Haier

Model Number

XPB135LA

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WD-0155-07 WD-0155-07 BAG
WH01X27678 WH01X27678 BAND
WD-0250-11 WD-0250-11 BASE
WD-0250-12 WD-0250-12 BASE
WD-0250-14 WD-0250-14 BASE - FRAME
WD-0250-13 WD-0250-13 BASE-CONTROL PANEL
WD-0344-08 WD-0344-08 BEARING
WH07X27710 WH07X27710 BELT-LOCKING
WD-0595-13 WD-0595-13 BLOCK-SLIDE
WD-0750-29 WD-0750-29 BOLT
WH01X27841 WH01X27841 BUSHING-B
WD-1300-22 WD-1300-22 CABINET
WD-1330-02 WD-1330-02 CAM-SELECTOR
WD-1400-11 WD-1400-11 CAPACITOR
WD-1610-06 WD-1610-06 CHANNEL-WATER
WD-1640-56 WD-1640-56 CLAMP
WD-1640-37 WD-1640-37 CLAMP-DRAIN HOSE
WD-1640-34 WD-1640-34 CLAMP-POWER CORD
WD-1830-03 WD-1830-03 CONNECTOR
WD-1830-04 WD-1830-04 CONNECTOR
WD-1930-15 WD-1930-15 COUNTERWEIGHT
WD-1950-57 WD-1950-57 COVER
WD-1950-134 WD-1950-134 COVER
WD-1950-60 WD-1950-60 COVER - INNER
WD-1950-136 WD-1950-136 COVER - SPIN TUB
WD-1950-138 WD-1950-138 COVER - WASH-TUB
WD-1950-135 WD-1950-135 COVER-BACK
WD-2800-20 WD-2800-20 FILTER - LINT
WD-2800-21 WD-2800-21 FILTER-OVERFLOW
WD-3100-66 WD-3100-66 GASKET
WD-3100-65 WD-3100-65 GASKET
WD-3100-20 WD-3100-20 GASKET-EXPANSION
WD-3570-78 WD-3570-78 HOSE
WD-3570-79 WD-3570-79 HOSE - DRAIN
WD-3845-01 WD-3845-01 INSULATION-MOTOR BOT
WD-4000-39 WD-4000-39 KNOB
WD-4100-05 WD-4100-05 LATCH
WD-4200-05 WD-4200-05 LEVER-UPPER
WD-4550-45 WD-4550-45 MOTOR
WD-4550-20 WD-4550-20 MOTOR - WASH
WD-4720-16 WD-4720-16 NUT
WD-5100-12 WD-5100-12 PAD-SHOCK A
WD-5100-13 WD-5100-13 PAD-SHOCK A
WD-5150-03 WD-5150-03 PAN-BRAKE
WD-5200-77 WD-5200-77 PANEL - CONTROL
WD-5250-07 WD-5250-07 PIN
WD-5255-53 WD-5255-53 PIPE - WATER
WD-5255-52 WD-5255-52 PIPE-CORRUGATION
WD-5300-20 WD-5300-20 PLATE-ADJUSTABLE LEG
WD-5300-11 WD-5300-11 PLATE-VALVE
WD-5450-10 WD-5450-10 PULLEY - RADIATING
WD-5460-17 WD-5460-17 PULSATOR
WD-5800-27 WD-5800-27 RING - TUB
WD-6150-95 WD-6150-95 SCREW
WD-6150-41 WD-6150-41 SCREW
WH02X26927 WH02X26927 SCREW
WD-6150-35 WD-6150-35 SCREW
WH01X27833 WH01X27833 SCREW
WH02X26155 WH02X26155 SCREW
WD-6150-36 WD-6150-36 SCREW-BOLT WITH LOCK
WD-6300-06 WD-6300-06 SHAFT
WD-6750-51 WD-6750-51 SPRING
WD-6750-56 WD-6750-56 SPRING
WD-6750-55 WD-6750-55 SPRING
WD-6750-57 WD-6750-57 SPRING
WD-6750-23 WD-6750-23 SPRING-LIMIT PLATE
WD-6750-31 WD-6750-31 SPRING-SMALL
WD-7000-15 WD-7000-15 SUPPORT
WD-7100-53 WD-7100-53 SWITCH
WD-7100-54 WD-7100-54 SWITCH
WD-7100-33 WD-7100-33 SWITCH-MICRO
WD-7400-06 WD-7400-06 TIMER - SPIN
WD-7400-15 WD-7400-15 TIMER - WASH
WD-7745-39 WD-7745-39 TUB-SPIN
WD-7745-40 WD-7745-40 TUB-TWIN
WD-7750-20 WD-7750-20 TUBE-WATER INLET
WD-7800-30 WD-7800-30 VALVE-BODY
WD-7950-05 WD-7950-05 WASHER
WD-7950-15 WD-7950-15 WASHER-SPRING
WD-8070-16 WD-8070-16 WIRE
WD-8070-15 WD-8070-15 WIRE
WD-8070-17 WD-8070-17 WIRE-GROUNDING
