Model Image
Manufacturer

Haier

Model Number

RADS51A

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AC-0668-94 AC-0668-94 BOARD-TOP COVER
AC-0850-75 AC-0850-75 BRACKET
WJ20X10192 WJ20X10192 CAPACITOR-COMPRESSOR
AC-1470-10 AC-1470-10 CASE-BLOWER SCROLL
AC-1620-16 AC-1620-16 CHASSIS-ASSY
AC-1750-48 AC-1750-48 COMPRESSOR
AC-1800-29 AC-1800-29 CONDENSER
AC-1950-230 AC-1950-230 COVER-ELECTRICAL BOX
AC-2650-23 AC-2650-23 EVAPORATOR-ASSY (SEN
AC-2750-18 AC-2750-18 FAN-BLOWER WHEEL
WJ85X23968 WJ85X23968 FILTER-ELECTROSTATIC
AC-2950-64 AC-2950-64 FRAME
WJ65X22104 WJ65X22104 GUIDE
AC-4200-02 AC-4200-02 LEVER
AC-4440-58 AC-4440-58 LOUVER-HORIZONTAL
AC-4550-149 AC-4550-149 MOTOR
AC-5100-14 AC-5100-14 PAD-SIDE
AC-5100-12 AC-5100-12 PAD-UPPER
AC-5200-275 AC-5200-275 PANEL-INDICATOR
AC-5255-139 AC-5255-139 PIPE-CAPILLARY
AC-5255-120 AC-5255-120 PIPE-SUCTION ASSY
AC-5255-89 AC-5255-89 PIPE-VENT (LG & RECH
AC-5300-31 AC-5300-31 PLATE-CONDUIT
AC-6500-05 AC-6500-05 SHROUD-CONDENSER
AC-7810-02 AC-7810-02 VANE-MAIN VERTICAL
AC-7810-03 AC-7810-03 VANE-VERTICAL
