Model Image
Manufacturer

Haier

Model Number

HRF10WNBWW

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
RF-1750-67 RF-1750-67 ACCESSORIES - COMPRE
WR01X29913 WR01X29913 AXLE-HINGE PIN
RF-0850-50 RF-0850-50 BRACKET
RF-0850-49 RF-0850-49 BRACKET-COMPRESSOR
WR14X29891 WR14X29891 BRACKET-EVAP FAN [B]
RF-1050-27 RF-1050-27 BULB
RF-1450-58 RF-1450-58 CARTON
RF-1640-06 RF-1640-06 CLAMP-CABLE
RF-1800-55 RF-1800-55 CONDENSER-ASSY.
RF-1900-56 RF-1900-56 CORD-POWER
RF-1950-111 RF-1950-111 COVER-BULB
RF-1950-134 RF-1950-134 COVER-TOP HINGE
WR09X29895 WR09X29895 DEFROST HEATER
RF-2650-83 RF-2650-83 EVAPORATOR
WR87X30058 WR87X30058 FILTER-DRIER
RF-3200-02 RF-3200-02 GROMMET
RF-3400-09 RF-3400-09 HEATER-DEFROST
RF-3450-132 RF-3450-132 HINGE-BOTTOM
WR13X27778 WR13X27778 HINGE-TOP
RF-4000-33 RF-4000-33 KNOB-THERMOSTAT
RF-9999-146 RF-9999-146 MANUAL - USE & CARE
RF-4600-68 RF-4600-68 NAMEPLATE
RF-5100-25 RF-5100-25 PAD-E SHAPE CABINET
RF-5300-10 RF-5300-10 PLATE
RF-5300-11 RF-5300-11 PLATE-ALUMINUM
RF-5310-23 RF-5310-23 PLUG-HINGE HOLE (WHI
RF-5310-24 RF-5310-24 PLUG-HINGE HOLE (WHI
WR14X29853 WR14X29853 REFRIGE WHIT GASKET
RF-6150-117 RF-6150-117 SCREW
RF-6150-115 RF-6150-115 SCREW
RF-6150-62 RF-6150-62 SCREW
RF-6150-84 RF-6150-84 SCREW
WR01X27788 WR01X27788 SCREW
WR01X27682 WR01X27682 SCREW
RF-6150-20 RF-6150-20 SCREW-HINGE [PHILLIP
RF-6350-107 RF-6350-107 SHELF-FREEZER [WIRE]
RF-7950-48 RF-7950-48 SHIM-WASHER (INSIDE
WR23X27351 WR23X27351 SWITCH
RF-7350-58 RF-7350-58 THERMOSTAT
RF-7600-95 RF-7600-95 TRAY - COMPRESSOR-DR
WR02X27688 WR02X27688 TRAY-ICE
RF-7750-27 RF-7750-27 TUBE
RF-7750-14 RF-7750-14 TUBE-CONDENSATION
RF-7750-41 RF-7750-41 TUBE-CONNECTION
RF-7950-37 RF-7950-37 WASHER-RUBBER
