Model Image
Manufacturer

Haier

Model Number

XPB70113SP

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WD-0155-07 WD-0155-07 BAG
WD-0250-10 WD-0250-10 BASE-HINGE
WD-0350-41 WD-0350-41 BELT
WH07X27710 WH07X27710 BELT-LOCKING
WD-0595-12 WD-0595-12 BLOCK-SLIDING
WD-0595-02 WD-0595-02 BLOCK-STABILIZING
WD-0750-29 WD-0750-29 BOLT
WD-1150-08 WD-1150-08 BUSHING-A
WH01X27841 WH01X27841 BUSHING-B
WD-1250-10 WD-1250-10 BUZZER
WD-1300-38 WD-1300-38 CABINET
WD-1330-02 WD-1330-02 CAM-SELECTOR
WD-1330-04 WD-1330-04 CAM-SELECTOR
WD-1640-39 WD-1640-39 CLAMP-DRAIN HOSE
WD-1640-37 WD-1640-37 CLAMP-DRAIN HOSE
WD-1685-05 WD-1685-05 CLUTCH
WH01X27874 WH01X27874 CORD-POWER
WD-1945-05 WD-1945-05 COUPLING
WD-1950-58 WD-1950-58 COVER
WD-1950-179 WD-1950-179 COVER-BACK
WD-1950-180 WD-1950-180 COVER-FLOW
WD-1950-181 WD-1950-181 COVER-SPIN TUB
WD-1950-59 WD-1950-59 COVER-VALVE [A]
WD-1950-182 WD-1950-182 COVER-WASH TUB
WD-2045-03 WD-2045-03 CYLINDER-OUTER
WH01X27926 WH01X27926 FILTER-LINT
WD-2800-35 WD-2800-35 FILTER-OVERFLOW
WD-2950-50 WD-2950-50 FRAME-BOTTOM
WD-2950-49 WD-2950-49 FRAME-TOP
WD-3100-21 WD-3100-21 GASKET
WD-3100-20 WD-3100-20 GASKET-EXPANSION
WD-3300-15 WD-3300-15 GUIDE-WATER
WD-3363-19 WD-3363-19 HARNESS-WIRE
WD-3570-106 WD-3570-106 HOSE-DRAIN
WD-3570-48 WD-3570-48 HOSE-WATER INLET
WD-3600-10 WD-3600-10 HOUSING-SPIN
WD-3600-11 WD-3600-11 HOUSING-WASH
WD-4000-36 WD-4000-36 KNOB
WD-4050-35 WD-4050-35 LABEL
WD-4250-25 WD-4250-25 LID-SPIN TUB
WD-4338-01 WD-4338-01 LINK-PULLBACK BRAKE
WD-4338-02 WD-4338-02 LINK-PULLBACK DRAIN
WD-9999-51 WD-9999-51 MANUAL - USE & CARE
WD-4600-38 WD-4600-38 NAMEPLATE
WD-5100-10 WD-5100-10 PAD-SHOCK A LOWER
WD-5100-11 WD-5100-11 PAD-SHOCK A UPPER
WD-5255-16 WD-5255-16 PIPE-CORRUGATED
WD-5255-17 WD-5255-17 PIPE-OVERFLOW
WD-5310-03 WD-5310-03 PLUG-VALVE
WD-5450-09 WD-5450-09 PULLEY-RADIATING
WD-5460-09 WD-5460-09 PULSATOR
WD-5950-07 WD-5950-07 ROD-CONNECTING
WD-6150-172 WD-6150-172 SCREW
WE02X26576 WE02X26576 SCREW
WD-6150-180 WD-6150-180 SCREW
WH02X26155 WH02X26155 SCREW
WE02X26386 WE02X26386 SCREW
WH01X27833 WH01X27833 SCREW
WH02X26865 WH02X26865 SCREW
WD-6150-179 WD-6150-179 SCREW
WD-6150-181 WD-6150-181 SCREW
WD-6150-178 WD-6150-178 SCREW
WD-6150-36 WD-6150-36 SCREW-BOLT WITH LOCK
WD-6200-21 WD-6200-21 SEAT - BEARING (A)
WD-6300-08 WD-6300-08 SHAFT-SPIN
WD-6750-51 WD-6750-51 SPRING
WD-6750-29 WD-6750-29 SPRING-KICK
WD-6750-23 WD-6750-23 SPRING-LIMIT PLATE
WD-6750-34 WD-6750-34 SPRING-SHOCK ABSORBE
WD-6750-31 WD-6750-31 SPRING-SMALL
WD-6750-30 WD-6750-30 SPRING-VALVE
WD-6900-02 WD-6900-02 STOPPER
WD-6945-03 WD-6945-03 STRAINER
WD-7000-16 WD-7000-16 SUPPORT-BRAKE PAD
WD-7100-33 WD-7100-33 SWITCH-MICRO
WD-7400-06 WD-7400-06 TIMER - SPIN
WD-7400-07 WD-7400-07 TIMER-WASH
WD-7745-59 WD-7745-59 TUB-SPIN
WD-7750-05 WD-7750-05 TUBE - BRAKE WHEEL
WD-7800-13 WD-7800-13 VALVE-ACCESS.
WD-7950-15 WD-7950-15 WASHER-SPRING
WD-8070-08 WD-8070-08 WIRE-EARTHING
WD-8070-02 WD-8070-02 WIRE-EARTHING
