Model Image
Manufacturer

GE

Model Number

HUF205PB

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WR71X29837 WR71X29837 BASKET-LOWER
WR60X29904 WR60X29904 BLADE-EVAP FAN (G.E.
RF-0800-33 RF-0800-33 BOX-THERMOSTAT
RF-0850-50 RF-0850-50 BRACKET
WR14X29891 WR14X29891 BRACKET-EVAP FAN [B]
WR09X27353 WR09X27353 CABLE - DEFROST THER
WR87X27279 WR87X27279 CAPACITOR 12MFD
WR02X27362 WR02X27362 CASTER-LEFT FRONT
WR02X27363 WR02X27363 CASTER-RIGHT FRONT
RF-1650-49 RF-1650-49 CLIP-HEAT CONDUCTION
RF-1750-241 RF-1750-241 COMPRESSOR
RF-1900-87 RF-1900-87 CORD-POWER
RF-1950-217 RF-1950-217 COVER
RF-1950-538 RF-1950-538 COVER-EVAPORATOR
RF-1950-172 RF-1950-172 COVER-HANDLE FRIDGE/
RF-1950-191 RF-1950-191 COVER-LIGHT
RF-1950-712 RF-1950-712 COVER-STARTER/OVERLOAD
WR13X29894 WR13X29894 COVER-TOP HINGE WHIT
RF-2400-26 RF-2400-26 DRIER
RF-2650-81 RF-2650-81 EVAPORATOR-ASSY
RF-3350-40 RF-3350-40 HANDLE-REFRIG & FREE
WR13X29812 WR13X29812 HINGE-BOTTOM
RF-3450-151 RF-3450-151 HINGE-LOCK
WR13X29903 WR13X29903 HINGE-TOP
RF-6150-201 RF-6150-201 HOLDER-LAMP
WR01X29938 WR01X29938 KEY-FOR RF-4390-13
RF-4000-48 RF-4000-48 KNOB
RF-7100-31 RF-7100-31 LAMP SWITCH - LIGHT SWITCH
RF-9999-238 RF-9999-238 MANUAL - USE & CARE
RF-4600-79 RF-4600-79 NAMEPLATE - HAIER
RF-4800-49 RF-4800-49 OVERLOAD PROTECTION
RF-5300-10 RF-5300-10 PLATE
RF-5300-94 RF-5300-94 PLATE - REFLECTOR
WR01X27354 WR01X27354 PLUG-CORNER TRIM
RF-5310-25 RF-5310-25 PLUG-SCREW HOLE
RF-5550-07 RF-5550-07 RAIL-ASSY
WR01X29890 WR01X29890 SHIM
WR01X29893 WR01X29893 SHIM - BOTTOM HINGE
RF-6600-10 RF-6600-10 SOCKET - BULB
RF-6957-16 RF-6957-16 STRIP
WR09X29883 WR09X29883 THERMOSTAT
WR09X29883 WR09X29883 THERMOSTAT
RF-7950-37 RF-7950-37 WASHER-RUBBER
WR01X29890 WR01X29890 WASHERS
