Model Image
Manufacturer

Haier

Model Number

PTCH0901UAC

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0344-11 AC-0344-11 BEARING
AC-0344-12 AC-0344-12 BEARING-23-B
AC-0595-60 AC-0595-60 BLOCK-CHOCK
AC-0595-59 AC-0595-59 BLOCK-CHOCK
WJ26X23823 WJ26X23823 BLOCK-TERMINAL
AC-0800-100 AC-0800-100 BOX-CONTROL 8-D
AC-0850-92 AC-0850-92 BRACKET
AC-0850-91 AC-0850-91 BRACKET
AC-0850-90 AC-0850-90 BRACKET-BRACKET; WALL SLEEVE M
AC-0850-89 AC-0850-89 BRACKET-SHROUD SUPPORT 14-B
AC-1400-39 AC-1400-39 CAPACITOR-COMPRESSOR
AC-1400-54 AC-1400-54 CAPACITOR-MOTOR
AC-1400-118 AC-1400-118 CAPACITOR-OUTDOOR MOTOR
AC-1405-095 AC-1405-095 CAPILLARY
AC-1640-055 AC-1640-055 CLAMP
AC-1650-43 AC-1650-43 CLIP-CAPACITOR
AC-1650-55 AC-1650-55 CLIP-FRONT PANEL
AC-1750-327 AC-1750-327 COMPRESSOR
AC-1800-250 AC-1800-250 CONDENSER
AC-1830-09 AC-1830-09 CONNECTOR
AC-1950-465 AC-1950-465 COVER
AC-1950-208 AC-1950-208 COVER-BEARING
AC-1950-211 AC-1950-211 COVER-CONTROL BARRIER 12-D
AC-1950-213 AC-1950-213 COVER-DRAIN 20-B
AC-1950-221 AC-1950-221 COVER-EVAPORATOR
AC-1950-212 AC-1950-212 COVER-HOUSING 1-D
AC-1950-207 AC-1950-207 COVER-VENT DOOR
AC-2015-192 AC-2015-192 CUSHION
AC-2650-213 AC-2650-213 EVAPORATOR
AC-2750-81 AC-2750-81 FAN-INDOOR DISK 4.33IN 45 BLAD
AC-2750-82 AC-2750-82 FAN-OUTDOOR DISK, 13.72 IN 3 B
AC-2800-65 AC-2800-65 FILTER-12.9 IN X 11IN X 0.6 IN
AC-3150-68 AC-3150-68 GRILL- DISCHARGE
AC-3250-03 AC-3250-03 GUARD-3-B
AC-3600-24 AC-3600-24 HOUSING
AC-3600-23 AC-3600-23 HOUSING-P.C.B. 2-D
AC-4000-36 AC-4000-36 KNOB-26-B
AC-4550-169 AC-4550-169 MOTOR- INDOOR, 208/230V/60HZ/1
AC-4550-170 AC-4550-170 MOTOR- OUTDOOR, 1/18HP 208/230
WJ01X23150 WJ01X23150 NUT
AC-5150-64 AC-5150-64 PAN-BASE
AC-5150-65 AC-5150-65 PAN-DRAIN
AC-5200-295 AC-5200-295 PANEL- FRONT
AC-5200-296 AC-5200-296 PANEL-BARRIER
AC-5200-299 AC-5200-299 PANEL-CONTROL BOX BACK
AC-5200-297 AC-5200-297 PANEL-SIDE CONTROL BOX
AC-5210-230 AC-5210-230 PCB WITH HOLDER
AC-5310-11 AC-5310-11 PLUG-RUBBER
AC-5900-01 AC-5900-01 RIVET
AC-6150-085 AC-6150-085 SCREW
AC-6340-03 AC-6340-03 SHEET-METAL 5-B
AC-7000-33 AC-7000-33 SUPPORT- ID MOTOR BRACKET
AC-7000-35 AC-7000-35 SUPPORT-CONTROL BOX LEFT SIDE
AC-7000-36 AC-7000-36 SUPPORT-CONTROL BOX RIGHT SIDE
AC-7000-37 AC-7000-37 SUPPORT-LEFT SIDE
AC-7000-34 AC-7000-34 SUPPORT-OD MOTOR BRACKET
AC-7800-70 AC-7800-70 VALVE- DRAINAGE TEMPERATURE
AC-7950-014 AC-7950-014 WASHER
AC-8070-07 AC-8070-07 WIRE-25-B
