Model Image
Manufacturer

Haier

Model Number

HSA02WNCBB

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
RF-3450-352 RF-3450-352 BASE-LOWER HINGE
RF-0850-79 RF-0850-79 BRACKET-COMPRESSOR
RF-1302-50 RF-1302-50 CABLE - CONNECTION
RF-1350-11 RF-1350-11 CAP-CONNECTION
RF-1450-136 RF-1450-136 CARTON
RF-1650-36 RF-1650-36 CLIP-CABLE
RF-1800-67 RF-1800-67 CONDENSER
WR13X27666 WR13X27666 COVER-HINGE
RF-2300-258 RF-2300-258 DOOR
RF-2650-111 RF-2650-111 EVAPORATOR
RF-3200-02 RF-3200-02 GROMMET
RF-3450-279 RF-3450-279 HINGE-UPPER
RF-3600-19 RF-3600-19 HOUSING-THERMOSTAT
WR02X27674 WR02X27674 KNOB-THERMOSTAT
RF-4600-57 RF-4600-57 NAMEPLATE
RF-6150-68 RF-6150-68 SCREW
RF-6150-62 RF-6150-62 SCREW
RF-6150-77 RF-6150-77 SCREW
RF-6150-144 RF-6150-144 SCREW
WR01X27774 WR01X27774 SCREW
WR01X27682 WR01X27682 SCREW
RF-6150-13 RF-6150-13 SCREW-PHILLIPS TAPPI
WR71X29956 WR71X29956 SHELF
RF-6535-13 RF-6535-13 SLEEVE-THERMOSTAT CA
WR02X27686 WR02X27686 SPRING-EVAP DOOR
RF-7350-101 RF-7350-101 THERMOSTAT
WR02X27688 WR02X27688 TRAY-ICE
WR14X27668 WR14X27668 TRAY-WATER
RF-7750-23 RF-7750-23 TUBE-DISCHARGE
RF-7950-33 RF-7950-33 WASHER
