Model Image
Manufacturer

GE

Model Number

HWR06XCJ

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WJ01X23761 WJ01X23761 BAG-SCREW ASSY
AC-0750-37 AC-0750-37 BOLT-BOTTOM
AC-0800-139 AC-0800-139 BOX-CONTROL
AC-0800-140 AC-0800-140 BOX-TOP
AC-1400-161 AC-1400-161 CAPACITOR-COMPRESSOR
AC-1405-57 AC-1405-57 CAPILLARY
AC-1470-58 AC-1470-58 CASE
AC-1620-24 AC-1620-24 CHASSIS-BOTTOM
AC-1650-75 AC-1650-75 CLIP-CABLE
WJ03X10093 WJ03X10093 CLIP-CAPACITOR
AC-1750-243 AC-1750-243 COMPRESSOR
AC-1800-174 AC-1800-174 CONDENSER-ASSEMBLY
AC-2100-28 AC-2100-28 DEFLECTOR-AIR
AC-2650-134 AC-2650-134 EVAPORATOR-ASSEMBLY
WJ65X23746 WJ65X23746 FRAME-LEFT
WJ65X23747 WJ65X23747 FRAME-RIGHT
AC-7800-178 AC-7800-178 GASKET-WINDOW SEAL
AC-3300-31 AC-3300-31 GUIDE-LOWER
AC-3363-23 AC-3363-23 HARNESS
AC-3845-16 AC-3845-16 INSULATION-KEYPAD
AC-3899-03 AC-3899-03 KEYPAD
AC-4550-305 AC-4550-305 MOTOR
AC-5210-161 AC-5210-161 P.C.B.-POWER BOARD
AC-5200-453 AC-5200-453 PANEL-FRONT ASSEMBLY
AC-5211-21 AC-5211-21 PARTITION-EVAPORATOR
AC-5211-19 AC-5211-19 PARTITION-FRONT
AC-5211-20 AC-5211-20 PARTITION-REAR
AC-5550-18 AC-5550-18 RAIL-TOP
WJ86X23745 WJ86X23745 SCREEN-ACCORDION
WJ27X23476 WJ27X23476 TRANSFORMER
AC-7750-212 AC-7750-212 TUBE-CONDENSER OUT
AC-7750-233 AC-7750-233 TUBE-EVAPORATOR IN
AC-7750-232 AC-7750-232 TUBE-SUCTION
