Model Image
Manufacturer

Haier

Model Number

RRTG21PAAB

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
RF-0150-08 RF-0150-08 BAFFLE-CONDENSER FAN
RF-0550-21 RF-0550-21 BLADE-CONDENSER
WR60X29904 WR60X29904 BLADE-EVAP FAN (G.E.
WR14X29896 WR14X29896 BRACKET-EVAP FAN [A]
WR14X29891 WR14X29891 BRACKET-EVAP FAN [B]
RF-1050-26 RF-1050-26 BULB-40W
WR02X27461 WR02X27461 CAP-DOOR (BLACK/LEFT
WR02X27460 WR02X27460 CAP-DOOR (BLACK/RIGH
WR87X27279 WR87X27279 CAPACITOR 12MFD
WR02X27362 WR02X27362 CASTER-LEFT FRONT
WR02X27363 WR02X27363 CASTER-RIGHT FRONT
WR01X29897 WR01X29897 CLIP
RF-1650-09 RF-1650-09 CLIP-CONDENSER
RF-1750-241 RF-1750-241 COMPRESSOR
RF-1800-70 RF-1800-70 CONDENSER-ASSY
RF-1900-77 RF-1900-77 CORD-POWER ASSY
RF-1950-422 RF-1950-422 COVER-CABLE
RF-1950-247 RF-1950-247 COVER-COMPRESSOR
RF-1950-712 RF-1950-712 COVER-STARTER/OVERLOAD
WR13X27459 WR13X27459 COVER-TOP HINGE BLAC
WR09X29888 WR09X29888 DEFROST HEATER
RF-2260-03 RF-2260-03 DIVIDER-SHELF PARTIT
RF-2300-456 RF-2300-456 DOOR-FZ ASSY
RF-2400-26 RF-2400-26 DRIER
RF-2650-81 RF-2650-81 EVAPORATOR-ASSY
WR14X29852 WR14X29852 GASKET - FF DOOR BLA
WR14X29855 WR14X29855 GASKET-FZ DOOR (BLAC
RF-3150-14 RF-3150-14 GRILL-BOTTOM [BLACK]
WR09X29888 WR09X29888 HEATER-DEFROST
WR13X29812 WR13X29812 HINGE-BOTTOM
WR13X29903 WR13X29903 HINGE-TOP
WR14X29900 WR14X29900 MOTOR-EVAP [KIT]
RF-4800-49 RF-4800-49 OVERLOAD PROTECTION
WR02X27458 WR02X27458 PLUG-HINGE HOLE
WR01X29890 WR01X29890 SHIM
WR01X29893 WR01X29893 SHIM - BOTTOM HINGE
WR13X27290 WR13X27290 SHIM-CENTER
WR23X27351 WR23X27351 SWITCH
WR09X29877 WR09X29877 THERMOSTAT
RF-7600-63 RF-7600-63 TRAY-ICE STORAGE
RF-7950-37 RF-7950-37 WASHER-RUBBER
WR01X29890 WR01X29890 WASHERS
