640-38 CLAMP-DRAIN HOSE
WD-1640-37 WD-1640-37 CLAMP-DRAIN HOSE
WD-1640-34 WD-1640-34 CLAMP-POWER CORD
WD-1650-17 WD-1650-17 CLIP-WIRE
WD-1685-04 WD-1685-04 CLUTCH
WD-1900-17 WD-1900-17 CORD-POWER
WD-1950-57 WD-1950-57 COVER
WD-1950-59 WD-1950-59 COVER-VALVE [A]
WD-2045-03 WD-2045-03 CYLINDER-OUTER
WH01X27926 WH01X27926 FILTER-LINT
WD-2950-40 WD-2950-40 FRAME-SPIN TUB
WD-3100-20 WD-3100-20 GASKET-EXPANSION
WD-3300-04 WD-3300-04 GUIDE
WD-3350-11 WD-3350-11 HANDLE-CABINET
WD-3550-05 WD-3550-05 HOOK-POWER CORD
WD-3570-75 WD-3570-75 HOSE - DRAIN (OUTER)
WD-3845-01 WD-3845-01 INSULATION-MOTOR BOT
WD-4000-36 WD-4000-36 KNOB
WD-4050-35 WD-4050-35 LABEL
WD-4050-36 WD-4050-36 LABEL-EXCESS FILLING
WD-4050-31 WD-4050-31 LABEL-WARNING
WD-4050-37 WD-4050-37 LABEL-WATER FILLING
WD-9999-26 WD-9999-26 MANUAL - USE & CARE
WD-4600-18 WD-4600-18 NAMEPLATE
WD-4720-16 WD-4720-16 NUT
WD-5250-07 WD-5250-07 PIN
WD-5255-50 WD-5255-50 PIPE-DRAIN
WD-5255-21 WD-5255-21 PIPE-OVERFLOW
WD-5255-20 WD-5255-20 PIPE-OVERFLOW [LONG]
WD-5300-20 WD-5300-20 PLATE-ADJUSTABLE LEG
WD-5310-02 WD-5310-02 PLUG-VALVE
WD-5450-08 WD-5450-08 PULLEY
WD-5460-07 WD-5460-07 PULSATOR
WD-5950-07 WD-5950-07 ROD-CONNECTING
WD-6150-35 WD-6150-35 SCREW
WD-6150-139 WD-6150-139 SCREW
WD-6150-143 WD-6150-143 SCREW
WD-6150-69 WD-6150-69 SCREW
WD-6150-95 WD-6150-95 SCREW
WD-6150-41 WD-6150-41 SCREW
WH01X27834 WH01X27834 SCREW
WH02X26155 WH02X26155 SCREW
WH01X27833 WH01X27833 SCREW
WD-6150-36 WD-6150-36 SCREW-BOLT WITH LOCK
WD-6200-21 WD-6200-21 SEAT - BEARING (A)
WD-6750-51 WD-6750-51 SPRING
WD-6750-29 WD-6750-29 SPRING-KICK
WD-6750-23 WD-6750-23 SPRING-LIMIT PLATE
WD-6750-31 WD-6750-31 SPRING-SMALL
WD-6750-30 WD-6750-30 SPRING-VALVE
WD-6900-02 WD-6900-02 STOPPER
WD-6957-01 WD-6957-01 STRIP
WD-7100-49 WD-7100-49 SWITCH-DRAIN
WD-7400-08 WD-7400-08 TIMER-SPIN
WD-7400-07 WD-7400-07 TIMER-WASH
WD-7745-37 WD-7745-37 TUB-SPIN
WD-7750-05 WD-7750-05 TUBE - BRAKE WHEEL
WD-7750-10 WD-7750-10 TUBE-CHANNEL
WD-7950-05 WD-7950-05 WASHER
WD-7950-14 WD-7950-14 WASHER
WD-7950-15 WD-7950-15 WASHER-SPRING
WD-8070-11 WD-8070-11 WIRE-GROUNDING
