Model Image
Manufacturer

GE

Model Number

HWR18VC5

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WJ01X23601 WJ01X23601 BAG-SCREW
AC-0668-23 AC-0668-23 BOARD-TOP COVER
AC-0800-49 AC-0800-49 BOX-ELECTRIC
AC-0840-10 AC-0840-10 BRACE-TRIANGLE [LEFT
AC-0850-103 AC-0850-103 BRACKET-ANGLE
AC-1470-22 AC-1470-22 CASE-SCROLL
AC-1650-16 AC-1650-16 CLIP-CAPACITOR
AC-1750-47 AC-1750-47 COMPRESSOR
AC-1800-30 AC-1800-30 CONDENSER
WJ29X10045 WJ29X10045 DISPLAY BOARD ONLY
AC-2650-32 AC-2650-32 EVAPORATOR
WJ73X10211 WJ73X10211 FAN- PROPELLER
WJ73X10212 WJ73X10212 FAN-CENTRIFUGAL
AC-2950-42 AC-2950-42 FRAME-ACCORDIAN SCRE
AC-3100-28 AC-3100-28 GASKET-SASH
AC-3300-17 AC-3300-17 GUIDE-INLET
AC-4440-40 AC-4440-40 LOUVER-SMALL VERTICA
A0010401514D A0010401514D MOTOR
AC-4720-06 AC-4720-06 NUT
AC-5200-249 AC-5200-249 PANEL-DISPLAY HOLDER
AC-5200-261 AC-5200-261 PANEL-SIDE PARTITION
AC-5255-112 AC-5255-112 PIPE
AC-5255-118 AC-5255-118 PIPE-SUCTION ASSY
AC-5300-60 AC-5300-60 PLATE-PARTITION REAR
0011800335 0011800335 POWER BOARD
AC-5950-29 AC-5950-29 ROD-CONNECTING
AC-6150-23 AC-6150-23 SCREW
AC-6150-15 AC-6150-15 SCREW-25MM WOOD
AC-0750-35 AC-0750-35 SCREW-BRACE
AC-6998-11 AC-6998-11 STYROFOAM
AC-7100-37 AC-7100-37 SWITCH-AIR EXCHANGE
